BILLY GOAT QL TRUCK LOADER VACUUM
Accessories
INTAKE
HOSE
REPLACEMENT
KIT
Standard on QL
units.
[12"(305mm) x
10' (3.0m)]
P/N 790211
Part No 790294
QL2300 Owner's Manual
Owner's Manual
QL2300KO
EXHAUST
EXHAUST HOSE
KIT
[8"(203mm) x 5'
(1.5m)] Quick
release coupler
and flexible steel
hose increases
exhaust
distance.
P/N 790114
1
TRAILER
TRAILER QL
Heavy duty
spring axle trailer
designed for
towing your QL.
Allows unit to be
mounted for
pickup from rear
and both sides.
P/N 790112
Form No F061907B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QL2300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billy Goat QL2300

Summary of Contents for Billy Goat QL2300

  • Page 1 BILLY GOAT QL TRUCK LOADER VACUUM Accessories INTAKE HOSE REPLACEMENT Standard on QL units. [12"(305mm) x 10' (3.0m)] P/N 790211 Part No 790294 QL2300 Owner’s Manual Owner's Manual QL2300KO EXHAUST EXHAUST HOSE [8"(203mm) x 5' (1.5m)] Quick release coupler and flexible steel...

  • Page 2: Table Of Contents

    ABOUT THIS MANUAL THANK YOU for purchasing a BILLY GOAT manufactured to provide years of reliable and productive service. This manual provides complete operating and maintenance instructions that will help to maintain your machine in top running order. Read this manual carefully before assembling, operating, or servicing your equipment.

  • Page 3: Serial Plate Data And Specifications

    In compliance with 2000/14/EEC standards Sound at operators position Vibration at operator position BATTERY NOT INCLUDED: Part No 790294 QL2300 Owner’s Manual QL2300KO 23 (17.14kW) PA-76559 KOHLER COMMANDER 8qt. (7.57 L) REMOTE TANK 2.0 qt. (1.9 L), REMOTE OIL FILTER 399# (181.3 kg)

  • Page 4: General Safety

    This symbol indicates that this manual and the engine manufacturer’s manual should be read carefully before assembling, operation, or servicing this equipment. This symbol indicates important information that will prevent damage to your BILLY GOAT QL VACUUM. This symbol indicates the engine oil level should be checked before operating this equipment.
  • Page 5 ALWAYS check fuel lines and fittings frequently for cracks or leaks. Replace if necessary. ALWAYS keep hands and feet away from moving or rotating parts. ALWAYS store fuel in approved safety containers. Part No 790294 QL2300 Owner’s Manual Form No F061907B...

  • Page 6: Vibration Data

    Note: See parts list for proper impeller bolt torque specifications. (See trouble shooting section on page 13). Part No 790294 QL2300 Owner’s Manual SOUND LEVEL 93 dB(a) at Operator Position VIBRATION LEVEL 0.02g...

  • Page 7: Instruction Labels

    INSTRUCTION LABELS The labels shown below were installed on your BILLY GOAT this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and Item numbers shown.

  • Page 8: Packing Checklist & Assembly

    PACKING CHECKLIST Your Billy Goat is shipped from the factory in one carton and is completely assembled except for the exhaust elbow, nozzle, handle loop for nozzle, hose booms, hose bands, hose coupler, hose clamps and related hardware. READ all safety instructions before assembling unit.

  • Page 9: Operation

    HOSE: DO NOT drag the hose with vehicle. Never lift the machine while the engine is running. ALWAYS ATTACH NOZZLE TO THE TRAY BEFORE TRANSPORTING UNIT Part No 790294 QL2300 Owner’s Manual Form No F061907B...
  • Page 10 MOUNTING: Unit can be mounted in various positions. Figure 2 illustrates the mounting options available when using the optional trailer (Billy Goat Part no. 790112) available from your Billy Goat dealer. The unit can be mounted to allow vacuuming from either side as well as from the rear.
  • Page 11 HOSE STORAGE: Storing hose in a covered area, out of sunlight and heat will prolong hose life. Do not store hose where it could be stepped on or where other objects could crush or damage hose. Part No 790294 QL2300 Owner’s Manual Fig. 3 Fig. 4 Hose Hose Bands.

  • Page 12: Maintenance

    Note: 3/4"-10 x 3" bolt is included in each impeller replacement kit or the bolt can be ordered from your local Billy Goat Dealer (part no. 790214). 8. When impeller is free of the engine shaft, align impeller with the opening and pull it straight out of the housing.

  • Page 13: Warranty Claim Procedure

    Warranty Claim. • The distributor service manager will sign off on the claim and submit it to BILLY GOAT for consideration. • The Technical Service Department at BILLY GOAT will study the claim and may request parts to be returned for examination.

  • Page 14: Illustrated Parts & Parts Lists

    QL2300 Owner’s Manual PARTS DRAWING QL2300KO Part No 790294 Form No F061907B...

  • Page 15: Parts List

    LABEL SECURE NOZZLE 890132 PLUG RD 1" 890254 LABEL EAR EYE BREATHE 890301 LABEL READ Part No 790294 QL2300 Owner’s Manual PART ITEM *8024044 BOLT CARRAIGE 5/16-18 x 2 *8041030 SCREWCAP 5/16-18 x 1 1/2 *8041031 SCREWCAP 5/16-18 x 1 3/4 790310 GROMNET 1"...

  • Page 16: Maintenance Record

    QL2300 Owner’s Manual MAINTENANCE RECORD Date Service Performed Part No 790294 Form No F061907B...
