Sauer Danfoss H1 Technical Information page 9

Model Code
(continued)
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specifications
A B D F
H1 P
H
Mounting
F
ISO 3019-1, flange 101-2 (SAE B)
J Input shaft
G4 ISO 3019-1, outer dia 22 mm - 4 (SAE B, 13 teeth splined shaft
G5
ISO 3019-1, outer dia 25 mm - 4 (SAE B-B, 15 teeth splined shaft
G1
ISO 3019-1, outer dia 32 mm - 4 (SAE B, 14 teeth splined shaft
F2 Conical keyed shaft end similar to ISO 3019-1 code 25-3, taper 1:8 (key not supplied with pump)
K
Auxiliary mounting pad
NN
None
H2 ISO 3019-1, flange 82 - 2, outer dia 16 mm - 4 (SAE A, 9 teeth
H1 ISO 3019-1, flange 82 - 2, outer dia 19 mm - 4 (SAE A, 11 teeth
H3
ISO 3019-1, flange 101 - 2, outer dia 22 mm - 4 (SAE B, 13 teeth
H5 ISO 3019-1, flange 101 - 2, outer dia 25 mm - 4 (SAE B-B, 15 teeth
M
Overpressure protection type and setting side "A" **
N
Overpressure protection type and setting side "B" **
** Pressure protection type must be the same for side "A" and "B"
High pressure relief valve + pressure
L
limiters with bypass
High pressure relief valve only with bypass
K
(no pressure limiters)
L18 K18 180 bar [2610 psi]
L20 K20 200 bar [2900 psi]
L23 K23 230 bar [3336 psi]
L25 K25 250 bar [3630 psi]
L28 K28 280 bar [4061 psi]
L30 K30 300 bar [4350 psi]
L33 K33 330 bar [4786 psi]
L35 K35 350 bar [5080 psi]
L38 K38 380 bar [5510 psi]
L40 K40 400 bar [5800 psi] (45 cm
L42 K42 420 bar [6090 psi] (45 cm
Contact factory for pressures not shown or for applied pressure above maximum working pressure
(see System Pressure page
S
Charge pump
B
12 cm³/rev [0.73 in³/rev]
N No charge pump, external charge supply, (align with Option T: Filtration Options, option E)
T
Filtration options (align with option G: Endcap selection)
L Suction filtration
P
Remote full charge flow filtration
E External charge flow filtation
V
Charge pressure relief setting (contact factory for pressure not shown)
20 20 bar [290 psi]
24
24 bar [348 psi]
W Special hardware features
PN
None
P1 NFPE valve plate (align with option D: Control Selection and option E: Displacement Limiters)
11063344 • Rev EA • Dec 2012
E G H J K
F
only)
3
3 only)
5)
(see basic drawings)
(see endcap drawings)
(see endcap drawings), (align with option S: Charge pump, option N)
M N S T V W
/ pitch)
16
32
/ pitch)
16
32
12 / pitch)
24
/ coupling)
16
32
/ coupling)
16
32
/ coupling)
16
32
/ coupling)
16
32
Use the selection for ports "A" and "B"
X Y
N N N N N N
Shipping cover
9
