Speed And Temperature Sensor, Option H For Mounting Flange Option K - Sauer Danfoss H1 Technical Information

Installation Drawings
(continued)
Speed sensor connector
Deutsch DTM04-6P
Paint free
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
Installation Drawings
Speed and Temperature Sensor

Speed and Temperature Sensor, option H for mounting flange option K

19.8 ±2.1
9.7
1 ±0.5
106 ±0.8
Speed sensor
1
Connector
PIN ASSIGNMENT
1 Output signal 2
2 Direction
3 Output signal 1
4 Supply
5 Ground
6
6 Temperature
Please contact Sauer-Danfoss for specific installation drawings
11063344 • Rev EA • Dec 2012
Mounting ange
Flange 101-2
Per ISO 3019-1 (SAE B)
0
-0.5
R0.8 max
Z
Paint free
Z (2:1)
3
4
P301 310
2x 73 ±0.25
107.6 ±0.8
125.2 ±2.5
mm
2x ∅14.3
+0.25
-0.13
P700 33 206
43
