National Instruments PXI-2530B Installation Instructions Manual

INSTALLATION INSTRUCTIONS
160-Pin Cable for the NI PXI-2530B
This guide describes how to connect and use the National Instruments 160-pin shielded cable for the
NI PXI-2530B which has a maximum voltage rating of 60 VDC/30 VRMS, CAT I.
Contents
About the Cable ................................................................................................................................... 1
What You Need to Get Started ............................................................................................................ 2
Getting Started with the 160-Pin Cable for the NI PXI-2530B........................................................... 3
Cable Configuration............................................................................................................................. 4
Specifications....................................................................................................................................... 13
Accessories .......................................................................................................................................... 14

About the Cable

Use this shielded cable to connect the NI PXI-2530B switch module to your application. As illustrated
in Figure 1, one end of the cable connects to the NI PXI-2530B, and the other end of the cable terminates
with four 50-pin female D-SUB connectors. This cable is designed for use with the NI PXI-2530B and
will not mate with the NI PXI-2530.
Caution Refer to the Read Me First: Safety and Electromagnetic Compatibility document at
ni.com/manuals
Note This cable is for multiplexer use only. Matrix topologies are not supported.
for important safety and compliance information.
