Summary of Contents for Billy Goat TR1104

Page 1 BILLY GOAT TRUCK LOADER VACUUM Accessories INTAKE HOSE COUPLER HOSE KIT 8" (203mm) CONNECTOR KIT 8" (203mm) TR & 10" (254mm) HTR Quick release coupler joins 2 For permanently hoses together to connecting 2 hoses increase together to vacuuming increase...
Page 2: Table Of Contents
ABOUT THIS MANUAL THANK YOU for purchasing a BILLY GOAT and manufactured to provide years of reliable and productive service. This manual provides complete operating and maintenance instructions that will help to maintain your machine in top running order. Read this manual carefully before assembling, operating, or servicing your equipment.
Page 3: Serial Plate Data And Specifications
1.16 qt. (1.1 L) 274# (124.3 kg) 240# (108.0 kg) 121 dB(a) 121 dB(a) 105 dB(a) 105 dB(a) 0.02g 0.02g TR1104 11 (9.04 kW) 2104320125E1 BRIGGS & STRATTON 4.0 qt (3.8 L) 0.875 qt. (0.8 L) 224# (101.6 kg) 121 dB(a) 105 dB(a) 0.02g...
Page 4: General Safety
This symbol indicates that this manual and the engine manufacturer’s manual should be read carefully before assembling, operation, or servicing this equipment. This symbol indicates important information that will prevent damage to your BILLY GOAT HTR/TR VACUUM. This symbol indicates the engine oil level should be checked before operating this equipment.
Page 5 DO NOT run this equipment indoors or in any poorly ventilated area. Refueling outdoors is recommended. DO NOT refuel this equipment while the engine is running. Allow engine to cool for at least two minutes before refueling. DO NOT store gasoline near an open flame. DO NOT remove gas cap while engine is running.
Page 6: Vibration Data
SOUND Sound tests were conducted in accordance with 2000/14/EEC, and were performed on 5-28-2002 under the conditions listed below. Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on the unit for the sound power level for your model.
Page 7: Instruction Labels
INSTRUCTION LABELS The labels shown below were installed on your BILLY GOAT operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and Item numbers shown.
Page 8: Packing Checklist & Assembly
PACKING CHECKLIST Your Billy Goat is shipped from the factory in one carton and is completely assembled except for the exhaust elbow, nozzle, handle loop for nozzle, hose booms, hose bands, hose coupler, hose clamps and related hardware. READ all safety instructions before assembling unit.
Page 9: Operation
HTR/TR Owner’s Manual ASSEMBLY 1. ASSEMBLE exhaust elbow (item 10), to main unit and firmly tighten knobs (item 90), that are preassembled to main unit. 2. SECURELY ATTACH unit to tailgate of a truck or to a trailer, so that the exhaust discharges into an enclosed container. 3.
Page 10 VACUUMING OPERATION EXHAUST FLAPPER: Discharging into enclosed container, position exhaust flapper to desired opening and secure adjustment knob before starting engine. NOTE: An enclosed container must capture all debris delivered into it preventing any debris from blowing back onto unit's engine (see page 1 optional accessories). NOZZLE: With machine running and fully assembled, move nozzle in sweeping motions over debris.
Page 11: Maintenance
14. Using a new impeller bolt and lockwasher (and engine bolt lock clip, TR only), reinstall (engine for TR only) and new impeller in reverse order. 15. Tighten impeller bolt. Torque HTR1803V and TR1304H impeller bolt to [50 Ft. Lbs. (68 N.m)] and TR1104 to [60 Ft. Lbs. (81.4 N.m)] (see item 16 on page 15).
Page 12: Warranty Claim Procedure
Warranty Claim. • The distributor service manager will sign off on the claim and submit it to BILLY GOAT for consideration. • The Technical Service Department at BILLY GOAT will study the claim and may request parts to be returned for examination.
Page 13: Maintenance Record
HTR/TR Owner’s Manual MAINTENANCE RECORD Date Service Performed Part No 811202 Form No F021307B...
Page 14: Illustrated Parts & Parts Lists
HTR/TR Owner’s Manual PARTS DRAWING HTR/TR Part No 811202 Form No F021307B...
Page 15: Parts List
*8041009 810868 - - - 810912 811010 - - - - - - 810706 - - - 811192 811121 810927 TR1304H TR1104 PART NO. PART NO. - - - - - - 811174 811174 8164005 8164005 400424 400424 *8172008 *8172008...
Page 16 811005 811020 *8172020 *8041030 400268 811019 500267 890132 811100 811101 500282 890440 811139 811230 TR1304H TR1104 PART NO. PART NO. *8177012 - - - - - - *8181008 - - - - - - 8041052 8041052 *8041050 *8041050 *8041008 *8041008...
