16.07 Simulated-encoder output scaling
ô
0 ~ 15
Enter the required value in 16.07 for scaling the simulated-encoder output.
The scaling factor is as follows:
1
[ 16 07 .
2
16.08 Simulated encoder– F/D output enable
ô
0 ~ 1
Use 16.08 to select the output mode of terminals 50, 51, 53, 54, as follows:
16.08
0
1
16.09 S
ô
0 ~ 6143
16.09 indicates the value of phase offset. See Phase offset in Chapter 5
Setting up the UD52 for ways in which the value is entered.
The value is saved at power-down and is changed only when one of the
procedures in Phase offset is performed.
When the operating mode of the Drive is changed, 16.09 is reset to zero.
Restoring default values does not affect the value of 16.09.
16.10 S
ô
0 ~ 1
Set 16.10 at
automatically returns to 0). See Phase offset in Chapter 5 Setting up the
UD52.
UD52 User Guide
Issue code: 52nu3
ð
0
]
ð
0
Output mode
A/B quadrature signals
Frequency and direction signals
- encoder– phase offset
IN COS
ð
- encoder phasing test
IN COS
ð
0
to initiate the encoder phasing test (on completion, 16.10
1
n
2 RW Uni
RW Bit
1/6143 rev. RW Uni S
RW Bit
P
21
