Note: Swirl patterns in the
UV filter, if present, do not
interfere with viewing or photo
documentation of gels.
•
p2

Unpacking

Unwrap all packages carefully and compare
contents with the packing list, making sure all
items arrived. If any part is missing, contact
your local Hoefer, Inc. sales office. Inspect all
components for damage that may have occurred
while the unit was in transit. If any part appears
damaged, contact the carrier immediately. Be
sure to keep all packing material for damage
claims or to use should it become necessary to
return the unit.

Specifications

Ultraviolet lamps
• UV-25: Six 8-W 302 nm UV dual bi-pin discharge
type tubes
Filter
• The factory-installed filter is for 254 nm and 302 nm
lamps only. Do not use with 365 nm lamps.
• The expected life of the filter is 5000 hours.
Input fuses
• 115 V: T 1A/250V 5 × 20 mm (2 fuses)
• 230 V: T 1A/250V 5 × 20 mm (2 fuses)
Dimensions (h
×
External: 12.1 × 24.1 × 33.7 cm
(4.75 × 9.50 × 13.25 in.)
Safety
• All electric components are HYPOT tested to 1500 V.
• The filter is covered by a 3 mm (1/8")-thick UV
blocking safety shield
• CE certified
• EN61010-1:2001, EN61326-1:2006,
EN50081-1:1992, EN50081-2:1993,
EN50082-1, EN50082-2, EN61000-3-2,
EN61000-3-3, EN170:2002
Features
• The variable intensity dial adjusts to a lower UV
intensity for preparative work.
• Removable power cord
d w)
×
