Numbers of inputs
On-state voltage range
Typical signal delay
Number of outputs
Maximum Supported output voltage
Typical output current (DIR and STEP outputs)
Typical output current (general purpose pins)
Maximum supported frequency
Typical signal delay
3.0
BOARD DESCRIPTION
User's Manual
OPTOISOLATED DIGITAL INPUT SPECIFICATIONS
OPEN COLLECTOR OUTPUT SPECIFICATIONS
18
5 to 24V DC
Less than 500uS
16
30VDC
30mA
500mA
250KHz
Less than 8nS
Page 3
