Isolate Input
4.6
Controller selection jumpers (IEEE1284/SS)
Some motion controllers are not IEEE1284 compatible, set the jumper select the
compatibility. Set it Non-Compatible if pull-up resistors in the motion controllers activate
outputs when not supposed to.
Compatible (IEEE1284)
Not Compatible (IEEE1284)
User's Manual
Page 8
