FEATURES

• Connects directly to the motion controller or Parallel Ports.
• IEEE 1284 Standard compatible.
• Built-in PWM-Based Speed Control.
• Two Built-in Electromechanical Relays with NO and NC positions for
spindle control.
• RJ45 Connector for Easy VFD Connection.
• Monitors E-Stop, Safety Charge Pump and fault signal from drivers.
• Monitors VFD alarm signal.
• Can enable and disable the drives.
• Electromechanical Relay with NO and NC positions for general purpose
(Port_2 16 or 17, jumper-selectable).
• Microcontroller based SCHP.
• RJ45 connectors for the axis.
• Opt -isolated inputs.
• Power terminal (12VDC / 24VDC).
• Outputs can be 500mA open collector or +5vdc at 24mA TTL.
• Status LEDs on all inputs and output connections.
• Works directly with popular CNC hardware and software.
• 18 inputs and 16 outputs on 2 ports.
