MediaPack™ 1288 Analog Gateway
Quick Setup Guide
Welcome
Congratulations on purchasing your AudioCodes MediaPack 1288 (MP-1288) High-Density Analog Gateway,
hereafter referred to as device!
This document is only intended to provide basic setup instructions for initial access to the device and
connecting it to your network. For advanced configuration and cabling, refer to the device's User's Manual and
Hardware Manual respectively, which can be downloaded from AudioCodes website at
https://www.audiocodes.com/library/technical-documents.
Before you begin, please read the
Package Contents
Make sure that the following items (in addition to any separate-orderable items that you may have purchased)
are included with your shipped device:
2 x front-mounting brackets for 19-inch rack mounting
1 x RJ-45-to-DB-9 serial cable adapter for serial communication
(AC-powered models) 2 x AC power cords
(DC-powered models) 2 x DC terminal blocks
1 x grounding lug
Regulatory Information document
Safety Precautions
on page 9.
1 |
P a g e

Advertisement

loading
Need help?

Need help?

Do you have a question about the MediaPack 1288 and is the answer not in the manual?

Questions and answers

Summary of Contents for AudioCodes MediaPack 1288

  • Page 1 MediaPack™ 1288 Analog Gateway Quick Setup Guide Welcome Congratulations on purchasing your AudioCodes MediaPack 1288 (MP-1288) High-Density Analog Gateway, hereafter referred to as device! This document is only intended to provide basic setup instructions for initial access to the device and connecting it to your network.
  • Page 2 Physical Description of Front Panel Fan Tray module cover LED indicating system status: Green On Device is operating normally or initial boot-up stage when device is powered on Orange On Device is approaching high-temperature threshold, but not yet critical Red On Fault detected in CPU module, or ...
  • Page 3 Physical Description of Rear Panel Central processing unit (CPU) module, providing: Reset pinhole button for resetting the device (2-10 second press) and restoring  factory defaults (11-30 second press) STAT LED indicating CPU status (same as SYS LED on front panel) ...
  • Page 4: Mounting The Device

    Mounting the Device You can mount the device in a standard 19-inch rack. Attach the two front-mounting brackets (supplied) to both sides of the chassis. Each bracket is secured to the chassis using 9 screws (supplied). With two people, lift the chassis into the rack from the front of the rack. Hold the chassis for support while the second person positions the chassis so that the front-mounting brackets are flush against the front-rack posts and that the holes of the front-mounting brackets are aligned with the holes on the front-rack post.
  • Page 5 Cabling the Device to Power The device can be powered from a standard alternating current (AC) electrical wall outlet or a DC power source. 1. GROUNDING: Ground (earth) the device by inserting an electrically earthed strap of 16-AWG (minimum) wire in to grounding lug (supplied), and then attaching the lug to the chassis using the two screws and spring washers.
  • Page 6 3. DC POWER: For each DC power model, disconnect your DC wires from your DC power source, and then connect the two DC wires (6-AWG) to the DC terminal block plug (supplied), making sure that the wires are inserted in to the correct openings on the terminal block according to their polarity (negative or positive).
  • Page 7: Assigning An Ip Address

    Assigning an IP Address Use the device's factory default IP address (192.168.0.2/24 and Default Gateway 0.0.0.0) to initially access the device's Web-based management interface and then change it to suit your network's addressing scheme for subsequent connectivity. Using a CAT-5e/6 shielded twisted pair (STP) straight-through RJ-45 Ethernet cable, connect any one of Ethernet ports of the CPU module (rear panel) to the LAN port of your computer.
  • Page 8 Re-cable the device to the required network. You can now access the device's management interfaces remotely, using the new IP address. Obtaining Software and Documentation If you have a maintenance and support agreement with AudioCodes, you can download the device's latest software version from AudioCodes' Services Portal at https://services.audiocodes.com (registered users only).
  • Page 9: Safety Precautions

    Safety Precautions The device must be installed and serviced only by qualified service personnel.  The device is considered as IPX0 non-water ingress protected and therefore, must be installed only  indoors. Do not expose the device to water or moisture. ...
  • Page 10 Website: https://www.audiocodes.com/ ©2019 AudioCodes Ltd. All rights reserved. AudioCodes, AC, HD VoIP, HD VoIP Sounds Better, IPmedia, Mediant, MediaPack, What’s Inside Matters, OSN, SmartTAP, User Management Pack, VMAS, VoIPerfect, VoIPerfectHD, Your Gateway To VoIP, 3GX, VocaNom, AudioCodes One Voice and CloudBond are trademarks or registered trademarks of AudioCodes Limited.
