  • Page 1 Cobalt Qube User Manual...
  • Page 2 For a complete listing of the software used within the Cobalt Qube 2, and the terms under which it can be distributed, refer to the Cobalt Web site at http://www.cobalt.com.

  • Page 3: Important Safeguards

    Important Safeguards For your protection, please read all these instructions regarding your Cobalt Qube 2 and retain for future reference. 1. Read Instructions Read and understand all the safety and operating instructions before operating the appliance. 2. Ventilation The Cobalt Qube 2’s bottom vents and fan opening are provided for ventilation and reliable operation of the product, and to protect it from overheating.
  • Page 4 Both Netscape Navigator® and Microsoft® Internet Explorer have bugs that can cause intermittent, unexplained failures. When using a Web browser to interact with your Cobalt Qube 2, you may occasionally experience a browser failure. Released product versions of the browsers are usually more reliable than beta versions and later versions typically work the most reliably.
  • Page 5 Regulations and Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 7: Table Of Contents

    Contents Important Safeguards 1 Introduction General Front view of the Qube 2 Rear view of the Qube 2 Qube 2 requirements Target audience for the Qube 2 Cobalt Developer Network Organization of the user manual List of chapters and appendices Customer Service and Technical Support General Cobalt information Cobalt Technical Support and Service...
  • Page 8 Contents Phase 2: Setting up with the Web browser Active Assist — Online Help Configuring the Qube 2 with the Setup Wizard Network Integration Administrator Setup Password guidelines Services Setup Time Setup Access Rights Users Setup Groups Setup Product Registration Completing configuration with the Setup Wizard 3 Services on the Qube 2 Managing your Personal Profile...
  • Page 9 Contents Working in collaboration through discussions Dynamic Host Configuration Protocol (DHCP) server What is DHCP and what are the benefits? What is a configuration? What are leases? How does DHCP work? Domain Name System (DNS) Network Address Translation (NAT) IP Firewall Internet access through high-speed serial port Searching for information on the Qube 2 Managing documents...
  • Page 10 Contents Mailing lists Configuring the mailing list settings Adding a mailing list Forwarding incoming email to several recipients Modifying a mailing list Removing a mailing list Network Ethernet settings Entering the settings for the network configuration Network Address Translation (NAT) Enabling or disabling the NAT feature Modem settings and the high-speed serial port Changing the modem settings...
  • Page 11 Contents IP Firewall Adding an IP filtering rule Modifying an IP filtering rule Removing an IP filtering rule Time Maintenance Backup Manual backup Scheduled backup Backup file locations Restore Install software Third-party software Installing third-party software Reboot Shutdown System Status Memory Central Processing Unit (CPU) Disk...
  • Page 12 Contents 5 Public Site Home View Users Viewing the users Viewing a user’s personal Web page Sending an email to another user Creating Web content View Groups Viewing the groups Viewing a group’s public Web page Viewing a group’s private Web page Sending an email to a group Posting a message to a discussion thread Creating Web content...
  • Page 13 Contents Usage data Backup Restore Page Builder Accessing the Page Builder tool Page Builder window Programs Managing documents Using the Infoplace Document Organizer Logging in to an InfoBase Accessing online help Designating easy-to-find documents Finding specific documents Administrator Site A Using the LCD console Changing network configuration Rebooting Powering down...
  • Page 14 Contents C Advanced Information URL for the default Qube 2 home page Telnet access CGI scripts D Domain Name System Basic DNS Enabling the DNS server feature Configuring a primary DNS server Specifying a reverse lookup (PTR) record Specifying a mail server (MX) record Specifying an alias (CNAME) record Configuring a secondary DNS server Adding a secondary name-server authority...

  • Page 15: Introduction

    Chapter 1 Introduction The Cobalt Qube 2 is a powerful and versatile network server. It fits easily within an existing network, and it enhances workgroup activities by providing many communication and collaboration services. Here is a sample of what you can do with the Cobalt Qube 2: •...

  • Page 16: General

    Chapter 1 General Figure 1 and Figure 2 show the Qube 2 controls, indicators and connectors. Front view of the Qube 2 The indicator light bar on the front glows green when the Qube 2 is powered on. Figure 1 Qube 2 front view Power On Indicator...

  • Page 17: Rear View Of The Qube 2

    Introduction Rear view of the Qube 2 Figure 2 shows the controls and connectors on the back panel. Figure 2 Qube 2 rear view Security lock hole PCI slot shield screen On/Off switch Reset Password console Locking power socket Secondary Primary Serial port Network...

  • Page 18: Qube 2 Requirements

    Chapter 1 5. The Secondary Network Interface accepts a second 10/100 BaseTX network cable and, as an option, can connect the Qube 2 to the Internet. 6. The Primary Network Interface accepts a 10/100 Base-TX network cable and is used to connect the Qube 2 to your intranet. 7.

  • Page 19: Target Audience For The Qube 2

    Introduction Target audience for the Qube 2 The user manual is for anyone who will set up the Qube 2 network server appliance for a group of users. You should be familiar with Microsoft® Windows , Macintosh® or other operating systems, and Netscape Navigator®, Microsoft®...
  • Page 20 Chapter 1 Figure 3 Administrator Site screen Figure 4 Public Site screen...

  • Page 21: List Of Chapters And Appendices

    Introduction List of chapters and appendices Chapter 1 “Introduction” on page 1 includes an overview of the Qube 2’s features and directs you to the information in other chapters of this guide. Chapter2 “Setting up the Qube 2” on page 13 describes the hardware setup of the Qube 2 and the network integration process.

  • Page 22: Customer Service And Technical Support

    Chapter 1 Customer Service and Technical Support For Cobalt product information, visit the support section of the Cobalt Web site at http://www.cobalt.com/support/. The site includes a Knowledge Base that customers can query; a list of Frequently Asked Questions (FAQs) that provide additional information is also available through the Knowledge Base.

  • Page 23: Further Information

    Introduction Further information Cobalt also offers other information resources. Discussion Groups Cobalt has made available a number of discussion groups through which users can share information. To view the current list of Cobalt discussion groups, type the URL http://www.cobalt.com/support/resources/usergroups.html. The names of the discussion groups show up as hypertext links.

  • Page 24: Before Contacting Cobalt Networks Technical Support

    Chapter 1 Solutions For customers looking for business-case information concerning Cobalt products, there are also a number of white papers available on Cobalt’s Web site at http://www.cobalt.com/solutions/ . Developers If you are a software or hardware developer, look for information at http://developer.cobalt.com/ . Before contacting Cobalt Networks Technical Support First, make an effort to resolve the problem on your own.

  • Page 25: Cobalt Logo Badge

    Introduction Cobalt logo badge For more information on the Qube 2 server, click on the Cobalt Networks logo badge in the top left corner. A table with the configuration information for your Qube 2 server appears. The table shows: • the amount of RAM •...
  • Page 26 Chapter 1...

  • Page 27: Setting Up The Qube 2

    Setting up the Qube 2 This chapter guides you through the process of connecting and configuring the Cobalt Qube 2 for your network and user community. A typical setup process takes less than 15 minutes, after which you can begin using all of the Qube 2 services.

  • Page 28: Connecting The Locking Power Supply

    Chapter 2 If you want to connect the Qube 2 to the Internet, you can use either an external modem or the Secondary Network Interface (if you have a leased line to the Internet). • For a modem connection to the Internet: Connect a standard (Hayes-compatible) external modem to the serial port of the Qube 2;...

  • Page 29: Using The Lcd Console To Configure The Network

    Setting up the Qube 2 so, the Qube 2 tries to configure itself automatically. If not, you must enter the necessary information manually, using the LCD console on the back of the Qube 2; see Figure 6. Before you proceed, make sure you have the following information: •...

  • Page 30: Configuring The Qube 2 Through A Dhcp Server

    Chapter 2 During startup, the LCD screen on the back of the Qube 2 displays status information about the boot process itself. When setting up the Qube 2, you use the LCD console to enter network configuration information for the Qube 2. Once the Qube 2 is running, the LCD console is used to change network configuration information, reboot the unit and power down the unit.

  • Page 31: Configuring The Qube 2 Manually

    Setting up the Qube 2 Configuring the Qube 2 manually IMPORTANT: In this phase, you configure only the Primary Network Interface. To complete this phase, you must know: • the IP address assigned to the Qube 2 • the subnet mask of your network Note: A gateway or router address is not required for a Qube 2 that is only connected to a local area network (LAN).
  • Page 32 Chapter 2 5. Enter the IP address of the gateway for your network. If your network does not have a gateway, do not enter a number — press button to accept the default value of Enter “000.000.000.000.” Note: A gateway or router address is not required for a Qube 2 that is only connected to a local area network (LAN).

  • Page 33: Phase 2: Setting Up With The Web Browser

    Setting up the Qube 2 Phase 2: Setting up with the Web browser The remainder of the setup process is performed through a Web browser on any computer on your network. Use one of the standard browsers available (for example, Netscape Navigator or Microsoft Internet Explorer, versions 3.0 or later) to do this.

  • Page 34: Active Assist - Online Help

    Chapter 2 Active Assist — Online Help Active Assist provides real-time context-sensitive help on the UI. To access Active Assist, place the cursor over the icon beside any item. A description of the item appears at the bottom of the browser page.
  • Page 35 Setting up the Qube 2 On this screen, you can: • assign a host name (for example, qube1) to the Qube 2 • enter your domain name (the official name that is registered with InterNIC, for example, cobalt.com) The host name and domain name must be coordinated with your network administrator in order for you to access the Qube 2 by its name and not just by its IP address.

  • Page 36: Administrator Setup

    Chapter 2 Administrator Setup The Administrator Setup screen appears; see Figure 9. The Qube 2 Administrator has several responsibilities: setting up and maintaining the users, groups and services on the Qube 2 responding to email alerts from the Qube 2 in order to forestall potential problems Figure 9 Administrator Setup (screen 2 of 7)
  • Page 37 Setting up the Qube 2 To set up the Qube 2 Administrator, you must enter the following information. • Full name Enter the first name and last name, separated by a space, of the person serving as the Qube 2 Administrator. •...

  • Page 38: Password Guidelines

    Chapter 2 Password guidelines Use the following guidelines when choosing a password: 1. Use between six and eight alphanumeric characters; you can use a password with more than eight characters, but Linux truncates the password at eight characters and verifies the password against those eight characters only.

  • Page 39: Services Setup

    Setting up the Qube 2 Services Setup The Services Setup screen appears; see Figure 10. Choose the services that you would like to be active on the Qube 2. For an explanation of services, refer to Chapter 3, “Services on the Qube 2”, on page 33.

  • Page 40: Time Setup

    Chapter 2 Time Setup The Time Setup screen appears see Figure 11. Enter the current date, time and time zone on the Qube 2. For more information on the time settings, see “Time” on page 110. Click the NEXT button to move to the next screen. Figure 11 Time Setup (screen 4 of 7)

  • Page 41: Access Rights

    Setting up the Qube 2 Access Rights The Access Rights screen appears; see Figure 12. Two options are available: • The open option allows any individual to self-register as a user. • The restricted option allows only the Qube 2 Administrator to add a user.

  • Page 42: Users Setup

    Chapter 2 Users Setup The Users Setup screen appears; see Figure 13. From this screen, you can add users to the Qube 2 and allocate the user disk space limits. The Qube 2 Administrator can modify how the Qube 2 selects the user name, password and the default disk usage limits by clicking Set User Defaults.

  • Page 43: Groups Setup

    Setting up the Qube 2 Groups Setup The Groups Setup screen appears; see Figure 14. On this screen, the Qube 2 Administrator can create different groups of users. Each group has its own mailing list, Web site, file storage and private discussion area.

  • Page 44: Product Registration

    Chapter 2 Product Registration The Product Registration screen appears; see Figure 15. If you are connected to the Internet, you can register the Qube 2 by completing the online registration. If you are not connected to the Internet, this screen does not appear. Fill out the registration card included in the packaging materials and return it to Cobalt Networks, Inc.
  • Page 45 Setting up the Qube 2 Figure 15 shows the online registration page. Figure 15 Online registration page...
  • Page 46 Chapter 2 Figure 16 shows the Public Site screen on the Qube 2. Figure 16 Public site on the Qube 2...

  • Page 47: Services On The Qube 2

    Services on the Qube 2 This chapter offers a brief overview of the services available on the Cobalt Qube 2. The services are described in detail in Chapter 4, “Administrator Site”, on page 55 and Chapter 5, “Public Site”, on page 129.

  • Page 48: Managing Your Personal Profile

    Chapter 3 Managing your Personal Profile Registered users on the Qube 2 can manage their own Personal Profile using any standard Web browser. The features accessible from this screen are: • modify user • email • usage data • backup •...

  • Page 49: Setting Up Your Email Client

    Services on the Qube 2 Setting up your email client Ensure that the following information is entered into your email client on your personal computer. Note: The Qube 2 does not offer an email client. The Qube 2 is an email server that receives email addressed to a domain name.

  • Page 50: Email Aliases

    Chapter 3 Email aliases Each registered user on the Qube 2 must have a unique user name (for example, mary or john.smith or khoward). This user name is used to send or retrieve email. The Email Alias feature allows you to create an arbitrary email address without creating a user account on the Qube 2.

  • Page 51: Email Relaying

    Services on the Qube 2 Email relaying Simple Mail Transfer Protocol (SMTP) service is different from Post Office Protocol (POP), telnet and file transfer protocol (FTP) services in that SMTP does not try to authenticate a user when an SMTP connection is made.

  • Page 52: Developing Web Pages

    Chapter 3 If you have users who access your server through the Internet, ask your Internet Service Provider (ISP) which networks are used by their remote access (dial-up) equipment. For example, if the ISP says the network 192.168.10.5 through 192.168.10.24, then enter “192.168.10” to the “Relay email from these hosts/domains”...

  • Page 53: Using Page Builder

    Services on the Qube 2 Using Page Builder The Qube 2 includes Page Builder, a tool that allows you to create Web pages without having to learn how to write HTML scripts. To enter the Page Builder tool: • click Edit This Page at the bottom of your home page, or •...

  • Page 54: Publishing Web Pages Using Ftp

    Chapter 3 Use FTP to upload .cgi and .pl files; use ASCII mode to upload CGI files. Once the file is on the Qube 2, use your FTP program to make the script executable. You can also use the telnet command: chmod 775 <filename>.cgi.

  • Page 55: Sharing Files And Transferring Data

    Services on the Qube 2 Sharing files and transferring data You can access or connect to the Qube 2 through your desktop computer as you would any other shared network volume. The Qube 2 can be mounted from any Windows or Macintosh computer — it appears as a mounted volume on your desktop computer.

  • Page 56: Using Windows File Sharing (Smb)

    Chapter 3 Using Windows file sharing (SMB) Windows-based machines use a file-sharing protocol called Server Message Block (SMB) or Common Internet File System (CIFS). Once SMB is set up, the Qube 2 appears in your Network Neighborhood as a machine named <hostname>. The <hostname> is the name that the Qube 2 Administrator assigned to the Qube 2, either in the Setup Wizard or the Control Panel screen of the Qube 2 Administrator Site.
  • Page 57 Services on the Qube 2 Setting up Windows file sharing for Windows 95 and 98 1. If the user name is the same on both your computer and the Qube 2, go to Step 6. 2. If the user name on your computer is different from the user name on the Qube 2, click the Start button in the bottom left corner of your screen.
  • Page 58 Chapter 3 8. Once the Qube 2 shows up in the Network Neighborhood list, double-click it to open it on your desktop computer. A password prompt appears. Enter the user name and password used on the Qube 2; the password is case-sensitive. Click OK.

  • Page 59: Windows Nt

    Services on the Qube 2 4. You may want to log in to the Qube 2 as a different user. If you see a password prompt in Step 3, you can do so. However, if your Windows NT account uses the same user name and password as the Qube 2, account, the password prompt in Step 3 will not appear.

  • Page 60: Using Appleshare Over Ip

    Chapter 3 Using AppleShare over IP The Qube 2 supports the use of AppleShare over IP, which means you can access your Qube 2 across an intranet or over the Internet. The Qube 2 shares its volume through AppleShare over IP by default. If you want to connect to a remote Appleshare volume over the Internet: 1.

  • Page 61: Working In Collaboration Through Discussions

    Services on the Qube 2 Working in collaboration through discussions Threaded discussions allow groups of individuals to develop and document a body of information on a particular topic. The discussion feature lets users collaborate without having to meet face-to-face. This feature is especially useful for individuals who are geographically dispersed or who otherwise find it difficult to meet.

  • Page 62: What Is A Configuration

    Chapter 3 What is a configuration? The Qube 2 DHCP configuration includes the default Gateway, DNS servers, subnet mask and IP address from an address pool. What are leases? When the Qube 2 sends a configuration to a requesting DHCP client, one of the DHCP options returned is the lease time.
  • Page 63 Services on the Qube 2 2. The Qube 2, as a DHCP server, receives the DHCP Discover request from a client and sends a reply, known as a DHCP Offer, to the DHCP client. 3. The DHCP client looks at the DHCP Offer it has received from the Qube 2 and sends back an acknowledgment (ACK) message to the Qube 2.

  • Page 64: Domain Name System (Dns)

    Chapter 3 Domain Name System (DNS) The Domain Name System (DNS) is a vital and integral part of the Internet. Setting up DNS correctly on your Qube 2 is very important. For this reason, we have created an appendix solely for explaining DNS. See Appendix D, “Domain Name System”, on page 173.
  • Page 65 Services on the Qube 2 For outgoing packets, NAT translates a private IP address (an IP address that is not globally unique) on the internal network into the legal address of the secondary interface; packets are then forwarded onto the Internet. For incoming packets, NAT does the opposite.

  • Page 66: Ip Firewall

    Chapter 3 IP Firewall A firewall is a set or filtering rules used to allow or deny IP packets access to the Qube 2. The IP Firewall option allows you to specify simple packet-filtering rules, which limit access to your Qube 2. You can choose to deny or allow communication in either direction between your Qube 2 and any or all IP addresses.

  • Page 67: Managing Documents

    Services on the Qube 2 Managing documents The InfoPlace Document Organizer allows users to store information — documents, images, graphics, multimedia files and URLs — on the Qube 2 in such a way that other users can find it quickly. The InfoPlace Document Organizer is entirely Web-based;...
  • Page 68 Chapter 3...

  • Page 69: Administrator Site

    Chapter 4 Administrator Site This chapter describes the functions that can be performed only by the Cobalt Qube 2 Administrator. To access the Qube 2 Administrator Site, you can either: • from the Public Site, click Administrator Site on the left, or •...
  • Page 70 Chapter 4 Figure 17 Administrator Site screen...

  • Page 71: Qube 2 Administrator

    Administrator Site Qube 2 Administrator The Qube 2 Administrator, with the user name “admin”, has full control of the Qube 2. The administrator enters the network settings, enables or disables the various services, performs maintenance functions and receives system alerts and warnings by email. The Qube 2 Administrator is automatically a member of each group created on the Qube 2.
  • Page 72 Chapter 4 Figure 18 shows the Administrator Settings table. Figure 18 Administrator Settings table...

  • Page 73: Modifying The Qube 2 Administrator Settings

    Administrator Site Modifying the Qube 2 Administrator settings Caution: Be sure to remember the password you enter here — otherwise, you will need to reset it (See “Resetting the Qube 2 Administrator password” on page 60). To modify the settings for the Qube 2 Administrator: 1.

  • Page 74: Resetting The Qube 2 Administrator Password

    Chapter 4 Resetting the Qube 2 Administrator password When the Qube 2 Administrator password is cleared, the root account is not accessible until a new administrator password is assigned. Caution: After you clear the password, enter a new one as soon as possible to protect the security of the Qube 2.

  • Page 75: Users

    Administrator Site Users In the Users section, you can manage user settings and the Qube 2 Administrator settings. To access this section, on the Administrator Site, click the Users button on the left. The Users List table appears; the table displays the full name of each user (for example, Jessica Smith) and the name he or she uses to log in to the Qube 2 (for example, jsmith).
  • Page 76 Chapter 4 Figure 19 shows the User Defaults table. Figure 19 User Defaults table...

  • Page 77: Adding A User

    Administrator Site Adding a user To add a user: 1. On the Administrator Site screen, click Users on the left. The Users List table appears. Click Add User. The Add New User table appears. See Figure 20. Fill in the fields: •...
  • Page 78 Chapter 4 Figure 20 shows the Add New User table. Figure 20 Add New User table...

  • Page 79: Modifying A User Account

    Administrator Site Modifying a user account To modify the information for user’s account: 1. On the Administrator Site screen, click Users on the left. The Users List table appears. In the Users List table, locate the user whose account information you want to modify.

  • Page 80: Modifying A User's Email Settings

    Chapter 4 Modifying a user’s email settings To change a user’s email settings: 1. On the Administrator Site screen, click Users on the left. The Users List table appears. In the Users List table, locate the user whose email settings you want to modify.
  • Page 81 Administrator Site Figure 21 shows the Email Settings table for a user. Figure 21 Email Settings table...

  • Page 82: Adding An Email Alias For A User

    Chapter 4 Adding an email alias for a user To add an email alias for a user: 1. On the Administrator Site screen, click Users on the left. The Users List table appears. In the Users List table, locate the user for whom you want to add an email alias.

  • Page 83: Groups

    Administrator Site Groups In the Groups section, you can manage the group settings. To access this section, on the Administrator Site, click Groups on the left. The Groups List table appears; see Figure 22. The table displays the group name and the members of each group. You can add groups to the Qube 2 and allocate disk space for each group.

  • Page 84: Configuring The Group Settings

    Chapter 4 Figure 22 shows the Groups List table. Figure 22 Groups List table Configuring the group settings The Qube 2 Administrator can: • configure the default group settings • add a group • modify the members of a group and the maximum allowed disk space for the group •...

  • Page 85: Configuring The Default Group Settings

    Administrator Site Configuring the default group settings To configure the default settings for a group: 1. On the Administrator Site screen, click Groups on the left. The Groups List table appears. Click Set Group Defaults. The Group Defaults table appears. See Figure 23.

  • Page 86: Adding A Group

    Chapter 4 Adding a group To add a group: 1. On the Administrator Site screen, click Groups on the left. The Groups List table appears. Click Add Group. The Add New Group table appears. See Figure 24. Fill in the fields: •...
  • Page 87 Administrator Site Figure 24 shows the Add New Group table. Figure 24 Add New Group table...

  • Page 88: Modifying A Group

    Chapter 4 Modifying a group To modify the members of a group or the maximum allowed disk space for the group: 1. On the Administrator Site screen, click Groups on the left. The Groups List table appears. In the list, locate the group that you want to modify. Click the green pencil icon next to that group.

  • Page 89: Removing A Group

    Administrator Site Removing a group To remove a group: Caution: You cannot undo this action. If you remove a group, you delete the group, all of the files in the group directory, the group directory itself, the associated mailing list for that group (if one has been created), and the Windows file sharing and Appleshare settings.
  • Page 90 Chapter 4 A mailing list with a dimmed trashcan is a mailing list created as part of a group on the Qube 2. A mailing list can receive email from an address that is external to the Qube 2. Note: When you reply to a message addressed to a mailing list, your reply is copied to everyone on the mailing list;...

  • Page 91: Configuring The Mailing List Settings

    Administrator Site Configuring the mailing list settings The Qube 2 Administrator can: • add a mailing list • modify a mailing list • remove a mailing list Adding a mailing list To add a mailing list: 1. On the Administrator Site screen, click Mailing Lists on the left. The Mailing Lists table appears.

  • Page 92: Forwarding Incoming Email To Several Recipients

    Chapter 4 Figure 26 shows the Add Mailing List table. Figure 26 Add Mailing List table Forwarding incoming email to several recipients If a user will not be accessing his or her email account for a period of time and wants to forward incoming email messages to several recipients, the Qube 2 Administrator can create a mailing list for the user.

  • Page 93: Modifying A Mailing List

    Administrator Site Modifying a mailing list To modify a mailing list: 1. On the Administrator Site screen, click Mailing Lists on the left. The Mailing Lists table appears. 2. In the list, locate the group that you want to modify. 3.

  • Page 94: Removing A Mailing List

    Chapter 4 Removing a mailing list A mailing list with a dimmed trashcan is a mailing list created as part of a group on the Qube 2. To remove this mailing list, you must remove the corresponding group. See “Removing a group” on page 75. To remove a mailing list: 1.

  • Page 95: Ethernet Settings

    Administrator Site Ethernet settings Be sure to enter the IP address of your DNS server(s) here. Otherwise, the Simple Mail Transfer Protocol (SMTP) will not work. SMTP is used for transferring electronic mail messages. For more information on DNS, see Appendix D, “Domain Name System”, on page 173.

  • Page 96: Entering The Settings For The Network Configuration

    Chapter 4 Entering the settings for the network configuration To enter or change the settings for the network configuration for the Qube 2: 1. On the Administrator Site screen, click Network on the left. The settings tables for the network configuration appear. See Figure 27. Modify the one or all of the general settings.
  • Page 97 Administrator Site • Secondary DNS server address This is the IP address of your secondary DNS server. A secondary DNS server can provide redundant DNS service to your computers. If the primary DNS server is turned off, then your Qube 2 can use the secondary DNS server with no loss of performance.

  • Page 98: Network Address Translation (Nat)

    Chapter 4 Network Address Translation (NAT) The Network Address Translation (NAT) feature allows the Qube 2 to present a single IP address for a private network to the public network. NAT enables private IP intranetworks that use non-registered IP addresses to connect to the Internet. NAT is both a security measure and a method of conserving IP addresses.
  • Page 99 Administrator Site The Qube 2 Administrator can also determine the connection mode between the Qube 2 and the ISP. There are three possible connection-mode settings; these settings determine how the Qube 2 uses the modem to connect to your ISP. •...

  • Page 100: Changing The Modem Settings

    Chapter 4 Changing the modem settings To enter or change the modem settings for the Qube 2: 1. On the Administrator Site screen, click Network on the left. The settings tables for the network configuration appear. Click Modem at the top. The Modem Dial-out Settings table appears.

  • Page 101: Verifying The Status Of The Modem Connection

    Administrator Site Verifying the status of the modem connection To verify the status of the modem connection: 1. On the Administrator Site screen, click System Status on the left. The Memory Status table appears. 2. Click Modem at the top. The Modem Status table appears. See Figure 28.

  • Page 102: Services

    Chapter 4 Services Figure 29 shows the Service Settings table of the Services section. Figure 29 Service Settings table...

  • Page 103: Managing The Settings For The Services

    Administrator Site Managing the settings for the services To manage the settings for the Qube 2 services: 1. On the Administrator Site screen, click Control Panel on the left. The Service Settings table appears. See Figure 29. To turn on any of the services listed in the Service Settings table (except Web server and Discussion Group, which are always on), click the check box next to that service.

  • Page 104: Smtp Server

    Chapter 4 SMTP server The Qube 2 can act as a Simple Mail Transfer Protocol (SMTP) server for sending and receiving Internet email. The Qube 2 Administrator can configure several parameters that can affect the performance of the SMTP server. Users created on any virtual site can retrieve their email using the Post Office Protocol 3 (POP3) and the Internet Message Access Protocol 4 (IMAP4).

  • Page 105: Enabling The Email Server

    Administrator Site Enabling the email server To enable the email server, click the Email Server check box. Now you can set the email parameters. To configure the email parameters: IMPORTANT: To receive email, the host name of the Qube 2 (as specified in the Setup Wizard) must be entered into your organization’s DNS server.
  • Page 106 Chapter 4 • Email Retrieval Settings table ISPs often arrange for all messages to an organization to be retrieved from a single mailbox. This mailbox is usually referred to as a “multidrop mailbox” because it contains email messages addressed to more than one person.
  • Page 107 Administrator Site • Receive email addressed to these hosts/domains In this field, enter the IP addresses or domain names of the sites on which you receive email. To receive email, your domain must be specified in this field. For example, if you want to receive email addressed to you at “username@domain.com”, then you must enter “domain.com”...

  • Page 108: Enabling The Email Relaying Feature

    Enabling the email relaying feature To enable email relaying, add the IP addresses (or domain names, or both) of the machines which use your Cobalt Qube 2 as the SMTP server. Note: If you do not want to allow email to be sent through the Qube 2, leave the “Relay email from these hosts/domains”...

  • Page 109: File Transfer Protocol Server

    Administrator Site For example, specifying a network such as 192.168.1 in the “Relay email from these hosts/domains” field trusts all IP addresses from 192.168.1.1 through 192.168.1.254. Note: There is no trailing period on the number of the network block and there are only three octets entered in the field. It is important that you do not include a trailing dot after the part of the IP address that you want to match.
  • Page 110 Chapter 4 To change the FTP settings for your Qube 2: 1. On the Administrator Site screen, click Control Panel on the left. The Service Settings table appears; the FTP server option is checked on by default. 2. Click Parameters next to the FTP Server option. The FTP Settings table appears.

  • Page 111: Windows File Sharing (Smb)

    Administrator Site Windows file sharing (SMB) Windows-based machines use a file-sharing protocol called Server Message Block (SMB) or Windows file sharing. Once Windows file sharing is set up, the Qube 2 appears in your Network Neighborhood as a machine named <hostname> (the name that the Qube 2 Administrator assigned to the Qube 2 in the Setup Wizard or the Control Panel screen).

  • Page 112: Setting Up Windows File Sharing For Windows 95 And

    Chapter 4 The parameters are: • Workgroup or NT Domain Enter a workgroup or NT domain to which you want the Qube 2 to belong. This entry determines how the Qube 2 appears in the Network Neighborhood on a Windows client machine.

  • Page 113: Simple Network Management Protocol (Snmp) Agent

    Administrator Site Simple Network Management Protocol (SNMP) agent You can specify the SNMP communities that can have read-only and read-and-write access to this SNMP agent. The default read-access community is “public.” To specify the SNMP communities: 1. On the Administrator Site screen, click Control Panel on the left. The Service Settings table appears.

  • Page 114: Domain Name System (Dns) Server

    Chapter 4 Domain Name System (DNS) server The Domain Name System (DNS) is a vital and integral part of the Internet. Setting up DNS correctly on your Qube 2 is very important. For this reason, we have created an appendix solely for explaining DNS. See “Domain Name System”...
  • Page 115 Administrator Site 4. Modify one or more of the following fields. • Domain name • Primary DNS Server address • Secondary DNS server address (optional) • Subnet mask • Default gateway • Maximum lease time (seconds)—The network information assigned by the DHCP server expires after a fixed period of time.
  • Page 116 Chapter 4 To assign dynamic or static network information to the DHCP clients: 1. On the Administrator Site screen, click Control Panel on the left. The Service Settings table appears. 2. Click Parameters next to the DHCP Server option. The DHCP Parameters page appears with three options.

  • Page 117: Access Rights

    Administrator Site Access rights Under Access Rights, you can specify the users who: • can add or delete users • can access the Qube 2 home page • can install CGI scripts • have telnet access To configure the access rights: 1.

  • Page 118: User Add And Remove

    Chapter 4 User add and remove With this option, you specify who can add or remove users from the Qube 2. • Open Any individual can register new users and all users can delete themselves. • Restricted Only the Qube 2 Administrator can add or remove users.

  • Page 119: Telnet Access

    Administrator Site Telnet access Warning to the Qube 2 Administrator: You can adversely affect the performance of your Qube 2 if you modify system configuration files. Check your warranty card for details. Warning: Telnet access should only be used by advanced users who want to run shell scripts or use shell commands.

  • Page 120: Ip Firewall

    Chapter 4 IP Firewall A firewall is a set or filtering rules used to allow or deny IP packets access to the Qube 2. The IP Firewall option allows you to specify simple packet-filtering rules, which limit access to your Qube 2. You can choose to deny or allow communication in either direction between your Qube 2 and any or all IP addresses.

  • Page 121: Adding An Ip Filtering Rule

    Administrator Site Adding an IP filtering rule To add an IP filtering rule: 1. On the Administrator Site screen, click Control Panel on the left. Click IP Firewall at the top. If there are any existing IP filtering rules, they appear in the IP Filtering Rule List table. Click Add Rule.
  • Page 122 Chapter 4 • Subnet mask Whether a rule applies to a single IP address or a range of addresses is determined by the value in the subnet mask field. For a single IP address, choose the value 32, which is a 32-bit subnet mask.

  • Page 123: Modifying An Ip Filtering Rule

    Administrator Site Modifying an IP filtering rule To modify an IP filtering rule: 1. On the Administrator Site screen, click Control Panel on the left. Click IP Firewall at the top. The IP Filtering Rule List table appears. In the list, locate the filtering rule that you want to modify. Click the green pencil icon next to that rule.

  • Page 124: Removing An Ip Filtering Rule

    Chapter 4 Removing an IP filtering rule To remove an IP filtering rule: 1. On the Administrator Site screen, click Control Panel on the left. Click IP Firewall at the top. The IP Filtering Rule List table appears. In the list, locate the filtering rule that you want to remove. Click the brown trashcan icon next to that rule.

  • Page 125: Maintenance

    Administrator Site Maintenance The Maintenance section of the Administrator Site screen provides several Web-based utilities that facilitate the day-to-day operations of the Qube 2. The Qube 2 Administrator can use the following utilities: • backup • restore • install software •...

  • Page 126: Manual Backup

    Chapter 4 Manual backup This feature allows administrators to manually back up data stored on the Qube 2. Figure 36 shows the File Backup table. Figure 36 File Backup table...
  • Page 127 Administrator Site To manually back up data stored on the Qube 2: 1. On the Maintenance screen, the Backup utility appears by default. The File Backup table is on the screen. See Figure 36. 2. In “Data to Backup,” select the type of backup: •...

  • Page 128: Scheduled Backup

    Chapter 4 Scheduled backup This feature allows administrators to schedule regular automatic backups. Figure 37 shows the Scheduled File Backup table. Figure 37 Scheduled File Backup table...
  • Page 129 Administrator Site To schedule regular, automatic backups: 1. On the Maintenance screen, the Backup utility appears by default. The File Backup table is on the screen. 2. Click Scheduled Backup. The Scheduled File Backup table appears; see Figure 37. 3. In “Data to Backup,” select the type of Backup, as described in step 2 in “Manual backup”...

  • Page 130: Backup File Locations

    Chapter 4 Backup file locations For a backup by FTP Server: • A location of puts the backup file <username>@ftp.server.com in the initial login directory. • A location of <username>@ftp.server.com/path/to/backups/ puts the backup file in the specified path on the server, using to login.

  • Page 131: Restore

    Administrator Site Restore You must restore data from the same machine on which the data was backed up. The Qube 2 Administrator can restore all the files on the Qube 2. Note: Legato NetWorker® client software is also available on the Qube 2 to support backup and restore needs.
  • Page 132 Chapter 4 Figure 38 shows the File Restore table. Figure 38 File Restore table To restore a backup file: 1. On the Maintenance screen, click Restore at the top. The File Restore table appears. See Figure 38. 2. The Qube 2 saves backed-up data in .qub files. Enter the path and filename of the backup file, or click Browse to select the .qub file archived on your computer which you wish to restore to the server.

  • Page 133: Install Software

    Administrator Site Install software You can add new software to the Qube 2 from the browser. You can install new software obtained either from the Cobalt Networks Web site or from a CD supplied by Cobalt Networks. Figure 39 shows the Install Software table. Figure 39 Install Software table...
  • Page 134 Chapter 4 To install or upgrade software from Cobalt’s Web site: 1. Through your Web browser, go to http://www.cobalt.com/support/ . 2. Download the new software to your desktop computer. 3. On the Administrator Site screen of the Qube 2, click Maintenance on the left.

  • Page 135: Third-Party Software

    Administrator Site Third-party software The Software On The Cobalt Server table lists the various software packages that have been installed on the Qube 2, including the version of the Cobalt OS and any the third-party software. See Figure 39. Installing third-party software For solutions that extend the functionality of the Qube 2, visit the Online Solutions Directory on Cobalt’s Web site at http://www.cobalt.com/solutions/ .

  • Page 136: Shutdown

    Chapter 4 Shutdown Caution: Turning off the power switch before the Qube 2 tells you to do so can result in lost or corrupted data. The Qube 2 can only be shut down from the LCD console located on the back of the unit.

  • Page 137: Memory

    Administrator Site Figure 40 shows a sample of the disk-usage statistics for each user. Figure 40 Disk Usage table Memory The Memory Status chart tells you if memory swapping is high. If you see a red light in this chart, you may want to add more memory to the Qube 2.

  • Page 138: Network

    Chapter 4 Network The Network Usage chart displays the number of network packets successfully sent and received, the total number of errors when sending or receiving network packets, the number of network packets dropped after failure in sending or receiving, and the number of attempts to send several network packets at the same time (the number of collisions) on the Network 1 interface.

  • Page 139: Web

    Administrator Site The Web Server Status chart displays the status of the Web server (green, yellow, red or grey). The Usage Summary chart provides you with a comprehensive analysis of Qube 2 usage. It outlines Web usage, based on number and types of requests.

  • Page 140: Email

    Chapter 4 Email The Email Status chart displays the status of the Post Office Protocol 3 (POP3) server, the Internet Message Access Protocol (IMAP) server and the Simple Mail Transfer Protocol (SMTP) service. File sharing services The File Services chart displays the status of the File Transfer Protocol (FTP) service, the Windows File Sharing (SMB/CIFS) service, and the AppleShare service.

  • Page 141: Public Site

    Administrator Site Public Site To move to the Public Site screen of the Qube 2, click Public Site on the left. For more information, see Chapter 5 “Public Site”. Active Monitor The Qube 2 uses Active Monitor software. Active Monitor is a Cobalt Networks utility that runs on a Qube 2 and updates key system information every 15 minutes.
  • Page 142 Chapter 4 Figure 42 Active Monitor screen Table 1 Colors and status indicators Color Status Green Correct functioning Yellow Advance warning of potential problems that should be investigated by the Qube 2 Administrator (for example, low disk space) Failure Grey Inactive or information is not yet available...

  • Page 143: Public Site

    Chapter 5 Public Site This chapter describes the functions that registered users or the Cobalt Qube 2 Administrator can perform on the Public Site of the Qube 2. As a registered user of the Qube 2, you can: • contact and collaborate with other users through email, mailing lists and discussions •...

  • Page 144: Home

    Chapter 5 Figure 43 shows the Public Site screen. Figure 43 Public Site screen Home When you first access the Qube 2, the home page on the Public Site screen appears. The default home page contains general information about the Qube 2. The buttons on the left provide access to all the functionality of the Qube 2.

  • Page 145: View Users

    Public Site View Users From this site, a user can: • view the list of all registered users on the Qube 2 • visit a user’s personal Web page • send an email to a user Viewing the users To view the users, click View Users. The View User List table appears. For each user, the table displays the full name and the user name.

  • Page 146: Viewing A User's Personal Web Page

    Chapter 5 Viewing a user’s personal Web page To view a user’s personal Web page: 1. Click View Users. The View User List table appears. See Figure 44. Click the green globe icon next to that user. The Web page for the user appears in the browser window.

  • Page 147: View Groups

    Public Site View Groups From this site, a user can: • view the list of all of the groups on the Qube 2 • visit a group’s public Web page (available to all registered users on the Qube 2) • visit a group’s private Web page (available only to the members of the group) •...

  • Page 148: Viewing A Group's Public Web Page

    Chapter 5 Viewing a group’s public Web page To view a group’s public Web page: 1. Click View Groups. The View Group List table appears. See Figure 45. Click the green globe icon next to that group. The public Web page is open to all registered users on the Qube 2.

  • Page 149: Posting A Message To A Discussion Thread

    Public Site Posting a message to a discussion thread For a detailed explanation of discussion threads, see “Working in collaboration through discussions” on page 135. Creating Web content To create Web content on the Qube 2, see “Developing Web pages” on page 38.
  • Page 150 Chapter 5 The following points describe a discussion thread: • If there is a list of messages, they are arranged by the date of the original message, with the most recent posting at the bottom of the list. You can display the messages according to the subject line or the sender’s name.

  • Page 151: Creating A New Discussion Topic

    Public Site Creating a new discussion topic Any user who belongs to a specific group can begin a discussion within that group. To begin a new discussion topic: 1. On the Public Site, click View Groups on the left. The View Group List table appears.

  • Page 152: Joining An Existing Discussion

    Chapter 5 Joining an existing discussion 1. On the Public Site, click View Groups on the left. The View Group List table appears. See Figure 45. Click the green balloon icon next to the group to which you belong. A separate browser window opens for the discussion group. 3.

  • Page 153: Adding A New Message

    Public Site Adding a new message To add a new message: 1. Click New Message at the top. The browser window displays the Discussion Group Message window. Fill in the fields for a new message. • Subject line (optional) • Attachment (optional) (see “Adding an attachment to a message”...

  • Page 154: Replying To A Message

    Chapter 5 Replying to a message The reply appears indented in the list, under the original message to which it is replying, in a “nested” arrangement. The content of the original message is indented within the reply message. To reply to a message: 1.

  • Page 155: Search

    Public Site Search The search function allows a user to search rapidly for a string of text in all text and HTML files on the Qube 2, including the Web pages. The search index is updated nightly. The results are presented as a list that includes the file name and a one-line description of the files that meet the criteria.

  • Page 156: Performing A Search

    Chapter 5 Performing a search To search for a string of text: 1. Click Search on the left. The Search Tool table appears. See Figure 48. 2. In the Find Text field, enter the string for which you want to search. The string must contain at least three characters;...
  • Page 157 Public Site Figure 49 shows the results of a sample search on the word “cobalt”. Figure 49 Results of a sample search If there is no match for your search, a message appears stating that no documents match your query. If there is a match for your search, the results appear in a numbered list and show the following information for each match (see Figure 49): •...

  • Page 158: Interpreting Search Results

    Chapter 5 Interpreting search results The search results are presented as a list of files that meet the search criteria. If the target file is a standard text file, then the file name, path name and the line containing the first occurrence of the search text are displayed. To see the contents of the file in a standard browser window, click the file name.

  • Page 159: Modify User

    Public Site Figure 50 Personal Profile screen Modify user The Modify User section allows you to change your full name and password. To change these settings: 1. On the Personal Profile screen, click Modify User at the top. The Modify User table appears. See Figure 50. 2.

  • Page 160: Forward Email To

    Chapter 5 Forward email to You can have your Qube 2 email forwarded to another email address. Enter the destination address in the “Forward Email To” field in the Email Settings table. Automatic vacation reply You can create a vacation-reply message that is automatically sent to each person who sends you email.

  • Page 161: Backup

    Public Site Backup You can back up your files located in your home directory. Caution: A backup captures data only (for example, email messages stored on the server or Web files). It does NOT back up the settings for Web sites or users. Caution: Once a file transfer begins, do NOT interrupt or cancel the backup process.

  • Page 162: Restore

    Chapter 5 Restore You can restore to your home directory a .qub backup file that you created previously. This restores all files and subdirectories. Caution: The system restores data only (for example, email messages stored on the server or Web files). It does NOT restore Web sites or site users to a Qube 2.

  • Page 163: Page Builder

    Public Site Page Builder The Qube 2 includes Page Builder, an interactive web development tool that allows you to create Web pages without having to learn how to write HTML scripts. Accessing the Page Builder tool There are two ways to access the Page Builder tool. The first method is as follows.

  • Page 164: Page Builder Window

    Chapter 5 The second method is as follows. 1. On the Public Site screen, click View Users. The View User List table appears. 2. Click the green globe icon next to the user’s name. A default home page appears with the title “Welcome to <user>’s Home Page”.

  • Page 165: Programs

    Public Site Once you are in the Page Builder tool, you can access the online help window by clicking Instructions in the Control Panel column. Figure 51 shows the Page Builder window for a user’s default home page. Figure 51 Page Builder window Programs The Qube 2 is shipped with the InfoPlace Document Organizer...
  • Page 166 Chapter 5 The InfoPlace Document Organizer maintains a database of information about the documents it stores on the Qube 2. This database is called an Infobase. Each Qube 2 group can have several Infobases; each Infobase can be accessed and used only by the group members. To access the InfoPlace Document Organizer: 1.

  • Page 167: Using The Infoplace Document Organizer

    Public Site Using the Infoplace Document Organizer The Qube 2 Administrator can create an Infobase for any group. Contact your Qube 2 Administrator. For more information, see “Creating a new InfoBase” on page 53. Note: When you logging in to the InfoPlace Document Organizer, you can select the Infobase labeled “Demo”...

  • Page 168: Finding Specific Documents

    Chapter 5 Finding specific documents You can find documents based on specific criteria. For example, you can ask the InfoPlace Document Organizer to find all of the documents authored by “Bill Lumbergh” and labeled “Competitive Analysis.” The InfoPlace Document Organizer finds all of the documents within its Infobase that meet both of the criteria and presents the results to you as a list of URLs.

  • Page 169: A Using The Lcd Console

    Appendix A Using the LCD console During startup, the LCD screen on the back of the Cobalt Qube 2 displays status information about the boot process itself. When setting up the Qube 2, you use the LCD console to enter network configuration information for the Qube 2.

  • Page 170: Changing Network Configuration

    Appendix A Changing network configuration To reset the IP address or change the network configuration of the Primary Network Interface: 1. On the LCD console, hold down the button for Select approximately 2 seconds. The LCD screen displays: SELECT: SETUP NETWORK 2.

  • Page 171: Rebooting

    Using the LCD console Rebooting To reboot the Qube 2 through the LCD console: 1. On the LCD console, hold down the button for Select approximately 2 seconds. The LCD screen displays: SELECT: SETUP NETWORK 2. Press the button until REBOOT appears in the LCD Select screen: SELECT:...

  • Page 172: Powering Down

    Appendix A Powering down Caution: To prevent the potential loss of data, it is important to follow the proper power-down procedure before turning off the Qube 2. To power down the Qube 2: 1. On the LCD console, press and hold down the button for Select approximately 2 seconds.

  • Page 173: Resetting Network Configuration

    Using the LCD console Resetting network configuration The “Reset Network” function resets the host name, IP address, netmask, gateway and DNS information for the Primary and Secondary Network Interfaces to that of a new, unconfigured Qube 2. This function is useful if you are moving the Qube 2 to a new network. To reset the network state of the Qube 2: 1.

  • Page 174: Resetting Ip Firewall

    Appendix A Resetting IP Firewall The “Reset Filters” function turns off the IP firewall filtering rules. To reset the filtering rules: 1. On the LCD console, hold down the button for Select approximately 2 seconds. The LCD screen displays: SELECT: SETUP NETWORK 2.

  • Page 175: B Product Specifications

    Appendix B Product Specifications Technical Data for the Qube 2 Hardware The Qube 2 has the following hardware components. See http://www.cobalt.com for the most up-to-date information on the hardware specifications. • 64-bit superscalar RISC controller • 16-MB, 32-MB or 64-MB DRAM, packaged in Single In-Line Memory Modules (SIMMs) (60 ns, 72 pin, EDO, 3.3 v) •...

  • Page 176: System Management

    Appendix B • Server Message Block (SMB)/CIFS • AppleShare (and AppleShare over IP) • The Glimpse search engine • Domain Name System (DNS) server: Berkeley Internet Name Domain (BIND) • Legato Networker client • InfoPlace Document Organizer System management • Browser-based Setup Wizard •...

  • Page 177: Regulatory Approvals

    Product Specifications Regulatory approvals • CISPR 22B • VCCI-B • • C-UL • • Upgrading your Qube 2 Before you purchase a component to add to the Qube 2, ensure that the component fits into the allocated space: • The SIMM modules must be less than 0.4 inches (10.1 mm) thick. •...

  • Page 178: Opening The Qube 2

    Appendix B Opening the Qube 2 Warning: You MUST power down the Qube 2 before opening the unit. 1. Power down the Qube 2. See “Powering down” on page 158. 2. Unplug the Qube 2. 3. Remove the power cord from the rear panel of the Qube 2. The power connector is located in the bottom right corner.

  • Page 179: Adding A Memory Module

    Product Specifications To add a memory module, see “Adding a memory module” on page 165. To add a PCI expansion card, see “Adding a PCI expansion card” on page 166. IMPORTANT: If you want to add a memory module and a PCI expansion card to the Qube 2 at the same time, add the memory module first.

  • Page 180: Adding A Pci Expansion Card

    Appendix B 7. If you have mismatched sizes of memory modules, you must install the larger module in Slot 0. See Figure 54. If the memory module you are adding is larger than the module currently installed, remove the current module from slot 0 and install the larger memory module.

  • Page 181: Closing The Qube 2

    Product Specifications Closing the Qube 2 To close up the Qube 2, perform the steps for opening the Qube 2 in reverse order. 1. Slide the sheet metal cover over the metal frame. The edge with the wider lip faces forward (the side of with the light bar). 2.

  • Page 182: I/O Board

    Appendix B I/O board Figure 53 shows the layout of the input/output (I/O) board in the Qube 2. The I/O board is installed on the bottom of the Qube 2. Figure 53 Layout of the input/output board Slot for Slot for PCI card CPU card IDE donnector...

  • Page 183: Cpu Card

    Product Specifications CPU card Figure 54 shows the layout of the central processing unit (CPU) card in the Qube 2. The CPU card fits into a slot on the I/O board in one direction only (see Figure 53). Figure 54 Layout of the CPU board Connector for Memory...
  • Page 184 Appendix B...

  • Page 185: C Advanced Information

    When the Qube 2 Administrator changes the “index.html” file to create a new home page, the default home page is replaced. Any user can continue to access the Cobalt Qube 2 home page by accessing the URL http://<hostname>/cobalt/ . Telnet access...

  • Page 186: Cgi Scripts

    Appendix C The Access Rights section under the Control Panel provides three options for controlling telnet access: • You can turn telnet access off completely. This is the most secure and safest option for the Qube 2. • You can limit telnet access to the Unix “root” user. •...

  • Page 187: D Domain Name System

    Appendix D Domain Name System Basic DNS The Internet uses a distributed naming system called the Domain Naming System (DNS). DNS allows us to refer to computers by host names as well as by Internet Protocol (IP) addresses. IP addresses are hard to remember and are inconvenient to use. DNS allows us to use host names and domain names which can resolved to IP addresses.

  • Page 188: Enabling The Dns Server Feature

    Appendix D Enabling the DNS server feature IMPORTANT: Always click Save Changes to DNS Server after modifying DNS records. If you do not, the changes will not take effect. To enable the DNS server on the Qube 2: 1. On the Administrator screen, click Control Panel. The Service Settings table appears.

  • Page 189: Specifying A Reverse Lookup (Ptr) Record

    Domain Name System 8. Click Update List. 9. Click Save Changes to DNS Server. Specifying a reverse lookup (PTR) record A DNS server can also resolve a computer host name to an IP address, which is known as reverse lookup. The network mask, or subnet size, is specified by an integer from 8 to 32.

  • Page 190: Specifying An Alias (Cname) Record

    Appendix D Specifying an alias (CNAME) record This feature allows you to alias one host name to another. The target host name does not need to be a member of the local domain. For example, you can create an alias record from “news.domain.com” to “uucp.isp.net”.

  • Page 191: Configuring A Secondary Dns Server

    Domain Name System Configuring a secondary DNS server You can configure a secondary DNS server to provide redundant DNS service to your computers. If the primary DNS server is turned off, a computer can use the secondary DNS server with no loss of performance.

  • Page 192: Advanced Dns

    Appendix D Advanced DNS Network Mask Notation Conversion Use Table 2 to convert between dot-quad and bit-count subnet mask and network size notations. Table 2 Network Mask Notation Conversion. Dot-Quad Bit count 255.0.0.0 255.128.0.0 255.192.0.0 255.224.0.0 255.240.0.0 255.248.0.0 255.252.0.0 255.254.0.0 255.255.0.0 255.255.128.0 255.255.192.0...

  • Page 193: Quick Start Guide For Domain Name Service (Dns)

    Domain Name System Quick Start Guide for Domain Name Service (DNS) This quick start guide assumes that you have already registered your domain with InterNIC or some other registration service. If you have not, refer to the FAQ section on Cobalt’s Web site (http:// www.cobalt.com/support, under the Knowledge Base link) for information on registering your domain name.
  • Page 194 Appendix D These records allow anyone on the Internet to type either “mydomain.com” or “www.mydomain.com” in order to access your Web site. To set up these records, go to the Parameters section of the DNS server in the Cobalt user interface (UI). 1.
  • Page 195 Domain Name System 5. Create an Address (A) Record for mydomain.com. • Click Add Forward Lookup. • Leave the Host Name field blank. • In the Domain Name field, type mydomain.com. • In the IP Address field, type 192.168.10.10. • Ensure the check box for Automatic Reverse Address Record Generation is checked.
  • Page 196 Appendix D 6. Create an Address (A) Record for “www.mydomain.com”. • Click Add Forward Lookup. • In the Host Name field, type www. • In the Domain Name field, type mydomain.com. • In the IP Address field, type 192.168.10.10. • Remove the check from the check box for Automatic Reverse Address Record Generation.
  • Page 197 Domain Name System 7. To receive mail for “mydomain.com”, create a Mail Server (MX) Record. An MX record is similar to a A record but points to a name rather than an IP address. It is critical that the MX record point to a name which has a corresponding A record with the proper IP address.

  • Page 198: Brief History Of The Domain Name System (Dns)

    Appendix D To edit another domain, select another domain from the Select Domain or Network... pull-down menu. You can select any domain that you have configured for the DNS server. To add a new domain, follow the same steps as described above. In the Domain Name field, replace the default domain name with the new domain name that you want to create.

  • Page 199: What Is A Dns Record

    Domain Name System DNS is a distributed database that allows local administration of the segments on the overall database. Data in each segment of the database are available across the entire network through a client-server scheme consisting of name servers and resolvers. What is a DNS record? People are much more comfortable dealing with names rather than strings of numbers.
  • Page 200 Appendix D To determine which primary name server contains your domain name: 1. The local name server (the DNS resolver/browser machine) contacts the root domain name server maintained by the several Internet root server authorities. 2. The root domain name server returns the IP address of the primary name server responsible for the requested domain name.

  • Page 201: E Licenses

    Appendix E Licenses THE BSD COPYRIGHT Copyright ©1991, 1992, 1993, 1994 The Regents of the University of California. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
  • Page 202 Appendix E GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 59 Temple Place - Suite 330, Boston, MA 02111-1307, USA TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License.
  • Page 203 Licenses These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the Program, and can be reasonably considered independent and separate works in themselves, then this License, and its terms, do not apply to those sections when you distribute them as separate works.
  • Page 204 Appendix E You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or modifying the Program or works based on it.
  • Page 205 Licenses 10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are different, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this.
  • Page 206 Appendix E...

  • Page 207: F Glossary

    Appendix F Glossary 10/100 BaseTX An Ethernet connection over twisted-pair cables with a throughput of 10 Mb/s or 100 Mb/s. 10BaseT A 10-Mb/s baseband Ethernet specification using two pairs of twisted-pair cabling (Category 3, 4, or 5): one pair for transmitting data and the other for receiving data.
  • Page 208 Appendix F see Common gateway interface (CGI) Common gateway interface (CGI) A set of rules that describe how a Web server communicates with another application running on the same computer and how the application (called a CGI program) communicates with the Web server. Any application can be a CGI program if it handles input and output according to the CGI standard.
  • Page 209 Glossary Domain Name System (DNS) The Internet service responsible for translating a human-readable host name such as cobalt.com into a numeric IP address (111.123.45.67) for TCP/IP communications. Dynamic Host Configuration Protocol (DHCP) A protocol that provides a mechanism for allocating IP addresses dynamically so that an address can be reused when a host no longer needs it.
  • Page 210 Appendix F HTTP see HyperText Transfer Protocol (HTTP) HyperText Markup Language (HTML) A set of “markup” symbols or tags inserted in a text file intended for display on a World Wide Web browser. The markup tags tell the Web browser how to display a Web page’s content, words, and images. HTML is a subset of Standardized Generalized Markup Language (SGML).
  • Page 211 Glossary Internet domain An Internet domain is a host naming convention used to ensure that no two individual hosts on the global Internet have the same host name. An Internet domain should not be confused with an NT Domain. Internet Message Access Protocol (IMAP) Internet Message Access Protocol is a standard protocol for accessing email from your local server.
  • Page 212 Appendix F IP address A 32-bit address assigned to hosts using Transmission Control Protocol/ Internet Protocol (TCP/IP). An IP address belongs to one of five classes (A, B, C, D or E) and is written as four octets separated by periods (for example, 192.168.10.10), also called the dotted decimal format.
  • Page 213 Glossary Media access control (MAC) address A standardized data-link-layer address that is required for every port or device that connects to a LAN. Other devices in the network use these addresses to locate specific ports in the network, and to create and update routing tables and data structures.
  • Page 214 Appendix F Packet The unit of data that is routed between an origin and a destination on the Internet or any other packet-switched network. The packet includes a header containing control information and (usually) user data. Packets are most often used to refer to network layer units of data. see Peripheral Component Interface (PCI) Peripheral Component Interconnect (PCI) Peripheral Component Interconnect (PCI) is an interconnection system...
  • Page 215 Glossary POP and IMAP deal with receiving email from your local server; Simple Mail Transfer Protocol (SMTP) is a protocol for transferring email between points on the Internet. You send email with SMTP and a mail handler receives it on your recipient’s behalf. The mail is then read using POP or IMAP.
  • Page 216 Appendix F Simple Mail Transfer Protocol (SMTP) The TCP/IP standard protocol for transferring electronic mail messages between points on the Internet. SMTP specifies how two mail systems interact and the format of control messages they exchange to transfer mail. SMTP is a protocol for transferring email between points on the Internet;...
  • Page 217 Glossary Subnet mask A number that, in conjunction with an IP address, defines the set of IP addresses that are considered “local.” For example, if your IP address is 192.168.25.77 and your subnet mask is 255.255.255.0, then addresses between 192.168.25.1 and 192.168.25.255 are considered local. Also known as netmask.
  • Page 218 Appendix F...

Table of Contents
