4.2 2 field
Control
LED line in the frame – can be switched and dimmed only
circumferentially
LED line / LED spotlights in the front gutter – can be switched
and dimmed only together (1 field and 2 fields)
Infrared heater - individually heat dimmable and switchable
Variant 1:
LED line in frame
Variant 2:
LED line in the
front gutters
Variant 3:
LED line in the frame
and LED line in the
front gutters
Variant 4:
LED spotlights at the
front gutters
1) If the central post distance in direction of awning extension is
smaller than 400 cm, only 1 infrared heater is recommended for 1
field and for 2 fields 2 infrared heaters.
markilux markant
Variant 5:
LED line in the frame
and LED spotlights at the
front gutters
Variant 6 1):
2 infra-red heaters
at the coupling profile
can be combined with
variants 1, 2, 3, 4, 5
Variant 7 1):
4 infrared heaters
at the coupling profile
can be combined with
variants 1, 2, 3, 4, 5
