  • Page 1 KM9800E User manual Electric built-in oven...
  • Page 2 Dear Customer Thank you for choosing one of our high-quality products. With this appliance you will experience the perfect combination of functional design and cutting edge technology. Convince yourself that our appliances are engineered to deliver the best performance and control - indeed we are setting the highest standards of excellence.

  • Page 3: Table Of Contents

    Contents Contents Operating instructions Safety information Electrical safety Children's safety Safety during use Microwave How to avoid damage to the appliance Do not use the appliance Description of product General view Control panel Oven layout Accessories Oven Before using for the first time Setting and changing the time Cleaning for the first time Getting to know the appliance...
  • Page 4 Contents Other functions Child safety device Button Beep Automatic switch-off Uses, Tables and Tips Single economy grill Grilling Table Microwave Information about operation Suitable cookware and materials Microwave Cooking Table Combi-Function Table Tips for the microwave Test dishes in accordance with IEC 60705 Programmes Cleaning and care The outside of the appliance...

  • Page 5: Operating Instructions

    Safety information Customer Care For Customer Service in The Republic of Ireland please contact us at the address below: European Guarantee www.electrolux.com Subject to change without notice Operating instructions Safety information Important safety instructions! Read carefully and keep for future use! Electrical safety •...

  • Page 6: Safety During Use

    Safety information • This appliance is fitted with a child safety device. Safety during use • This appliance should be used only for normal domestic cooking, roasting and baking of food. • Be careful if connecting electrical appliances to sockets near to this appliance. Electrical leads must not be caught under the hot oven door.
  • Page 7 Safety information • When heating liquids always put a cof- fee spoon or a glass rod in the container to avoid boiling delay. With boiling de- lay the boiling temperature is reached without the typical steam bubbles ris- ing. If the container is shaken even slightly the liquid can suddenly boil over or spray violently.

  • Page 8: How To Avoid Damage To The Appliance

    Safety information How to avoid damage to the appliance • Do not line the oven with aluminium foil and do not place a baking tray or saucepan etc. on the floor, as otherwise the oven enamel will be damaged by the heat build-up.

  • Page 9: Do Not Use The Appliance

    Safety information Do not use the appliance ... for cooking eggs in their shells (with fried eggs, pierce the yolks first) and snails, as oth- erwise these burst. Cooking oil (fondue, deep frying) and drinks with high alcohol content: Spontaneous ig- nition! Risk of explosion! ...

  • Page 10: Description Of Product

    Description of product Description of product General view Control panel Door handle Full glass door...

  • Page 11: Control Panel

    Description of product Control panel Oven displays Oven functions buttons Oven layout Grill element...

  • Page 12: Accessories Oven

    Before using for the first time Microwave generator Light in the oven Glass base, removable Side rails, removable Oven levels Accessories Oven Oven shelf For cookware, cake tins, roasts and grilling food. Crunch plate Before using for the first time Setting and changing the time The oven only operates when the time has been set.

  • Page 13: Cleaning For The First Time

    Before using for the first time 2. Using the button, set the current time. After approx. 5 seconds, the flashing stops and the clock displays the time set. The appliance is now ready to use. The time can only be modified, if the child safety device is deactivated, none of the clock functions Countdown , Cook Time or End...

  • Page 14: Getting To Know The Appliance

    Operating the oven Getting to know the appliance The appliance can be operated in test mode to test or demonstrate all operating steps. The oven does not heat up. Test mode Switching on 1. Switch off the appliance using the Stop button.
  • Page 15 Operating the oven Temperature/Time/Microwave Power Weight display Time functions Length of operation Thermometer symbol Baking/Roasting Programmes Oven functions The control panel Start button Microwave button button +/- Stop button / Restore settings Clock functions Baking/Roasting Programmes Grill Function button General instructions •...
  • Page 16 Operating the oven • If the oven door is opened during operation, the function stops. After closing the door continue with the Start button . If the Start button is not started within 30 seconds, the appliance switches itself off. •...

  • Page 17: Oven Functions

    Operating the oven Thermometer symbol • The slowly rising thermometer symbol indicates how far the oven has heated • When the selected temperature is reached, a signal sounds. Switching the oven off To switch the oven off, press the Stop but- ton repeatedly until only the time and any residual heat is displayed.
  • Page 18 Operating the oven 2. By repeatedly pressing the Micro- wave button, set the desired mi- crowave power. – The settings options are in 100 Watt steps from 1,000 Watt to 100 Watt. – Repeatedly pressing the Micro- wave button makes the power display begin again at 1,000 Watt.

  • Page 19: Combi Function

    Operating the oven – While the time counts down, using the clock functions but- tons the cooking time can be increased or reduced. When the time has elapsed, a signal sounds for 2 minutes. The microwave switches itself off. The symbol for Cook Time flashes and the time display appears.

  • Page 20: Microwave Quick Start

    Operating the oven – The cooking times can be set as follows: – from 0 to 2 min. in 5 second steps, – from 2 to 5 min. in 10 second steps, – from 5 to 10 min. in 20 second steps, –...

  • Page 21: Information On Power Settings

    Operating the oven 2. Press the Start button repeatedly until the desired period of operation appears. The appliance switches itself on at maximum microwave power. – Each press of the button adds 30 seconds to the cooking time dis- played. Maximum 7 min. at maxi- mum microwave power.

  • Page 22: Inserting The Oven Shelf

    Operating the oven Microwave Power Suitable for 600 Watt • Defrosting and heating frozen meals • Heating one-plate meals 500 Watt • Simmering stews • Cooking egg dishes 400 Watt • Continuing to cook meals • Cooking delicate foodstuffs 300 Watt •...

  • Page 23: Additional Functions

    Operating the oven Additional functions Microwave Programmes For this function, use the pre-set programmes (see section "Uses, Tables and Tips: Programmes). Selecting a programme 1. Switch off the appliance using the Stop button, if necessary. 2. By repeatedly pressing the Baking/ Roasting Programmes button, se- lect the desired programme (P 1 to...

  • Page 24: Memory Function

    Operating the oven With some programmes, after the time has elapsed a Keep Warm function is started. A signal sounds and "HH" lights up in the dis- play. After the Keep Warm function has ended, a signal sounds for 2 minutes. The microwave switches itself off.

  • Page 25: Clock Functions

    Operating the oven Clock functions Clock functions Clock displays Time Cook Time/End Time/Operating Time Clock functions Selector buttons Countdown To set a countdown. When it has counted down, a signal sounds. This function has no effect on the operation of the microwave and oven. Microwave Cook Time For setting how long the microwave is to operate.

  • Page 26: Countdown

    Operating the oven General instructions • After a clock function has been selected, the corresponding symbol flashes for about 5 seconds. During this period, the desired times can be set or modified using the button. • When the desired time has been set, the symbol continues to flash for approx. 5 seconds.

  • Page 27: Microwave Cook Time Min

    Operating the oven After approx. 5 seconds the display shows the time remaining. The symbol for Countdown lights up. When the time has elapsed, a signal sounds for 2 minutes. "0.00" lights up and the symbol for Countdown flashes. To turn off the signal: Press any button. Microwave Cook Time min.

  • Page 28: Cook Time

    Operating the oven 3. When the Start button is pressed, the time set begins to count down. The symbol for Cook Time lights up. By repeatedly pressing the clock func- tions button the current time can be found out. While the time counts down, using the buttons the cooking time can be increased or...

  • Page 29: End Time

    Operating the oven 4. When the Start button is pressed, the time set begins to count down. The symbol for Cook Time lights up. By repeatedly pressing the clock func- tions button the current time can be found out. When the time has elapsed, a signal sounds for 2 minutes.

  • Page 30: Cook Time And End Time Combined

    Operating the oven The symbols for End Time and Cook Time light up. The oven switches itself on automatically. By repeatedly pressing the clock functions button the current time can be found out. When the time has elapsed, a signal sounds for 2 minutes.
  • Page 31 Operating the oven 3. Using the End Time function , set the time at which the dish is to be ready, e. g. at 14:05. The symbols for Cook Time and End Time light up. The oven switches itself on automatically at the time calculated, e.

  • Page 32: Other Functions

    Operating the oven Other functions Child safety device As soon as the child safety device is activated, it is no longer possible to operate the oven. Switching on the child safety device 1. Switch off the appliance using the Stop button, if necessary. An oven function must not be selected.

  • Page 33: Automatic Switch-Off

    Uses, Tables and Tips 1. Switch off the appliance using the Stop button, if necessary. 2. Press and hold the buttons at the same time, until a signal sounds (approx. 2 seconds). The button beep is now switched off. Switching on button beep Press and hold the buttons at the same time, until a signal sounds (ap-...

  • Page 34: Grilling Table

    Uses, Tables and Tips • Grilling is particularly suitable for flat pieces of meat or fish. Grilling Table Food to be grilled Oven level Cooking times 1st side 2nd side Rissoles 12-15 min. 9-12 min. Pork fillet 10-12 min. 6-10 min. Sausages 12-16 min.

  • Page 35: Suitable Cookware And Materials

    Uses, Tables and Tips Defrosting meat, poultry, fish • Place the frozen, unwrapped food on a small upturned plate with a container underneath or on a defrosting rack or plastic sieve so that the defrosting liquid can run off. • Turn the food after half the defrosting time. If possible, divide and then remove pieces that have started to defrost.
  • Page 36 Uses, Tables and Tips Cookware/Material Microwave Single economy Defrosting Heating Cooking grill oven Cardboard, paper Clingfilm Roasting film with microwave safe closure 3 Roasting dishes made of metal, e. g. enamel, cast iron Baking tins, black lacquer or silicon-coated Baking tray Browning cookware, e.

  • Page 37: Microwave Cooking Table

    Uses, Tables and Tips Microwave Cooking Table Defrosting Dish Microwave Size (g) Power Cook Standing Things to note (Watts) Time time min. (min.). Meat Whole cuts of meat 10-12 10-15 Turn halfway through Steak 5-10 Turn halfway through; remove defrosted parts Mixed minced meat 10-15...
  • Page 38 Uses, Tables and Tips Defrosting Dish Microwave Size (g) Power Cook Standing Things to note (Watts) Time time min. (min.). Quark 10-15 25-30 Remove aluminium parts, turn halfway through Butter 15-20 Remove aluminium parts, turn halfway through Cheese 30-60 Remove aluminium parts, turn halfway through Cream...
  • Page 39 Uses, Tables and Tips Defrosting Dish Microwave Size (g) Power Cook Standing Things to note (Watts) Time time min. (min.). Melting Chocolate / Chocolate Stir halfway through coating Butter Stir halfway through Heating Baby food in jars Stir halfway through; check temperature! Baby milk (bottle, 180 1000...

  • Page 40: Combi-Function Table

    Uses, Tables and Tips Cooking Dish Microwave Size (g) Power Cook Standing Things to note (Watts) Time time min. min. Fish fillets Cook covered, turn container several times during cooking Vegetables, short cook- 12-16 Add approx. 50 ml wa- ter, cook covered, stir ing time, fresh halfway through Vegetables, short cook-...
  • Page 41 Uses, Tables and Tips Dish Baking/ Oven Temp. Micro- Oven Time Things to note roasting funct. in °C wave level dishes Watt min. Potato gratin Ovenproof 10 min. stand- 1000 g glassware on ing time oven shelf Neck of roast Ovenproof Turn once half- pork 1100 g...

  • Page 42: Tips For The Microwave

    Uses, Tables and Tips The cooking times and temperatures are guidelines only and depend upon the type and qualities of the foodstuffs. Tips for the microwave Result Remedy You cannot find details for the amount of Look for a similar food. Increase or shorten the length food prepared.

  • Page 43: Programmes

    Uses, Tables and Tips Programmes The appliance has 10 programmed functions, which can be selected one after the other using the Baking/Roasting Programmes button. For settings, see section Additional Functions: Microwave Programmes. Pro- Func- Recipe Weight Time ac- Keep gramme tion cording Warm...

  • Page 44: Cleaning And Care

    Cleaning and care Pro- Func- Recipe Weight Time ac- Keep gramme tion cording Warm Preset- min. max. to preset- function ting ting "HH" P 10 Fish 1,000 g 100 g 1,000 g 21 min. 40 sec. Cleaning and care WARNING! For cleaning, the appliance must be switched off and cooled down.

  • Page 45: Accessories

    Cleaning and care Remove stubborn dirt with special oven cleaners. When using oven sprays, please follow the manufacturer's instructions exactly! Accessories Wash up all insertable parts (oven shelf, baking tray, side rails, etc.) after each use and dry well. For easier cleaning, leave to soak for a while. Side rails The left and right-hand side rails can be removed from the oven, so that the side walls of the oven can be cleaned.

  • Page 46: Replacing The Side Rails

    Cleaning and care Replacing the side rails To insert rails, re-insert them into the mounts and lower them. Oven lighting WARNING! Risk of electric shock! Before replacing the oven light bulb: • Switching the oven off! • Take the fuses out of the fuse box or switch off. To protect the oven light bulb and the glass cover, lay a cloth on the floor of the oven.

  • Page 47: If Something Is Wrong

    If something is wrong… If something is wrong… Problem Possible cause Remedy The oven is not heating The oven has not been switched on Switch the oven on The clock has not been set Set the current time on the clock The required settings have not Check the settings been made...

  • Page 48: Electrical Connection

    Electrical Connection Electrical Connection The oven is designed to be connected to 230-240V~(50Hz) electricity supply. The oven has an easily accessible terminal block which is marked as follows: Letter L - Live terminal Letter N - Neutral terminal - Earth terminal CAUTION! This oven must be earthed! The cable used to connect the oven to the electrical supply must comply to the...

  • Page 49: Safety Information For The Installation Engineer

    To prevent risk of injury, damaged connection cables must be replaced by our Customer Care Department or a designated specialist Safety information for the installation engineer • The electrical installation is provided with a device to enable the appliance to be cut off from the mains with with a minimum 3 mm all-pole contact separation.
  • Page 50 380-383 min. min.
  • Page 51 380-383 min. 560 min.
  • Page 53 2x3,5x25...

  • Page 54: Disposal

    Disposal Disposal The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.

  • Page 55: Guarantee/Customer Service

    Guarantee/Customer Service So that you have the necessary reference numbers from your appliance at hand, we recommend that you write them in here: Model description: ........PNC: ........S-No: ........Guarantee/Customer Service GREAT BRITAIN & IRELAND Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that:...

  • Page 56: Service And Spare Parts

    Customer Care Department, Electrolux Major Appliances Addington Way, Luton Bedfordshire, LU4 9QQ Tel: Electrolux 08705 950 950 AEG-Electrolux 08705 350 350 Zanussi-Electrolux 08705 727 727 1) Calls may be recorded for training purposes...
  • Page 57 European Guarantee For Customer Service in The Republic of Ireland please contact us at the address below: Electrolux Group (Irl) Ltd Long Mile Road, Dublin 12, Republic of Ireland Tel: +353 (0)1 4090751 Email: service.eid@electrolux.ie European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law.
  • Page 58 www.electrolux.com www.electrolux.com Albania +35 5 4 261 450 Rr. Pjeter Bogdani Nr. 7 Tirane Belgique/België/Belgien +32 2 363 04 44 Bergensesteenweg 719, 1502 Lembeek Česká republika +420 2 61 12 61 12 Budějovická 3, Praha 4, 140 21 Danmark +45 70 11 74 00 Sjællandsgade 2, 7000 Frederi- Deutschland +49 180 32 26 622...
  • Page 59 Norge +47 81 5 30 222 Risløkkvn. 2 , 0508 Oslo Österreich +43 18 66 400 Herziggasse 9, 1230 Wien Polska +48 22 43 47 300 ul. Kolejowa 5/7, Warsza‐ Portugal +35 12 14 40 39 39 Quinta da Fonte - Edificio Gon- çalves Zarco - Q 35 -2774-518 Paço de Arcos Romania...
  • Page 60 www.electrolux.com...
