SPRAY EQUIPMENT
INSTRUCTIONS AND PARTS LIST
SERIES TEL 16-2K
(2:1)
MIXING PUMP
Instructions and Parts List
INDEX
........................ 1
....................................... 1
Pressure relief procedure ............... 2
................... 2
...................................... 3
....................... 5
................ 12
C/. Anboto, 17 Poligono ANSOLETA Phone: (34) 945-132744 Fax. (34) 945-134756
MBP S.L.
01006 VITORIA (Alava) / SPAIN
P.O. BOX 3144

Advertisement

loading
Need help?

Need help?

Do you have a question about the TEL 16-2K Series and is the answer not in the manual?

Questions and answers

Summary of Contents for mbp TEL 16-2K Series

  • Page 1: Table Of Contents

    Pressure relief procedure ....2 Operating instructions ....2 Cleaning ........3 Parts drawing & list ....... 5 Troubleshooting guide ....12 C/. Anboto, 17 Poligono ANSOLETA Phone: (34) 945-132744 Fax. (34) 945-134756 MBP S.L. 01006 VITORIA (Alava) / SPAIN P.O. BOX 3144...
  • Page 2: Typical Installation

    TYPICAL INSTALLATION BASE BASE DISOLVENTE DE LIMPIEZA RESINA CATALIZADOR WARNING ATTENTION!! Read and understand all instructions carefully before operating equipment. INJECTION HAZARD This equipment generates very high fluid pressure. Spray from the gun, leaks or ruptured components can inject fluid through your skin and into your body and cause extremely serious bodily injury. The spray gun should never be handled carelessly, nor spray directed toward any part of the body.
  • Page 3: Pressure Relief Procedure

    FIRE HAZARD Static electricity is created by the high velocity flow of fluid through the pump and hose. If every part of spray equipment is not properly grounded, sparking may occur, and the system may become hazardous. Check the entire system for positive grounding. GROUNDING Before starting to work the pump must be connected to ground: The pump must be connected to ground with a ground wire which is supplied with the...
  • Page 4: Cleaning

    • Put the suction pipes into the respective containers: ‘’C’’ to base product (varnish) ‘’B’’ to catalyst • Open the air inlet valve (fig.1) and turn on the air regulator until the pump begins to cycle. Allow the pump to cycle slowly until all air is purged from the fluid lines. The lines are purged when the fluids emitted from the drain valves ‘’B’’...
  • Page 5 VALVE ‘’A’’ AIR REGULATOR ‘’X’’ (fig.2) ( For working / varnishing ) DOWN ( For reclying ) (fig. 3)
  • Page 6: Parts Drawing & List

    AIR MOTOR 16A.200.00 Nº REF. DESCRIPCION A.110.02 C.JT0.01 JOINT A.210.01 CYLINDER A.120.04 A.220.07 SUPPORT A.120.08 YOKE A.221.00 C.TJ0.02 SCREW A.240.02 CLIP A.240.01 PISTON A.122.00 STEM C.JT0.05 JOINT A.220.11 C.JT0.07 JOINT CB2.015 SLEEVE C.JT0.06 JOINT A.130.02 PLATE A.250.01 BASE C.TA0.01 SCREW C.TC0.01 SCREW A.120.01...
  • Page 7 (fig. 5) DISPLACEMENT PUMP ASSEMBLAGE FOR TEL 16-2K 2:1 Nº REF. DESCRIPTION Nº REF. DESCRIPTION 16.200.02 UNION 16.300.00 SUCTION 16.000.04 SCREW 16.313.00 FILTER C.PA1.01 D.130.00 FILTER C.TA0.05 SCREW G.100.02 COVER 16.200.01 G.100.05 FILTER (*) 16.000.07 COUPLING G.100.04 SPRING 16.200.03 SUPPORT C.TA9.01 SCREW 16B.101.00...
  • Page 8 PUMP A (PAINT) 16B.101.00 Nº REF. DESCRIPTION C.PA1.01 B.120.00 PACKING NUT B.130.01 FEMALE GLAND 100.230.02 PACKING B.130.02 PACKING B.130.03 MALE GLAND B.110.00 HOUSING B.100.01 JOINT B.100.02 SLEEVE B.100.03 B.140.01 WASHER C.B0.202 BALL B.150.00 PISTON B.100.05 B.170.01 RETAINER B.100.06 JOINT CBO.209 BALL B.171.00 VALVE...
  • Page 9 PUMP B (CATALYST) 16.400.00 Nº REF. DESCRIPCION C.PA1.01 B.120.00 PACKING NUT 16.420.01N FEMALE GLAND 16.420.02PN PACKING 16.420.02TN PACKING 16.420.03N MALE GLAND B.110.00 HOUSING B.100.01 JOINT 16.400.02 SLEEVE 16.400.01 16.411.04 WASHER 16.411.01N MALE GLAND 16.411.02PN PACKING 16.411.02TN PACKING 16.411.03N FEMALE GLAND C.B0.202 BALL 16.410.00...
  • Page 10 MIXER (16.120.00) Nº REF. DESCRIPTION 16.120.01 BODY 16.120.02 BODY 16.121.00 VALVE 16.120.03 SEAT CNB.005 GAUGE CTB.032 SCREW CTB.007 SCREW CTU.105 16.100.07 MIXER 16.100.05 MIXER BODY G.100.06 COUPLING CNA.116 SWIVEL CNC.006 VALVE CNA.057 COUPLING CNA.063 ELBOW 16.122.00 HANDLE (fig. 8) Nº REF.
  • Page 11 AIR MOTOR ‘‘CLEANING PUMP’’ Nº REF. DESCRIPTION CTB.002 SCREW 080.100.01 COVER CNA.065 ELBOW CTB.023 SCREW 080.120.00 COVER 080.100.05 SNUBBER 080.170.05 GUIDE 080.100.08 WASHER 080.150.00 AIR DISPENSER 080.100.07 HOUSING 080.100.04 SNUBBER CTB.030 SCREW 080.110.00 MOTOR BODY 080.140.00 SPRING SUPPORT 080.100.09 SPRING BUTT END 080.100.11 SPRING 080.100.10...
  • Page 12 DISPLACEMENT PUMP ‘‘CLEANING PUMP’’ Nº REF. DESCRIPTION CJT.026 JOINT CAR.111 RETAINER 080.200.03 BRIDLE 080.200.01 BODY 080.210.00 OIL TUBE 080.200.04 FEMALE GLAND B.131.02 PACKING B.930.04 PACKING 080.200.06 MALE GLAND CPA.109 080.200.16 080.200.07 SPRING 080.200.08 CYLINDER 080.200.12 MALE GLANG 080.200.13 PACKING 080.200.15 FEMALE GLAND CB0110 BALL...
  • Page 13: Troubleshooting Guide

    TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Pump. fails Restricted line or inadequate air supply. Clear, increase air. to operate. Insufficient air pressure, closed or clogged air Open, clean. valves, etc. Exhausted fluid supply. Refill; purge all air from pump and fluid lines.
  • Page 14 AITOR ORTIZ FECHA / DATE MBP, S.L. figura inscrita en el Registro Industrial del País Vasco con el Nº 01/8030 y cumple los requisitos para el desarrollo de su actividad comercial. MBP, S.L. is registered in the Industrial Register of the Basque Country with the Nº 01/8030.
