Sizing and dimensional data

Typical AC switchgear sections, 635V maximum,
50/60 Hz
Switchgear section and line-up sizing
AKD-10 indoor low voltage switchgear height is 92" (97" over
the top wiring trough and 103.5" over the optional breaker
hoist). The available breaker stacking space is 84". Optional
78"-high indoor equipment with a breaker stacking space of
70" is also available (contact factory for details).
Table 32.1 Enclosure depth options
Enclosure type
Front compartment
Rear compartment (Std depth or 7" or 14" rear extension)
Indoor (total indoor frame depth)
Outdoor (total indoor frame depth)
Walk-in (total enclosure depth)
Non-walk-in (total enclosure depth)
Table 32.2 AKD-10 Switchgear section sizing
Breaker type
Device combination
or bus rating
WPS-08
WPH-08
WPX-08
WPF-08
WPS-16
WPH-16
WPF-16
WPS-20
WPS-20 with fuse roll-out
WPS-32
WPH-32
WPX-32
WPS-32 with fuse roll-out
WPS-40
WPX-40
WPS-40 with fuse roll-out
WPS-50
WPX-50
WPS-50 with fuse roll-out Œ
1600-4000A main bus rating
5000A main bus rating
ΠBreaker and fuse roll-out must be mounted in separate vertical sections
 81" depth available only when these devices are used in a line-up with items identified with **
z Section width can be increased for additional cable / conduit space. 22" sections can be increased to 30" wide, 30" wide sections can be increased to 38" wide.
Table 32.3 Switchgear weights
Procedure:
A) Add the weight of every vertical section in the lineup
B) Add the weight of each breaker and fuse roll-out in the lineup
Vertical section weights, Lb. [Kg]
Section
# of breaker compartments
width
in vertical section
1
2
22"
3
4
1
30"
2
1
38"
2
22" or 30" Auxiliary section
ΠAlso includes number of fuse roll-outs in the vertical section.
32
Frame size
Breaker cubicle
(amperes)
vertical height
(inches)
800
1600
2000
3200
4000
5000
Œ
Enclosure type
Indoor
Outdoor
940 (426)
1610 (730)
1100 (499) 1770 (803)
1270 (576) 1940 (880)
1440 (653) 2110 (957)
1300 (590) 2100 (953)
1400 (635) 2300 (1043)
1660 (753) 2600 (1179)
1900 (862) 2830 (1284)
1170 (531) 1800 (816)
Breaker frame size and type determine the width of the
breaker sections and also the minimum depth of the
switchgear line-up. Refer to Tables 31.1 and 31.2 for properly
sizing AKD-10 line-ups. The depth of the entire line-up is
determined by the deepest device in the line-up. For example,
a line-up with a WPS-20 breaker with a fuse roll-out (depth -
60") and WPF-08 breakers (depth - 67") would be a minimum
of 67" deep — the WPF-08 being the deepest device. Also
refer to the section arrangements on the following pages for
available breaker stacking configurations.
Available depth options
30"
30" (std) 37" (7" ext)44" (14" ext)
60"
67"
74"
60"
108"
68"
Minimum section
z
width
(inches)
21
22
56
30
35
84
38
35
30
35
30
84
38
35
38
Table 32.4 WavePro breaker and fuse roll-out weights
Device
WPS / WPH-08
WPX-08
WPF-08
WPS / WPH-16
WPF-16
WPS-20
WPS / WPH / WPX-32
WPS / WPX-40
WPS / WPX-50
2000/3200A Fuse Roll-out (WP32FRE) 330 [150] 3 Fuses – add 75 [34]
4000A Fuse Roll-out (WP40FRE)
5000A Fuse Roll-out (WP50FRE)
37"
30" (std) 37" (7" ext)44" (14" ext)
67"
74"
81"
74"
122"
82"
Minimum equipment
Optional
depth [Front/Rear
equipment
compt] (inches)
depth (inches)
60 [30 / 30]
67/74
67 [37 / 30]
74/81**
60 [30 / 30]
67/74
60 [30 / 30]
67/74
67 [37 / 30]
74/81**
60 [30 / 30]
67/74
67/74/81 
60 [30 / 30]
67/74/81 
60 [30 / 30]
67/74/81 
60 [30 / 30]
67/74/81 
60 [30 / 30]
67/74/81 
60 [30 / 30]
67/74/81 
60 [30 / 30]
67/74/81 
60 [30 / 30]
67 [37 / 30]
74/81**
74 [37 / 37]
81**
74 [37 / 37]
81**
74 [37 / 37]
81**
60 [30 / 30]
67/74
74/81 
67 [30 / 37]
Net Weight, lb. [kg]
Manual
Electrical
175 [79]
180 [82]
210 [95]
215 [98]
220 [100] 225 [102]
210 [95]
215 [98]
280 [127] 285 [129]
220 [100] 225 [102]
490 [222] 500 [227]
535 [243] 545 [247]
600 [272] 610 [277]
335 [152] 3 Fuses – add 90 [41]
345 [156] 3 Fuses – add 90 [41]
