GM862 Product Description
GM862-GPS, GM862-QUAD-PY , GM862-QUAD
80272ST10019a Rev. 10 – 18/09/2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM862PYT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telit Wireless Solutions GM862PYT Series

Summary of Contents for Telit Wireless Solutions GM862PYT Series

  • Page 1 GM862 Product Description GM862-GPS, GM862-QUAD-PY , GM862-QUAD 80272ST10019a Rev. 10 – 18/09/2008...
  • Page 2 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 This document is relating to the following products: GM862-QUAD-PY GM862PYT***-*** GM862-QUAD GM862QUD***-*** GM862-GPS GM862GPS***-*** The suffix “***-***” depends on the module HW/SW configuration. Please contact your Telit representative for details. Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 2 of 60...

  • Page 3: Table Of Contents

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Contents Overview............................7 General Product Description ......................9 Dimensions ..........................9 Weight ............................10 Environmental requirements....................11 2.3.1 Temperature range ........................11 2.3.2 Vibration Test (non functional)....................... 11 2.3.3 RoHS compliance .......................... 11 Operating Frequency ......................12 Transmitter output power.....................12 Reference sensitivity ......................12 Antennas ..........................13 2.7.1...
  • Page 4 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 2.12.15 Buzzer Output ..........................19 2.12.16 RF Transmission Monitor......................19 2.13 EMC ............................19 2.14 Logic level specifications.....................19 2.14.1 Reset signal ........................... 19 2.15 Audio levels specifications ....................21 2.16 ADC Converter ........................21 2.17 Interface connectors on GM862 modules ................22 Evaluation Kit..........................23 Software Features........................24...
  • Page 5 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862-GPS: Conformity Assessment ................49 GM862-GPS FCC Equipment Authorization................52 GM862-GPS IC Equipment Authorization ................53 SAFETY RECOMMENDATIONS ....................54 GM862 Family Technical Support ....................56 Acronyms .............................57 10 Document Change Log .......................59 Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 5 of 60...
  • Page 6 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 DISCLAIMER The information contained in this document is the proprietary information of Telit Communications S.p.A. and its affiliates (“TELIT”). The contents are confidential and any disclosure to persons other than the officers, employees, agents or subcontractors of the owner or licensee of this document, without the prior written consent of Telit, is strictly prohibited.

  • Page 7: Overview

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Overview GM862 family consist of the following modules: the GM862-GPS, GM862-QUAD-PY and GM862-QUAD, which combine the access to digital communication services in GSM 850, 900, DCS 1800, PCS1900 MHz networks with an additional key feature of the integrated GPS receiver (GM862-GPS only). Telit GM862-GPS GM862- includes a 20 channels GPS receiver.
  • Page 8 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 From the interface point of view, the GM862-GPS, GM862-QUAD-PY GM862-QUAD provide the following features: • Full RS232 UART, CMOS level (ASC0) interface for AT commands: - Auto-bauding from 2.4 up to 57.6 Kbps - Fixed baud rate up to 115.2 Kbps •...

  • Page 9: General Product Description

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 2 General Product Description Dimensions Telit GM862-QUAD-PY and GM862-QUAD modules overall dimension are: • Length: 43.9 mm • Width: 43.9 mm • Thickness: 6.9 mm • ≅ 13 cm Volume: The layout is shown in the following figure: Reproduction forbidden without Telit Communications S.p.A.

  • Page 10: Weight

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 The layout of Telit GM862 GPS module is shown in the following figure: GPS antenna connector Weight Telit GM862 Family modules weight is: product weight (gr) GM862-QUAD/QUAD-PY GM862-GPS Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 10 of 60...

  • Page 11: Environmental Requirements

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Environmental requirements Telit GM862 modules are compliant with the applicable ETSI reference documentation GSM 05.05 Release1999 ETSI EN300910 V8.4.1 2.3.1 Temperature range GM862-QUAD / GM862-GPS Note GM862-QUAD-PY The module is fully functional (*) in –20°C ÷...

  • Page 12: Operating Frequency

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Operating Frequency The operating frequencies in GSM, DCS, PCS modes are conform to the GSM specifications. Mode Freq. TX (MHz) Freq. RX (MHz) Channels TX - RX offset (ARFC) E-GSM-900 890.0 - 914.8 935.0 - 959.8 0 –...

  • Page 13: Antennas

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Antennas 2.7.1 GSM Antenna The antenna that the customer chooses to use, should fulfill the following requirements: Frequency range Depending by frequency band(s) provided by the network operator, the customer shall use the most suitable antenna for that/those band(s) Bandwidth 80 MHz in EGSM 900, 70 MHz if GSM 850, 170 MHz in DCS,...

  • Page 14: Gps Module Features

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GPS Module features The GM862-GPS includes a SiRFstarIII™ single chip GPS receiver, that supports real-time location in urban area and wherever a high sensitivity acquisition is needed. As main features of such GPS receiver, we can mention: •...

  • Page 15: Gps Driving

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862-GPS (3990250657) GM862-GPS (3990250689) 70 mA ±20%, including 50 mA 55mA, including 35mA GPS for Operating current for the GPS hardware and 20 the GPS hardware and 20 mA mA for the antenna LNA for the antenna LNA 2.8.1.3 GPS Driving The GPS functions are driven from the GSM BB processor trough a dedicated AT command set...

  • Page 16: Gsm Power Consumption

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 NOTE: Operating voltage range must never be exceeded; min/max voltage requirements and peak current supply should be fulfilled. 2.10 GSM Power consumption The typical current consumption of the Telit GM862 Family modules are: Power off current (typical) <...

  • Page 17: Speech Coding

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 2.12.1 Speech Coding Telit GM862 voice codec supports the following rates: • Half Rate. • Full rate, • Enhanced Full Rate • Adaptive Multi Rate 2.12.2 SIM Reader Telit GM862-QUAD, GM862-QUAD-PY GM862-GPS support phase 2 GSM11.14 - SIM 1.8V and 3V.

  • Page 18: Call Control

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 2.12.7 Call control Call cost control function. 2.12.8 Phonebook Function available to store the telephone numbers in SIM memory. Capability depends on SIM version/memory 2.12.9 Characters management The GM862 supports the IRA characters set (International Reference Alphabet), in TEXT and PDU mode.

  • Page 19: Buzzer Output

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 • SMS received tone; • Busy tone; • Power on/off tone; • Off Hook dial tone; • Congestion tone; • Connected tone; • Call dropped; • No service tone; • Alarm tone. 2.12.15 Buzzer Output The General Purpose I/O pin GPIO7 can be configured to output the BUZZER output signal, with only...
  • Page 20 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862 NOTE: do not use this signal to power off the . Use the ON/OFF signal (Pin 17 of SO301) to perform this function or the AT#SHDN command. Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 20 of 60...

  • Page 21: Audio Levels Specifications

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 2.15 Audio levels specifications Telit GM862 module The audio path of the is organized into two main paths: • internal path (called also MT) • external path (called also HF) Telit GM862 These two paths are meant respectively for handset and headset/hands free use.

  • Page 22: Interface Connectors On Gm862 Modules

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 2.17 Interface connectors on GM862 modules Telit GM862 Family modules has the following interfaces: • GSM antenna connector • Board To Board Interface connector • SIM Card Reader • GPS antenna connector (GM862-GPS only) Telit GM862 Family modules board to board connector is a CSTP 50 pin vertical SMD Molex 52991–...

  • Page 23: Evaluation Kit

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 3 Evaluation Kit Telit GM862 Family modules In order to assist you in the development of your based application, Telit can supply an Evaluation Kit that interfaces the Telit GM862 Family modules directly with appropriate power supply, SIM card housing, RS 232 serial port level translator and USB, direct UART connection, Telit...

  • Page 24: Software Features

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 4 Software Features Enhanced Easy GPRS Extension 4.1.1 Overview Telit GM862-QUAD,QUAD-PY The Easy GPRS feature allows the models user to contact a device in internet and establish with it a raw data flow over the GPRS and Internet networks. This feature can be seen as a way to obtain a "virtual"...

  • Page 25: Easy Gprs Definition

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 • Keep the GPRS context active even after the closing of a socket, allowing the application to keep the same IP address; • Also Mobile terminated (incoming) connections can be made, now it is possible to receive incoming TCP connection requests;...

  • Page 26: Multisocket

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Multisocket New functionality of the Telit modules, multisocket is an extension of Telit Easy GPRS feature, which allows the user to have two contexts activated (that means two different IP address), more than one socket connection (with a maximum of 6) and simultaneous FTP client service.
  • Page 27 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 This new feature allows the user to switch between online mode and command mode without closing the connection and eventually opening another socket (or resuming the suspended one) or FTP connection. Another feature is the possibility to associate any socket connection to a specific context, this means that we can use different IP addresses for the connections (max 2).

  • Page 28: Jammed Detect & Report Extension

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Jammed Detect & Report Extension 4.3.1 Overview Telit GM862-QUAD,QUAD-PY GPS modules The Jammed Detect & Report feature allows a to detect the presence of a disturbing device such as a Communication Jammer and give indication to the user and/or send a report of that to the network.

  • Page 29: Cmux

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 CMUX CMUX ( Converter-Multiplexer) is a multiplexing protocol implemented in the Telit module that can be used to send any data, SMS, fax, TCP data. 4.4.1.1 Product architecture The Multiplexer mode enables one serial interface to transmit data to four different customer applications.

  • Page 30: Easy Script Extension - Python Interpreter

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Easy Script Extension - Python interpreter 4.5.1 Overview NOTE: This feature is available only on models GM862-QUAD-PY GM862-GPS. The Easy Script Extension is a feature that allows driving the modem "internally", writing the controlling application directly in a nice high level language: Python.
  • Page 31 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 In order to eliminate this external controller, and further simplify the programming of the sequence of operations, inside the GM862-QUAD-PY / GM862-GPS it is included: • Python script interpreter engine v. 1.5.2+ •...

  • Page 32: Python 1.5.2+ Copyright Notice

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 4.5.2 Python 1.5.2+ Copyright Notice The Python code implemented into the Telit module is copyrighted by Stichting Mathematisch Centrum, this is the license: Copyright © 1991-1995 by Stichting Mathematisch Centrum, Amsterdam, The Netherlands. All Rights Reserved Copyright (c) 1995-2001 Corporation for National Research Initiatives;...

  • Page 33: Python Implementation Description

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 4.5.3 Python implementation description Python scripts are text files stored in NVM inside the Telit GM862-QUAD-PY and GM862-GPS. There's a file system inside the module that allows to write and read files with different names on one single level (no subdirectories are supported).
  • Page 34 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 NOTE: Antenna GPS, GPS receiver and GPS Library are available exclusively for GPS module GM862-GPS. Moreover SER2 Library can not be used by the GPS modules since their TRACE port is not available. •...

  • Page 35: Python Core Supported Features

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 4.5.4 Python core supported features The Python core version is 1.5.2+ (string methods added to 1.5.2). You can use all Python statements and almost all Python built-in types and functions. Built-in types and functions not Available modules supported (all others are not supported)

  • Page 36: Python Build-In Custom Modules

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 4.5.5 Python Build-in Custom Modules Several build in custom modules have been included in the python core, specifically aimed at the hardware environment of the module. The build in modules included are: interface between Python and mobile internal AT command handling MDM2 second interface between Python and mobile internal AT command handling...

  • Page 37: Sap: Sim Access Profile

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 SAP: SIM Access Profile 4.6.1 Product architecture The SAP feature allow the module to use the SIM of a remote SIM Server. This feature is implemented using special AT Command on a Virtual circuit of the CMUX interface. 4.6.2 Implementation feature •...

  • Page 38: Tfus (Telit Firmware Update Service)

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Transfer ATR Disconnection Initiated by the Client Disconnection Initiated by the Server Transfer APDU Transfer APDU Transfer ATR Transfer ATR Power SIM on Power SIM on Transfer ATR Report Status Report Status Error Handling Error Response Report Status, Disconnection Initiated by the Server and Error Response are independent messages...

  • Page 39: At Commands

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 AT Commands GM862 module can be driven via the serial interface using the standard AT commands . The GM862 module are compliant with: 1. Hayes standard AT command set, in order to maintain the compatibility with existing SW programs.

  • Page 40: Conformity Assessments

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 6 Conformity Assessments Telit GM862 modules are assessed to be conform to the R&TTE Directive as stand-alone products, so if the module is installed in conformance with Telit Communications installation instructions require no further evaluation under Article 3.2 of the R&TTE Directive and do not require further involvement of a R&TTE Directive Notified Body for the final product.
  • Page 41 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 • The system antenna(s) used for this module must not exceed 3 dBi for mobile and fixed or mobile operating configurations. • Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

  • Page 42: Gm862-Quad: Conformity Assessment

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 6.1 GM862-QUAD: Conformity Assessment Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 42 of 60...
  • Page 43 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 43 of 60...

  • Page 44: Gm862-Quad-Py: Conformity Assessment

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862-QUAD-PY: Conformity Assessment Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 44 of 60...
  • Page 45 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 45 of 60...

  • Page 46: Gm862-Quad/Quad-Py/Gps: Rohs Certificate

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862-QUAD/QUAD-PY/GPS: RoHS certificate Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 46 of 60...

  • Page 47: Gm862-Quad / Quad-Py: Fcc Equipment Authorization

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862-QUAD / QUAD-PY: FCC Equipment Authorization Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 47 of 60...

  • Page 48: Gm862-Quad / Quad-Py: Ic Equipment Authorization

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862-QUAD / QUAD-PY: IC Equipment Authorization Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 48 of 60...

  • Page 49: Gm862-Gps: Conformity Assessment

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862-GPS: Conformity Assessment Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 49 of 60...
  • Page 50 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 50 of 60...
  • Page 51 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 51 of 60...

  • Page 52: Gm862-Gps Fcc Equipment Authorization

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862-GPS FCC Equipment Authorization Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 52 of 60...

  • Page 53: Gm862-Gps Ic Equipment Authorization

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 GM862-GPS IC Equipment Authorization Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 53 of 60...

  • Page 54: Safety Recommendations

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 7 SAFETY RECOMMENDATIONS READ CAREFULLY Be sure the use of this product is allowed in the country and in the environment required. The use of this product may be dangerous and has to be avoided in the following areas: •...
  • Page 55 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 • The Low Voltage Directive (LVD) 73/23/EEC and The Council Directive 89/336/EEC of 3 May 1989 on ... electromagnetic compatibility (EMC Directive) are available at: http://europa.eu.int/comm/enterprise/electr_equipment/index_en.htm • The DIRECTIVE 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 27 January 2003 on waste electrical and electronic equipment (WEEE) and the DIRECTIVE 2002/95/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 27 January 2003 on the restriction of the use of certain hazardous substances in electrical and electronic...

  • Page 56: Gm862 Family Technical Support

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 8 GM862 Family Technical Support Telit’s technical support to GM862 wireless modem customers consists in: • Technical documentation: available for download on the Website www.telit.com >Products >Modules > selected model. • Engineering support: accessible via E-Mail service with 48 hr replies assured under normal conditions.

  • Page 57: Acronyms

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Acronyms Accumulated Call Meter ASCII American Standard Code for Information Interchange Attention commands Ball Grid Array (of solder balls on surface mount devices) Cell Broadcast Cell Broadcasting Service Call Control Meter CLIP Calling Line Identification Presentation CLIR Calling Line Identification Restriction...
  • Page 58 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Inter-Working Function Liquid Crystal Display Light Emitting Diode Linefeed Mobile Equipment Man Machine Interface Mobile Originated Mobile Station Mobile Terminated NMEA National Marine Electronics Association Other Equipment Manufacturer Phone Book Protocol Data Unit Packet Handler Personal Identity Number PLMN...

  • Page 59: Document Change Log

    GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 10 Document Change Log Revision Date Changes ISSUE#0 10/04/05 initial release. ISSUE#1 27/10/05 Paragraphs reviewed: Overview Dimensions (GPS antenna position frozen) 2.3.1 Temperature range Reference sensitivity 2.7.1 GSM Antenna GPS Module features 2.8.1.1 GPS Sensitivity 2.8.1.2 GPS Consumption 2.12.9...
  • Page 60 GM862 Product Description 80272ST10019a Rev. 10 – 18/09/2008 Assessment 7.11 GM862-GPS: Conformity Assessment ISSUE#5 08/01/07 added footnotes on the pages 7, 8 and 17 Weight: changed weight values 2.7.1 GSM Antenna: updated values of bandwidth 2.10 GSM Power Consumption: updated values of operating current (P/N:3990250655) / GM862-QUAD...
