User Manual for EXCELAM-1100SWING
EXCELAM-1670SWING
Before operating the unit, please read this manual thoroughly and retain it for future reference.
※ The design / specification of the machine could be changed for improvement without any prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXCELAM-1100SWING and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GMP EXCELAM-1100SWING

Summary of Contents for GMP EXCELAM-1100SWING

  • Page 1 User Manual for EXCELAM-1100SWING EXCELAM-1670SWING Before operating the unit, please read this manual thoroughly and retain it for future reference. ※ The design / specification of the machine could be changed for improvement without any prior notice.
  • Page 2 35 page ◐ PRODUCT MAINTENANCE ◐ USAGE OF CONTROL PANEL 16 page 36 page Control Panel ◐ TROUBLE SHOOTING 17 page Function Button 38 page ◐ PRODUCT SPECIFICATION 20 page ◐ USAGE OF MAIN DEVICE 39 page ◐ GMP SUBSIDIARIES...
  • Page 3 IMPORTANT SAFETY INSTRUCTION It is for the purpose of user's safety and prevention of the property loss. Read thoroughly the following contents and use rightly according to the manual. Safety instruction is classified as "Warning" and "Caution", the meaning is as follows; Warning : If you ignore this symbol, you can suffer serious injury and sudden to death.
  • Page 4 IMPORTANT SAFETY INSTRUCTION WARNING POWER Connect or dissemble the power plug with a wet hand. It make a electric shock Do not use more than one outlet with other products. The overheating of the outlet can be a main reason of a fire flame. Do not use without a specified power supply and voltage.
  • Page 5 IMPORTANT SAFETY INSTRUCTION Installation & Usage Do not use materials near the heating place or flammable materials. It makes a fire flame. Do not place nearby a place just like a dark place or slope Do not use more than one outlet with other products. The overheating of the outlet can be a main reason of a fire flame Do not dissemble, make repairs, convert.
  • Page 6 IMPORTANT SAFETY INSTRUCTION Installation & Usage Take care of yourself from wound by cutting knife. This product is too heavy so, necessarily a lot of people should carry the product when unpacking or carrying, if you don't , it makes a product damage or personal injury Be careful not to allow a part of your body or other alien substance wound into the gear or the chain.
  • Page 7 SAFETY DEVICE Emergency switch ☞ Emergency Switch This device is stopping the system operating and running motor of roller, at emergency. when this switch is pressed, the system does not operate. ☞ Location of Emergency Switch Emergency Switch ☞ Emergency stop and release Press the emergency switch(red button) will stop the motor.
  • Page 8 WARNING STICKER Warning Sticker In order to avoid an unexpected damage & to keep the operators' safety, the Warning Stickers are on the machine. ☞ Roller ☞ Extremely high Temperature Do not insert the Hand or body to the rollers Be cautious not to touch the surface This would be a cause of damage by high temp.
  • Page 9 WARNING STICKER Location of Warning Sticker 9/39...
  • Page 10 PACKING CONTENTS Packing contents FUSE 3A 2EA 2.5mm T wrench 1EA FUSE 6A 2EA 3mm L wrench 1EA (UL 5A 4EA) 5mm L wrench 2EA User Manual LAMINATOR 10/39...
  • Page 11 PART NAME Part Name 1. Rewinder tension Control handle 4. Roll film 7. Control panel 2. Laminating roller 5. Caster 8. Roller Pressure Control handle 3. Front Table 6. Rewinder 9. Stand 11/39...
  • Page 12 PART NAME Main Device Film tension handle Roller safety cover Power switch Film shaft holding pin Emergency switch Side slitter Film trimmer Rewinder tension control Pressure plate Idle roller Film core Foot switch 12/39...
  • Page 13 PART NAME Main Device Explanation Emergency switch When pressing in emergent situation, motor stops. Film shaft Device for installing laminating film rolls Film shaft holding pin This is not to let film shaft move needlessly Laminating roller Heating & pressing roller Idle roller This is to make being-laminated film flat for good lamination result.
  • Page 14 CARRIAGE AND INSTALLATION Carriage and Installation Product Carriage This product is too easy to carry mainly due to the moving wheels. At transportation, "Moving wheel "works after pushing the moving wheel locker's direction "OFF" and then push the laminator The product is too heavy to carry, therefore more than two persons should carry the laminator. If you carry this product, necessarily move it with a forklift truck After a product installation, Push "the moving wheel locker's direction "On".
  • Page 15 CARRIAGE AND INSTALLATION Carriage and Installation Product Carriage and Installation : When you carry this product, more than 3persons necessarily carry safety. Product placing should be installed at the hard and balanced floor. Connecting Power : Power supply should be used AC 220V/20A above. Necessarily Grounding is needed for your safety. Caution : Necessarily grounding is needed for your safety At the case of malfunction and electric leakage can make an electric shock.
  • Page 16 USAGE OF CONTROL PANEL Control Panel 1. TEMP.DISPLAY WINDOW Displays the present temperature or setting temperature of roller EXCELAM-1670SWING Temperature setting range is from Min. "0℃" to Max."160℃" Note : Refer to function button guide to check present temperature or set up the temperature. This product has function of self-diagnosis for troubles.
  • Page 17 USAGE OF CONTROL PANEL Function Button 1 - MEMORY is for memorizing of working condition. EXCELAM-1670SWING 2 - JOB is for working condition memorized from JOB1 to JOB9. ☞ Saving working condition 1) By using Job button, select the number to memorize. (Selected number displays on window) 2) Set the roller temp.
  • Page 18 USAGE OF CONTROL PANEL 5 - TOP/BOTTOM TEMPERATURE To set up the Roller Temp. Temp. Setting Range is "0 ~ 160"℃ . EXCELAM-1670SWING First press the button one time, temperature goes up(down) by "1℃", continuous pressing can make that for the first 2second, goes up 1℃ by 0.5sencond, after then goes up 10℃rapidly. 6 - SPEED To set up the laminating speed.
  • Page 19 USAGE OF CONTROL PANEL 10 - STAND-BY Is for stand-By the machine. ☞ STAND-BY MODE ? EXCELAM-1670SWING When you leaves the machine for long time, the roller temp. can be controlled below 80℃ or cut off the power of machine. 1) Setting by Users : For short time, if you does not operate the machine, it can be used.
  • Page 20 USAGE OF MAIN DEVICE ☞ POWER SWITCH is for supplying or cutting off the power, circuit breaker installed, at the time of overloading of machine, current overflow, automatically cut off the power. When the switch direction is "I", the power is on, otherwise the power is off. Remark : If found wrong operating continuously please contact to your agent or distributor.
  • Page 21 USAGE OF MAIN DEVICE ☞ FILM TENSION CONTROL HANDLE FOR REWINDING - ① This handle functions to adjust tensile of film for rewinding. Use this handle when film tension is loosened or tightened too much. When turn the Film Tension Control handle to the right, film tension increases and turn to the left, it decreases. ☞...
  • Page 22 USAGE OF MAIN DEVICE Trimmer Fixing Knob ☞ SIDE SLITTER Side slitter is located in between the Heat Roller and Pull Roller and this is to trim a margin on laminating film. How to use Side Slitter : 1. Move Side Slitter at a required position. 2.
  • Page 23 HOW TO LAMINATE HOT LAMINATING Stage 1 : Film Installation Structure of Film Shaft 1. Film Shaft : Device for loading a laminating roll film. 2. Film Shaft Pin : Device to prevent from moving film shaft. 3. Film Core : Device for fixing a laminating roll film. Film Loading 4.
  • Page 24 HOW TO LAMINATE HOT LAMINATING Film Loading Upper Sub-Roller Roll Film Pulling Roller Laminating Roller Stretch bar Lower Sub-Roller Roll Film Caution : At the condition of laminating status, temperature and speed adjusting is needed. 24/39...
  • Page 25 HOW TO LAMINATE HOT LAMINATING Stage 2 : To Ready For Laminating 5. Install Laminating Roller 1. Put some beginning parts 2. Stick paper in between 3. Stick lower film on the 4. Install Front Plate. Cover. of upper film on the roller rollers on the upper film paper and upper film.
  • Page 26 HOW TO LAMINATE HOT LAMINATING Stage 3 : Laminating 1. Put a Pressure Adjust 2. Set required Speed and 3. Lay the sheet on front handle on required position. temperature. plate and push it in slightly. DO NOT HOT LAMINATING Caution : If you laminate the paper printed by the sublimating heat transfer printer, the laminated paper changed by the time passed.
  • Page 27 HOW TO LAMINATE ULTRA-THIN OVERLAY COATING (MICRONEX FILM) Stage 1 : Film Installation Film installation is the same as the stage 1 of hot laminating. Only the film should be placed at the upper end of the film core. MICRONEX is only for the single side laminator. ☞...
  • Page 28 HOW TO LAMINATE ULTRA-THIN OVERLAY COATING (MICRONEX FILM) Film Loading Rewinder Upper Film Upper Sub-Roller Separator(Optional) Using a separator(optional), separate the laminated Film and paper. Pull Roller Heat Roller Caution : At the condition of laminating status, temperature and speed adjusting is needed. 28/39...
  • Page 29 HOW TO LAMINATE ULTRA-THIN OVERLAY COATING (MICRONEX FILM) Stage 3 : To Ready For Laminating 4. It is a readiness for 1. After Installing separator, 2. It is the same as hot 3. Rewind the film into the micronex film laminating. insert the paper to push out.
  • Page 30 HOW TO LAMINATE COLD LAMINATING Stage 1 : Film Installation Film Installation is the same case as like the hot laminating stage 1(Film installation) Caution : In the case of film width is above 1M or 25KG, More than 2persons is needed. If you does not, you can suffer a personal injury.
  • Page 31 HOW TO LAMINATE COLD LAMINATING Film Loading Rewinder Upper Film Upper sub-roller The rotating direction of rewinder Pull roller Heat roller Caution : At the condition of laminating status, temperature and speed adjusting is needed. 31/39...
  • Page 32 HOW TO LAMINATE COLD LAMINATING Stage 4 : Laminating Laminating is same with 3rd step of Hot laminating. ☞ It is easy to work when you use the foot switch on cold laminating. ☞ Caution at the cold laminating 1. Please Be Attention That sheet Printed By Sublimated Heat Transfer Mode Is Subject To Degenerate Or Lost Its Color When Cold Laminating.
  • Page 33 LAMINATION GUIDE LAMINATION GUIDE Film Thickness Paper Type Max. Setting Temp. Speed Below 38㎛(1.5mil) 110℃ 50~80㎛(2~3.5mil) Below 100g 110℃ 100~150㎛(4~6mil) 110℃ 175~250㎛(7~10mil) 110℃ Below 38㎛(1.5mil) 110℃ 50~80㎛(2~3.5mil) Above 100g ~ 110℃ 100~150㎛(4~6mil) Below 150g 110℃ 175~250㎛(7~10mil) 110℃ Below 38㎛(1.5mil) 110℃ 50~80㎛(2~3.5mil) Above 150g ~ 110℃...
  • Page 34 6. Do not use other film except GMP laminating film. It can cause a machine disorder. 7. If the paper are not feeded into feeding table rightly, it can cause film crease.
  • Page 35 PRODUCT MAINTENCE A roller's washing ☞ If the rollers not to be washed ~ - A film can be wound into the rollers - A laminating result has a stain * To prevent this status, roller cleansing is needed. ☞ A roller's washing - After laminating, if the roller's temperature is lowered below 80, with "linen"...

  • Page 36: Trouble Shooting

    TROUBLE SHOOTING Symptom Cause of Trouble How to solve When the power is not "ON" 1. Check Power Switch "ON/OFF" 2. When ran reverse-current circuit breaker 2. Contact Purchased place or Service Center. 3. When cut off fuse 3. Please exchange to included Fuse. When roller not working 1.
  • Page 37 TROUBLE SHOOTING Symptom "C" of Fig. 1. when over pressure on laminating roller 1. decrease a lamination roller pressure Symptom "D" of Fig. 1. when laminating roller need a pressure 1. Increase a laminating roller pressure Symptom "E" of Fig. 1.
  • Page 38 Product Specification Specification Classification EXCELAM-Q1100SWING EXCELAM-Q1670SWING Regular voltage 220~240V, 50/60Hz Consumption electricity 3300W/15A Product size(W*L*H)(mm) 1500*710*1250 2000*710*1250 Preheating time(min) 22 Minutes 25 Minutes Max Laminating speed(mm) 3,000 Max Laminating Width(mm) 1,100 1,670 Laminating film thickness(mic, ㎛) 25~500㎛ Max Mounting Height(mm) 13mm Laminating paper(g/㎡) 80g/㎡...
  • Page 39 Address : #139, Saneopdanji-gil, Paju-si, Gyeonggi-do, Korea Tel No : +82-31-943-3600 Fax No : +82-31-943-4433 http://www.gmp.com KOREA GMP PROGRAPHICS Germany GmbH EU Prographics Center for Distribution, Marketing, Service and Training Address : Robert-Bosch-Str.4 D-56751 Polch, Germany Tel No : +49-2654-9490-0 Fax No : +49-2654-9490-90...
