- Page 1 2015. 08 RTR-380COMBI User Manual Before operating the unit, please read this manual thoroughly and retain it for future reference. ※ The design / specification of the machine could be changed for improvement without any prior notice.
- Page 2 CONTENTS Pre-information Maintenance & Service Important Safety Instruction page Product Maintenance page Safety Device page Malfunction & Measures page Contents page Product Specification page Each Part Name page Subsidiaries page How to install Transportation & Installation page How to use the control panel page How to use Main Device page...
- Page 3 IMPORTANT SAFETY INSTRUCTION "Important Safety Instruction " is for the purpose of user's safety Read thoroughly and use rightly according to the manual Important safety Instruction is classfied as "Warning" and "Caution", the meaning is as follws; Warning: If you ignore this symbol, you could suffer serious injury or death. Caution: If you ignore this symbol, you could receive a serious injuty or loss property.
- Page 4 IMPORTANT SAFETY INSTRUCTION Warning Do not connect of disconnect with wet hands, as this will cause an electric shock Do not overload a power supply, as this will cause a fire and an electric fire and an electric shock Do not use a damaged plug or lead, as this could cause a fire or an electric shock Make sure plug is in the socket, as it could cause fire or an electirc shock Danger, Malfunction, loss of electricity could cause an electric shock Do not pull the plug or bend improperly...
- Page 5 IMPORTANT SAFETY INSTRUCTION Caution When moving the product, turn off the power switch, disconnect the power plug from the socket When the laminator is not in use, you must turn off the power switch, disconnect the power plug from the socket This product is rellay heavy.
- Page 6 SAFETY DEVICE Safety Device Push the below red botton, and emergency switch will works ☞ Safety Device stop all system. Emergency Switch fucntion is stopping drive motor. Turn red botton as below and it will return to normal. This is only for the emergency. ※...
- Page 7 PACKING CONTENTS Packing Contents Item Q'ty(EA) LAMINATOR User Manual 4mm T Wrench 3mm L Wrench User Manual 3.15A FUSE 6.3A FUSE LAMINATOR 7/25...
- Page 8 EACH PART NAME Each Part Name 1. Rewinder Tension Handle 2. Emergency Switch 3. Upper Film Tension Handle 4. Lower Film Tension Handle 5. Decurling Adjusment Handle 6. Upper Rewinder Tension Handle 7. Seperator 8. Power 9. Lower Rewinder Tension Handle 10.
- Page 9 MOVEMENT & INSTALLATION Carriage & Installation: If you carry this product. 2 people is needed with extra caution Warning : Product is so heavy, necessarily 2 people are needed. It is a main reason of breakage and personal injury Warning : Please sepregate plug from an outlet.
- Page 10 HOW TO USE CONTROL PANEL ☞ What's on the control panel Control panel consists of display window(A) & master dial(B) & function button(C~L) A. Display B. MASTER DIAL C. Button for upper roller temperature setting D. Button for upper roller temperature setting E.
- Page 11 HOW TO USE CONTROL PANEL ② To show roller speed It shows running speed of laminating roller. Regarding how to adjust roller speed, refer to function of "SPEED" button ③ To show job mode It is a function of saving the value of temperature & speed set by user in accordance with kind of film. This mode can save 13 different kinds of job condition ranging to 1~9,H,U,P,C Ref.
- Page 12 HOW TO USE CONTROL PANEL C & D. Temperature set button (TEMP) : This is to set roller temperature. Temperature setting range is "0 ~ 150"℃. TOP TEMP : temperature setting button for upper roller, BOTTOM TEMP : temperature setting button for lower roller ☞...
- Page 13 MAIN DEVICES ☞ POWER SWITCH Power S/W to supply / stop power to the machine. Press "-" to turn on the machine and press "0" to turn it off. ☞ CIRCUIT BREAKER to stop supply power when the machine has overload/overcurrent. If this is activated, cool down the machine and press the outstanding part of it.
- Page 14 MAIN DEVICES ☞ DECURLING ADJUSTABLE KNOB to avoid curling on laminated results in single side lamination. It is natural that a laminated result is curled to the film direction in single side lamination, then this is not caused by a trouble in the machine. As the left picture, a curling can be controlled by the knob.
- Page 15 HOW TO LAMINATE How to laminate 1st step : Loading a film ☞ Components of Film shaft ① Film shaft : This is used to install Laminating roll film. ① ② ④ ② Film shaft holder fixing pin : This is used to fix the film shaft holder. ③...
- Page 16 HOW TO LAMINATE 2nd step : Preparation for lamination Warning : When preparing the lamination, Please pay attention to not touch the laminating roller. It would cause a burn. 1. Insert the loading paper between the upper/lower roller 2. Pass the upper and lower film through the guide roller and attach the when the machine is stopped.
- Page 17 HOW TO LAMINATE 3rd Step : Lamination ☞ Test Lamination : When the temperature of the roller reaches the Set temperature, do a test lamination to check the status. A low speed lamination is recommended for test lamination and please follow the below instrutions 1.
- Page 18 HOW TO LAMINATE Recommendation 1. Please avoid using very thick papers. It could be stuck 2. A sudden stop of the job may cause a mark on the output. 3. Generally, the thicker the paper or film is, the slower and higher temperature is needed. 4.
- Page 19 HOW TO LAMINATE Loading films(OFF - LINE) FILM [SLEEKING WEB DIGRAM] WEB DIGRAM [Single side Paper Liner Separator Rewinder SLEEKNG FOIL Decurling Bar Heating roller Pull Roller Label OR Media Label OR Media [COLD LAMINATING WEB DIGRAM] Paper Liner [MICRONEX WEB DIGRAM] Paper Liner COLD FILM MICRONEX FILM...
- Page 20 HOW TO LAMINATE Loading Film(IN - LINE) ▶ Standard Laminating speed and Temperature [Single side Lamination] 1) Single side Lamination (Film 100㎛, Paper 100g/㎡) :Upper Roller Temp 110℃, Lower roller Temp 0℃, Speed 5 2) SLEEKING :Upper Roller Temp 130℃, Lower roller Temp 0℃, Speed 3 3) MICRONEX :Upper Roller Temp 130℃, Lower roller Temp 0℃, Speed 3 PRINTER...
- Page 21 MAINTENANCE CLEAN ROLLERS ※ If rollers in the laminator would not be cleaned, - laminated results would be contaminted. - film could be rolled on the roller. - Film front edges could be folded. ※ How to clean the roller - In high temp.
-
Page 22: Troubleshooting
TROUBLESHOOTING These belows are to troubleshoot a trouble for operator. Please ask to a supplier for a trouble that is not listed in the belows. SYMPTOMS CAUSE OF TROUBLE TROUBLESHOOTING Power is not turned on 1. POWER S/W is ON/OFF 1. - Page 23 TROUBLESHOOTING Laminated results has below "C" 1. Laminating Roller pressure is too high. 1. Reduce Laminating Roller pressure. Laminated results has below "D" 1. Laminating Roller pressure is too low. 1. Increase Laminating Roller pressure. Laminated results has below "E" 1.
- Page 24 SPECIFICATION ITEMS SPECFICATIONS Power Requirements AC 220V - 240V 50/60Hz Power Consumption 3,300W / 14.1A Dimension(W*L*H)(mm) 660*1200*555 Warm-up Time 7min Max Laminating Speed(m) 7 m/min Max Laminating Width(mm) Laminating Film Thickness(mic, ㎛) 25 ~ 250 Substrate Thickness(g/㎡) 80 ~ 350 Operating Temperature(℃) 150℃MAX Heating System...
- Page 25 Address : #139, Saneopdanji-gil, Paju-si, Gyeonggi-do, Korea Fax No : +82-31-943-4433 Tel No : +82-31-943-3600 http://www.gmp.com KOREA GMP PROGRAPHICS Germany GmbH EU Prographics Center for Distribution, Marketing, Service and Training Address : Robert-Bosch-Str.4 D-56751 Polch, Germany Tel No : +49-2654-9490-0...
