User Guide 2001.05.30
User's Guide
1600HR,2100HR
LEADERS IN LAMINATION TECHNOLOGY
Operating Instructions
Before operating the unit, please read this manual thoroughly and retain it for future reference.
Copyright GMP 2001. All rights reserved. Reproduction by any means of any image in this catalogue is prohibited without the prior consent of GMP and its authroized agent

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GraphicMaster 1600HR and is the answer not in the manual?

Questions and answers

Related Manuals for GMP GraphicMaster 1600HR

Summary of Contents for GMP GraphicMaster 1600HR

  • Page 1 Before operating the unit, please read this manual thoroughly and retain it for future reference. Copyright GMP 2001. All rights reserved. Reproduction by any means of any image in this catalogue is prohibited without the prior consent of GMP and its authroized agent...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS INSTALLATION FEATURES NAME OF EACH PART OPERATION OF CONTROL PANEL HOW TO PERFORM LAMINATION SAFETY DEVICE HOW TO PERFORM MOUNTING LAMINATION GUIDE CLEANING TROUBLE-SHOOTING SPECIFICATIONS...

  • Page 3: Important Safety Instructions

    Your safety as well as the safety of others is important to GMP. In this instruction manual you will Do not defeat or remove electrical and mechanical safety equipment such as interlocks, shields find important safety messages regarding the product.

  • Page 4: Installation

    Do not operate the laminator with a damaged power supply cord or attachment plug, upon If the operating surface is not leveled, that may cause life of the unit to be shortened. occurrence of a malfunction, or after the laminator has been damaged, contact GMP’s Technical Service Department or your dealer/distributor for assistance.

  • Page 5: Features

    5. Make sure the unit is connected to proper air pressure before turning the power on. Not enough air pressure may cause mal-functioning of the unit. FEATURES From the GMP Stable comes a brand new concept in Hot & Cold Laminating, Mounting. The GMP GraphicMaster has been designed to meet the needs of the developing Graphics Reproduction Market.
  • Page 6 Power Panel Lay-out Cross Slitter Control Panel Power Power Switch Cord (Circuit Breaker) Foot S/W Cord Top Unwinder(Optional) Emergency Switch Laminator Motor Vacuum Fan Transformer AC9V Fuse 250V / T6.3AL Fuse 250V / T4AL Fuse 250V / T3.15AL Transformer AC18V Transformer Primary Cooling Fan Fuse 250V / T3.15AL...

  • Page 7: Operation Of Control Panel

    OPERATION OF CONTROL PANEL Controls Select Key & Jog Dial Vacuum Fluorescent Display (VFD) This part is to control the laminating speed and mode of the unit. Should operator desire to change the Top Temperature, press TOP TOP TEMPERATURE TEMPERATURE key and turn the Jog Dial left or right to set the BOTTOM TEMPERATURE desired temperature.

  • Page 8: How To Perform Lamination

    All the factory-set parameters can be over-ridden (except the pressure setting) HOW TO PERFORM LAMINATION according to operator s needs. In order to perform cold lamination at above 3 settings, please follow as below: How to web the laminating films on the unit for Hot Lamination. Please refer to below diagram 1) Performing Cold Lamination right after Hot Lamination (when the laminator is still hot): IMPORTANT NOTE:...
  • Page 9 P o s i t i o n i n g . . . The unit display “OVERH(OVER HEAT)” when the actual temp. exceeds 160 . Release the rollers and turn off the unit power, then contact GMP agent for support. Mode will be changing as per each mounting thickness settings Note) When you perform Hot Laminating with Mounting Board (EX:GMP Foam T O P >...
  • Page 10 5) Heating Up Display “ ”mark will flash while the heater is being heated T O P > 1 1 0 C S P E E D > 0 5 B O T > 1 1 0 C R / T > 0 0 : 0 0 T O P >...
  • Page 11 RUN TIME Display Front Table (Vacuum Table) Once the unit starts to run, the Run Time Counter will be activated. GraphicMaster series are built so that the user only has to fold up the table, rather than It is displayed in ‘Hours : Minutes’ format and “:” will flash every 0.5 seconds. taking off the table, in order to load the laminating films on the unit.

  • Page 12: Safety Device

    Once the Photo-eye Interrupt message appears, operator can not run the unit by pressing 1” PRONEX UV Cold Film from GMP. Peel off the liner from top edge of ‘START’ button anymore. Start running the unit by using foot switch or by removing the the film and fold up at about 1”(25mm)

  • Page 13: Lamination Guide

    10 mm 10mm Mount There may be improper film tension. Mounting GMP laminating films will work with a minimal amount of brake tension. 15 mm 15mm Mount Use the cooling fans for long runs. 20mm Mount 20 mm If you are using photo materials, Inkjet prints, run the laminator at a higher speed.

  • Page 14: Specifications

    SPECIFICATIONS Classifications GraphicMaster-2100HR GraphicMaster-1600HR Power Consumption (Watts) 12,000 7,500 2800 x 994 x 1540 Dimension (W L H) mm 2110 x 850 x 1395 Max.Laminating Width (mm) 1670 2240 Infrared Heater Heating System Proportional Control by 8-bit Microprocessor (IR Sensor) Temperature Control Weight (kg) 1,050...
  • Page 15 Various types of displays can be created for making effective presentation by utilizing whole range of special laminating films made for graphics display from GMP. Depending on the purpose and application, selection of film material and thickness can make optimal presentation possible.
  • Page 16 OUT-DOOR DISPLAY Suitable for ColorSpan, Encad, EPSON, HP prints (COLD APPLICATION) INDOOR DISPLAY Suitable for ColorSpan, Encad, EPSON, HP prints (COLD APPLICATION) or other prints that doesn’t laminate with normal hot film or other prints that doesn’t laminate with normal hot film : 75 mic PRONEX UV COLD Sand,Matt,SoftMatt,Gloss : 75 mic PRONEX UV COLD Sand,Matt,SoftMatt MEDIA...
  • Page 17 In case of using EXCELJET inkjet media from GMP ROLL-UP DISPLAY : 150 mic CHROMONEX UV Sand,Matt,Gloss or 75mic PRONEX UV COLD Film Sand,Matt,SoftMatt,Gloss BOTTOM : Inkjet Print on 75mic JETEL-LIGHT PROTECT media POP -UP DISPLAY : 150 mic CHROMONEX UV Sand,Matt,Gloss or...
  • Page 18 Lamination Guide for Graphic & Displays LEADERS IN LAMINATION TECHNOLOGY Copyright GMP 2001. All rights reserved. Reproduction by any means of any image in this catalogue is prohibited without the prior consent of GMP and its authroized agent...
