- Page 1 U U ser manual BOX Panorama 65 Serial number: Version number : 01- 347422 Production date: Date: 01-11- 2018...
- Page 2 Barbas Bellfires BV. This document could contain technical inaccuracies or typographical errors. Barbas Bellfires BV reserves the right to revise this document from time to time in the contents thereof.
-
Page 3: Table Of Contents
Contents C C ontents Declaration of Performance..............5 BOX Panorama 65........................5 BOX Panorama 65 with wood log storage module..............6 BOX Panorama 65 with support frame..................7 The Clean Air Act 1993 and Smoke Control Areas........8 About this document................9 How to work with this document............ - Page 4 Contents 1 1 1 Technical data ..................28 Warranty Terms..................29 Box Panorama 65...
-
Page 5: Declaration Of Performance
Name, registered trade name or registered trade mark Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands and contact address of the manufacturer as required pursuant to Article 11(5) -
Page 6: Box Panorama 65 With Wood Log Storage Module
Name, registered trade name or registered trade mark Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands and contact address of the manufacturer as required pursuant to Article 11(5) -
Page 7: Box Panorama 65 With Support Frame
Name, registered trade name or registered trade mark Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands and contact address of the manufacturer as required pursuant to Article 11(5) -
Page 8: The Clean Air Act 1993 And Smoke Control Areas
The Clean Air Act 1993 and Smoke Control Areas The following Barbas BOX Panorama 65 appliances have been exempted or recommended for exemption under section 21 of the Clean Air Act 1993 and can be used in accordance with the intended use as described in this manual in smoke control areas in the UK. -
Page 9: About This Document
• Do basic maintenance This document refers to the BOX Panorama 65 as 'the appliance'. This document is an essential part of your appliance. Read it carefully before you do work on the appliance. Keep it in a safe place. -
Page 10: How To Work With This Document
If you do not obey these instructions, there is a risk of damage to the equipment or to property. Note A note shows more information. Symbol Description Visual sign that there is a hazard Visual sign that there is a notice Related documentation • Installation and maintenance manual • User manual Box Panorama 65... -
Page 11: Description
Flue connection The connection to the flue system that extracts the flue gases. Primary air inlet Combustion air supply through the grate into the combustion cham- ber. The function of primary air is to start the fire. Box Panorama 65... - Page 12 Steel plate in the top of the combustion chamber above the lower baf- Lower baffle Ceramic plate in the top of the combustion chamber External combustion Provides the appliance with combustion air. This option is only availa- air inlet (optional) ble when ordered with the appliance. Box Panorama 65...
- Page 13 Description T T able 3: Back view (for BOX Panorama 65 with optional support frame) Item Description Support frame The optional support frame carries the appliance when put on a wall Cover Cover to protect the wall from heat radiation...
-
Page 14: Intended Use
Provides the appliance with combustion air. This option is only availa- tion air inlet ble when ordered with the appliance. Slots Only for BOX Panorama 65 with optional support frame. The slots make sure the appliance is in the correct position on the support frame. Intended use The appliance is intended for indoor use to heat the room wherein it is installed. -
Page 15: Safety
Do not use the appliance in case of visual glass damage. • Make sure that the appliance is installed correctly. Refer to the Installation and Maintenance manual. You can find the manuals on www.barbas.com. • Wear the glove and use the operating hook or a poke when refilling the appliance •... - Page 16 Dispose of ceramic heat-resistant glass as household waste. Do not dispose of ceramic heat-resistant glass in a glass recycling container. • Dispose of an obsolete appliance according to instructions of the authorities or the fitter. • Obey the local regulations. 1 1 6 Box Panorama 65...
-
Page 17: Fuel
The above listed amount burns for approximately 45 minutes. This time can be different, dependent on the chimney draught and the position of the combustion air valve. The amount of fuel specified here should not be exceeded, overloading can cause excess smoke. Box Panorama 65... -
Page 18: Operation
Make sure there is sufficient ventilation in the room in which the appliance is installed. Note: The appliance has a heat-resistant coating. When you use the appliance for the first time, the coating can cause an unpleasant, but harmless smell. Box Panorama 65... -
Page 19: Firing The Appliance
Put minimum 4 wood logs crosswise on the floor of the combustion chamber. Put some kindling wood and 1 or 2 firestarter cubes on top of the wood logs. Put some kindling wood above the firestarter cubes. Box Panorama 65... -
Page 20: Reload With Fuel
After ignition of the fuel, move the control lever to the left to a position that gives a quiet burning fire. 8.3.3 Control the burn process Control the burn process with the control lever. This lever controls the amount of primary combustion air and both the secondary combustion air and airwash amount. Box Panorama 65... -
Page 21: Increase The Flue Draught
8.3.4 Increase the flue draught Warning: Do the procedure hereunder when you have made sure the appliance has cooled down and there are no glowing embers. Box Panorama 65... - Page 22 Unscrew the socket screw. Make sure the nut stays attached to the socket screw. Push up (1) the front of the heat shield and pull it forward (2) and move downward to a vertical position (3). Remove the upper baffle from the appliance. 2 2 2 Box Panorama 65...
-
Page 23: General Firing Tips
• After the first load, do not overload the appliance with fuel. Refer to for the recommended amount of fuel. Too much fuel leads to incomplete combustion, soot formation and a chance of a chimney fire. Box Panorama 65... -
Page 24: Maintenance
Use only: • neutral cleaning liquids • soft cloth or sponge Tip: Remove the 2 side log guards before cleaning the 2 side glasses. Box Panorama 65... - Page 25 Maintenance Make sure that the glass is dry. Water droplets can leave a mark on the glass. N N ote: Damaged or broken glass must be replaced before the appliance can be used again. Box Panorama 65...
-
Page 26: Troubleshooting
Do the recommended ignition when the door of the combus- procedure. Refer to chapter tion chamber is open 8.3.1 • Remove one or more break out strips from the upper baffle. 8.3.4 Refer to chapter • Contact your installer. Box Panorama 65... - Page 27 The underpressure in the in- Reduce the underpressure, for ex- stallation room is too high ample by opening a ventilation opening in the installation room. Box Panorama 65...
-
Page 28: Technical Data
Technical data 1 1 1 Technical data Name Barbas Model BOX Panorama 65, BOX Panorama 65 with wood log storage module, BOX Panorama 65 with sup- port frame Tested in accordance with EN 13240:2001-A2:2004 EN 16510-1 annex D, E, F... -
Page 29: Warranty Terms
Complaints will only be accepted if they are reported to the Barbas dealer, together with the serial number of the Barbas appliance which is stated on the front of the instructions for use. In addition, the original receipt (invoice, receipt, cash receipt) showing the date of purchase must also be submitted. - Page 30 Article 5: Warranty period This warranty will only be granted during the warranty period. The body of the Barbas appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase. For other parts of the Barbas appliance, a similar warranty applies from the moment of purchase for a period of one year.
- Page 31 Warranty Terms Box Panorama 65 3 3 1...
- Page 32 Y Y our Barbas dealer 001 - 011118 - 347422...
