  • Page 1 Installation User Guide GPON OLT P1200-08 Version: V1.0...
  • Page 2 Specifications are subject to change without notice. is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-Link Technologies Co., Ltd.
  • Page 3: Table Of Contents

    CONTENTS 1 Product Introduction ........................1 Brief Introduction ......................1 Functional Features ....................... 1 Appearance and Interface ....................2 2 Pre-Installation Preparation ......................4 Power Requirement ....................... 4 Equipment Ground ......................4 Room Design Requirements ..................4 3 Hardware Installation ........................4 Open package and checkout ..................
  • Page 4: Product Introduction

    Standalone 1U 8PON compact design of OLT products P1200-08 provides 8 GPON ports, 8 uplink GE optical ports + 8 uplink GE electric ports, 10 Gigabit card expansion slot provides 2*10Gigabit SFP+ uplink port. Each PON port supports 128 ONT, total 1024 ONT for one chassis. Support dual power supply redundancy, 220VAC and -48VDC mixed.
  • Page 5: Appearance And Interface

    OLT on ONT configuration, fault diagnosis, performance and security management. 1.3 Appearance and Interface The P1200-08 1U high Pizza-Box, can be mounted into the standard 19” rack. Demission of machine frame: 440mm (L)*391mm (W)*44mm (H). As shown below:...
  • Page 6 Slow Flash ALARM More than three fan doesn’t work Fast Flash All the fan work Figure 1-3 Back View of P1200-08 Item Specification One, it's in the left of the front panel and is used to grounding for machine Grounding Terminal...
  • Page 7: Pre-Installation Preparation

    optional Support Pluggable type two power module. You can chose AC or DC power Power module supply, optional 2 Pre-Installation Preparation 2.1 Power Requirement The input voltage must be stable, no EMI noise and distortion. When use DC power supply, the input voltage is -48VDC, the allowed range is -36 ~ -72 VDC. When use AC power supply, the input voltage is 110/220VAC, the allowed range is 90 ~ 264VAC.
  • Page 8: Pre-Installation Preparation

    AC power line or DC power line according to user requirement   RJ-45-to-DB-9 console cable 3.2 Pre-installation Preparation Verify the following working environment and installation requirements 1. Power Supply Requirement: - DC power supply: –48V DC, the allowed range:-36VDC~ -72 VDC - AC power supply: 110/220V AC, the allowed range: 90 ~ 264VAC 2.
  • Page 9: Port And Connection

    Front Panel Figure 3-1 Rack installation The installation process is as follows: Step I: Pre-Installation Validation Ensure the cabinet is fixed and the installation location of the OLT device in the cabinet is well  arranged, and no obstacles inside the cabinet and the surroundings affecting the installation of the device exist.
  • Page 10: Pon Port Connection

    3.4.2 PON Port Connection P1200-08 support eight GPON SFP slots, every SFP GPON slots can mount a GPON SFP module and provides one PON port. Caution: When insert into optical cable, please confirm the connector is inserted into the...
  • Page 11: Ground Cable Connection

    OLT and the ODN networking. 3.4.3 Ground Cable Connection Ensure the safety and reliable working of OLT. P1200-08 should be connected with the ground if necessary. Grounding screws are located in the rear panel. While connecting, you should use screwdriver to loosen the grounding screw first, then connect the ground cable, finally tighten the screws.
  • Page 12: Power Supply

    3.4.5.1 Connecting the AC Power Cable The two AC power supply units in the P1200-08 allow for 1 + 1 power redundancy. If one power supply unit fails, then the system will continue to operate using the remaining power supply unit.
  • Page 13: Olt Working Status Checkout

    3.5.3 Network Management Checkout Local Command Line Interface Management: Use the RJ45/DB9 Serial Port cable (in package) to link management PC with P1200-08 CONSOLE or MGMT port. Management computer can access to OLT equipment from Super terminal interface of the PC for configuration.
  • Page 14: Console Parameter Configuration

    IP Address: 192.168.1.100 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.1.1 4.2 CONSOLE Parameter Configuration Band Rate: 9600 Data Bit: 8 Parity Check: NO Stop Bit: 1 Flow Control: NO 4.3 Default Username and Password Local Command Line Username: root Password: admin 5 Appendix: OLT Specification Item Specification...
  • Page 15 Transmission Distance :20KM, PON port speed: Downstream Data Rate: 2.5Gbps, Upstream Data Rate: 1.25Gbps, Wavelength: 1490nm TX,1310nm RX, Connector: SC, PON Port Specification Fiber Type: 9/125μm SMF, TX Power: +1.5 ~ (Apply to C-Data PON module) +5dBm, Rx Sensitivity: -28dBm, Saturation Optical Power: -8dBm Management Mode Support for state monitoring, configuration...
