Quick Start Guide
1. a. Connect receiver to power source.
b. Connect receiver to mixer or amplifier. Press the power button to turn on the receiver.
2. Press group button on receiver to perform a group scan.
3.
a.
Install batteries and turn on transmitter.
b. On the transmitter, set the group and channel to match the receiver. The RF bars and battery LED on the receiver should illuminate.
©2017 Shure Incorporated
ANTENNA B
POWER
ANTENNA B
POWER
MIC OUT
INSTRUMENT OUT VOLUME
ANTENNA A
group
(A-Y)
group
channel
(A-Y)
(9-0)
MIC OUT
INSTRUMENT OUT VOLUME
ANTENNA A
BLX4R
BLX4R Quickstart
BLX4R
group
channel
(A-Y)
(9 -0)
1/2
