Carryout
CARRYING
HANDLE
TWIST OFF
CAP
ONE OF TWO
LOCKING CLIPS
TIE DOWN
IMPORTANT:
When preparing the Carryout
MP1 for storage, be sure to
tighten both elevation knobs
to lock the reflector in the
DOWN position. This will help
protect it while you travel.
WINEGARD
MP1 Portable Satellite TV Antenna
®
Model GM-MP1
U.S. Patent Pending
AZIMUTH
ROTATION
LOCK
ONE OF TWO
®
ELEVATION
KNOBS
ROTATION
BEARING
Winegard Company • 3000 Kirkwood St. • Burlington, IA 52601-2000
800/788-4417 • FAX 319/754-0787 • www.winegard.com
Printed in U.S.A. © Winegard Company 2009 2452191 REV1 1/10
TOP
ELEVATION
MARKINGS
HANDLE AS IT CAN DAMAGE
BASE
REFLECTOR
BUBBLE
LEVEL
®
WARNING:
DO NOT USE LNBF AS A
THE SYSTEM.
LNBF
BASE
COMPASS
