OMNIDIRECTIONAL TV/FM ANTENNA
NOTE: Please read all instructions before beginning installation!
To prevent FIRE or SHOCK HAZARD, avoid exposure of power
supply to moisture.
PARTS LIST
1. (1) Antenna
2. (1) 15' RG-6 Low Loss Coax Cable
3. (1) Cable Tool
4. (1) Power Supply RV-7542
5. (1) 5' Power Harness
6. (4) 1/4-20 Nylock Hex Nuts
7. (4) 1/4-20 Carriage Bolts
8. (2) Insulated Quick-Disconnect
Terminals
9. Mount
10. (4) Lag Screws 1/4" x 1/4"
11. (4) Washers 1/4"
12. (1) Roof Gasket
13. (1) Cable Gasket Plug
14. (1) Antenna Gasket
15. Stem Mount
TOOLS NEEDED
#2 Phillips screwdriver
7/16" wrench
Crimping tool
Medium slot screwdriver
Cable tool (provided)
Wire stripper
Winegard Company • 3000 Kirkwood Street • Burlington, IA 52601 • 319/754-0600 Fax 754-0787 • www.winegard.com
WINEGARD
MODEL RS-1500
WARNING!
#1. ANTENNA
#8. CARRIAGE
BOLT
#14. ANTENNA
GASKET
#10. LAG SCREWS
#11. WASHERS
#15. STEM MOUNT
#12. ROOF GASKET
#8. INSULATED QUICK
DISCONNECT TERMINALS
#2. COAX CABLE
#3. CABLE TOOL
#5. 5' POWER HARNESS
Printed in U.S.A. © 2002 Winegard Company 2451233
®
#6. NYLOCK HEX NUT
#4. POWER SUPPLY
& screws (2)
#13. CABLE
GASKET PLUG
Advertisement
Related Manuals for Winegard RS-1500
Summary of Contents for Winegard RS-1500
- Page 1 Medium slot screwdriver #2. COAX CABLE Cable tool (provided) Wire stripper #3. CABLE TOOL #5. 5’ POWER HARNESS Winegard Company • 3000 Kirkwood Street • Burlington, IA 52601 • 319/754-0600 Fax 754-0787 • www.winegard.com Printed in U.S.A. © 2002 Winegard Company 2451233...
- Page 2 BEFORE YOU MOUNT ANTENNA: 2. Pull the cable down until the end of the connector is flush with the hex-shaped end of the cable tool. See Decide location of power supply before Figure 3. mounting your antenna. A wiring diagram, Figure 1, will help you determine the location for your power supply and antenna.
-
Page 3: Wiring Diagram
CONNECTING POWER SUPPLY FIGURE 6 1. Select location for power supply. Run two coax cables AUXILLIARY (three if Set 2 jack is going to be used) (RG-59 type) between locations and install connectors on each end. Mark cables so SATELLITE RECEIVER "cable input", "TV output"... - Page 4 3000 Kirkwood Street, Burlington, IA 52601-2000, Telephone 319-754-0600). Winegard Company (at its option) will either repair or replace the defective product at no charge to you. This warranty covers parts, but does not cover any costs incurred in removal, shipping or reinstallation of the product. This limited warranty does not apply if the product is damaged, deteriorates, malfunctions or fails from: misuse, improper installation, abuse, neglect, accident, tampering, modification of the product as originally manufactured by Winegard, usage not in accordance with product instructions or acts of nature such as damage caused by wind, lightning, ice or corrosive environments such as salt spray and acid rain.
