1. Pass the control cable and the cold-
device cable from the PrograMill Suction
Unit (included in the delivery of the
PrograMill Suction Unit) through the
energy chain and out through the
opening (1).
2. Pass the tube connected to the
separator of the PrograMill Suction Unit
(2.5 m, included in the delivery of the
PrograMill Suction Unit) out through
the opening (2) to be connected to the
milling machine.
3. Pass the water outlet tube connected to
the PrograMill Tank (included in the
delivery of the PrograMill milling
machine) out through the opening (3)
to the outside.
4. Pass the water intake tube connected to
the PrograMill Filter (included in the
delivery of the PrograMill milling
machine) through the energy chain and
out through the opening (4).
5. Connect the cables and tubes to the milling machine.
6. Push the pull-out shelf by the handles into the PrograMill Base and fasten the locks.
7. If necessary, place other PrograMill accessories into the PrograMill Base cabinet
("Suggestion for the placement of items within the drawer", page 15).
Initial Operation
1
2
3
4
