Design and Function
No. Description
1 Pull-out shelf with indentations (in the
illustration part of the front panel has
been faded out for better visibility)
2 Exhaust air outlet
3 Service wheels
4 Drawer
5 Storage space
6 Indentations for device feet
7 Tube and cable access
8 Handle
9 Tube holder
10 Lock
11 Device feet
12 Energy chain
13 Wheels
14 Crossbeam
14
Function
• Holds the PrograMill Suction Unit
• The indentations ensure proper
positioning of PrograMill Suction
Unit
Removal of exhaust air to the
PrograMill Suction Unit
Only for the service partner
Storage of tools, discs / blocks and
cleaning agents
Position for the milling machine
Secure positioning of the milling
machine on the PrograMill Base
Cable and tube guides
Pulling the shelf out and pushing it
back in
The water outlet tube and the water
inlet tube are attached in the tube
holder during cleaning and
maintenance work
Securing the pull-out shelf against
unwanted movement
Height adjustment of the PrograMill
Base cabinet
• Laying cables and tubes
• Kink protection for cables and tubes
Pulling the shelf out and pushing it
back in
Ensures the stability of the PrograMill
system
