9. List of control commands
The Anemometer 2D can be controlled via its serial data interface using the commands in the following list.
Any standard terminal program such as "procomm" , "telix" or a Windows terminal program (e.g. "Hyper
Terminal" ) can be used.
All adjustments are stored in a E²ROM so that the adjusted parameters cannot get lost after switching
off or failure of power supply.

9.1 List of commands

Command
<ID> AM 00000 Vectorial averaging
<ID> AM 00001 Scalar averaging
<ID> AM 00002 Scalar / vectorial averaging
<ID> AM 00003 Vectorial / Scalar averaging
<ID> AV 00000 Instantaneous value
<ID> AV 00001 Mean value over 1 second
<ID> AV 00002 Mean value over 10 seconds
<ID> AV 00003 Mean value over 1 minute
<ID> AV 00004 Mean value over 2 minutes
<ID> AV 00005 Mean value over 10 minutes
<ID> BR 00002 1200 Baud N 8 1
<ID> BR 00010 1200 Baud E 7 1
<ID> BR 00003 2400 Baud N 8 1
<ID> BR 00011 2400 Baud E 7 1
<ID> BR 00004 4800 Baud N 8 1
<ID> BR 00012 4800 Baud E 7 1
<ID> BR 00005 9600 Baud N 8 1
<ID> BR 00013 9600 Baud E 7 1
<ID> BR 00006 19200 Baud N 8 1
<ID> BR 00014 19200 Baud E 7 1
<ID> DM 00000 Duplex mode half duplex
<ID> DM 00001 Duplex mode full duplex
<ID> ES 00000 Sign-echo switched off
<ID> ES 00001 Sign-echo switched on
<ID> KY 00000 Key, no access
<ID> KY 00001 Key, open access
<ID> MT 00000 Measurement trigger off
<ID> MT 00001 Measurement trigger on
<ID> LT 00000 Interface selection
<ID> LT 00001 Interface-selecting
<ID> NC 00xxx North correction in 1°
<ID> OR 00xxx Output rate online (
<ID> OS 00000 Wind speed in m/s
<ID> OS 00001 Wind speed in Km/h
<ID> OS 00002 Wind speed in mph
<ID> OS 00003 Wind speed in Knots
<ID> SC 00000 Start value of current 0mA
<ID> SC 00001 Start value of current 4mA
<ID> TR 00000 no Telegram on request
<ID> TR 00001 Telegram VD on request
<ID> TR 00002 Telegram VDT on request
<ID> TR 00003 Telegram V4DT on request
<ID> TR 00004 Telegram NMEA on request
<ID> TT 00000 No telegram output
<ID> TT 00001 Telegram VW spontaneous
<ID> TT 00002 Telegram VDT spontaneous
<ID> TT 00003 Telegram V4DT spontaneous
<ID> TT 00004 Telegram NMEA V 2.0
Remark:
Function
)
spontaneous
9 -12
Vectorial averaging of wind speed and direction
Scalar averaging of wind speed and direction
Scalar averaging of speed / vectorial averaging of direction
Vectorial averaging of speed / scalar averaging of direction
Output of the instantaneous values
Output of the gliding mean value over 1 second
Output of the gliding mean value over 10 seconds
Output of the gliding mean value over 1 minute
Output of the gliding mean value over 2 minutes
Output of the gliding mean value over 10 minutes
Data rate 1200 Baud, 8 Data bits, No Parity, 1 Stop bit
Data rate 1200 Baud, 7 Data bits, Parity Equal, 1 Stop bit
Data rate 2400 Baud, 8 Data bits, No Parity, 1 Stop bit
Data rate 2400 Baud, 7 Data bits, Parity Equal, 1 Stop bit
Data rate 4800 Baud, 8 Data bits, No Parity, 1 Stop bit
Data rate 4800 Baud, 7 Data bits, Parity Equal, 1 Stop bit
Data rate 9600 Baud, 8 Data bits, No Parity, 1 Stop bit
Data rate 9600 Baud, 7 Data bits, Parity Equal, 1 Stop bit
Data rate 19200 Baud, 8 Data bits, No Parity, 1 Stop bit
Data rate 19200 Baud, 7 Data bits, Parity Equal, 1 Stop bit
Half duplex, 2-wire operation
Full duplex, 4-wire operation
Echo operation of transmitted characters switched off
Echo operation of transmitted characters switched on
Software-key, access to EEPROM closed
Software- key, access to EEPROM open
No synchronization of measurement onto request poss.
Synchronization of measurement onto request possible
Interface standard RS 485 (RS 422)
Interface standard RS 232
Input of north correction, value range 00000 up to 00360
Output rate xxx times 100ms, value range 00001 up to 00255
Scale of Wind speed in meter per second
Scaling of Wind speed in kilo meter per hour
Scaling of Wind speed in miles per hour
Scaling of Wind speed in knots (nautically)
Analogue output current 0 - 20mA / 0 – 10 V
Analogue output current 4 - 20mA / 2 – 10 V
single output of the telegram form, see 6.1.1
single output of the telegram form, see 6.1.2
single output of the telegram form, see 6.1.3
single output of the telegram form, see 6.1.4
Online output of telegram form, see 6.1.1
Online output of telegram form, see 6.1.2
Online output of telegram form, to 6.1.3
Online output of telegram form, to 6.1.4
Remark
