5.9.4 Bay Roles

Each of the drive bays can be configured as a Master, Target, or both Master/Target. Tap
a drive bay, then tap the Edit Role icon to assign the specific drive bay

5.10 Network Settings

The Network settings screen has the following tabs: Services, Interfaces and HTTP
Proxy. The Services tab allows certain services to be enabled or disabled. The
Interfaces tab allows the configuration of the network interface which include setting a
static IP (DHCP is set by default) and allows certain services to be enabled or disabled.
There is also an HTTP Proxy tab where proxy server information can be entered.
Logicube ZClone™Xi User's Manual
After changing the bay role, it is highly recommended to save the
settings into a profile, load that profile, then reboot. See
for more information on saving and loading a profile.
TYPES OF OPERATIONS
Section 5.9.1
