1.11 SDI Video Format

E
Output Signal
SMPTE-274M
SMPTE-296M
SMPTE-260M
SMPTE-125M
ITU-R BT.656

1.12 VGA (15 Pin D-Sub)

Pin No.
1
2
3
4
5 DDC 5V Standby Cable
6
7
8
1080i (60 / 59.94 / 50)
1080p (30 / 29.97 / 25 / 24 / 24sF / 23.98 / 23.98sF)
720p (60 / 59.94 / 50)
1035i (60 / 59.94)
480i (59.94)
576i (50)
Assignment Pin No.
Red
Green
Blue
Ground
Connection Check
Ground-Red
Ground-Green
Ground-Blue
Description
Assignment
9 No Connection
10 Ground-Sync
11 Ground
12 DDC Data
13 H.Sync
14 V.Sync
15 DDC Clock
E-30
1 5
6 10
11 15
