ZOOM / PAN
Controls the zoom in / out of the image.
RESET
Reset the unit to factory outgoing status
AUTO SOURCE
When AUTO SOURCE SELECT is on, the monitor automatically
SELECT
searches input source, except PIP sub source
USER NAME
Put User's name, etc. into Preset
ENTRY
PIP LAYOUT
Change sub window layout (SINGLE, PIP, PBP1, PBP2)
PIP: Main/Sub window doesn't change aspect ratio
PBP1: Main/Sub window doesn't change aspect ratio
PBP2: Main/Sub window H/V display 1:1 size
0:
3:
6:
Controls the PAN in / out of the image
NOTICE: Maximum ZOOM size is ten times as large
E-27
1: 2:
4: 5:
7: 8:
as original size
E
