F-18 Modbus RTU Communications Protocol
Command
Code Function
29 Reset Data
Regions
30 Control Remote
Bits
Note Command Code 30–Control Remote Bits
This code controls the remote bits. This command code has two parameters:
Parameter 1 determines the bit operation.
Parameter 2 determines which bit to control. It is bitmasked for future expansion, but only one bit can
be controlled at a time. The highest numbered bit will be controlled if more than one bit occurs in the
parameter.
Bit Pattern
0000 0000 0000 0001
0000 0000 0000 0010
0000 0000 0000 0100
0000 0000 0000 1000
0000 0000 0001 0000
0000 0000 0010 0000
0000 0000 0100 0000
0000 0000 1000 0000

Error Codes

In addition to the error codes returned for function codes 06h or 10h, the following error codes
are returned for command codes.
•
If the relay is disabled or if the breaker jumper is not installed while the commands 1–4 and
7–26 are issued, the relay will return error code 04 (device error).
•
If the relay is disabled while Reset Targets command (05) is issued, the relay will return
error code 04h (device error).
Date Code 20060731
Parameter Definition
0000 0000 0000 0001 Demand Metering
0000 0000 0000 0010 Peak Demand Metering
0000 0000 0000 0100 Energy Values
0000 0000 0000 1000 Max/Min meter values
0000 0000 0001 0000 Breaker Monitor
0000 0000 0010 0000 History Buffer (history
0000 0000 0100 0000 Targets
0000 0000 1000 0000 Sync Check
0000 0001 0000 0000 SER
0000 0010 0000 0000 Communication
0000 0100 0000 0000 Profiles
See Note
Value Operation
1 Set
2 Clear
3 Pulse (1/4 cycle)
Remote Bit
RB1
RB2
RB3
RB4
RB5
RB6
RB7
RB8
and events)
Counters
Bit Pattern
0000 0001 0000 0000
0000 0010 0000 0000
0000 0100 0000 0000
0000 1000 0000 0000
0001 0000 0000 0000
0010 0000 0000 0000
0100 0000 0000 0000
1000 0000 0000 0000
SEL-300G Instruction Manual
Modbus
Function Code
06h, 10h
06h, 10h
Remote Bit
RB9
RB10
RB11
RB12
RB13
RB14
RB15
RB16
