USER MANUAL
CCI2100HW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCI2100HW and is the answer not in the manual?

Questions and answers

Related Manuals for Costar Video Systems CCI2100HW

Summary of Contents for Costar Video Systems CCI2100HW

  • Page 1 USER MANUAL CCI2100HW...
  • Page 2 1 Introduction The network camera supports the network service for a sensor image with progressive scan, which can be monitored on a real-time screen regardless of distances and locations. By using its dedicated program, many users are able to have an access to the network camera at once or a single user can monitor various network cameras at the same time.

  • Page 3: Installation

    2 Installation 2.1 Basic Configuration of Camera System The camera must be installed by qualified service personnel in accordance with all local and federal electrical and building codes. Description 12VDC AUDIO IN AUDIO OUT C/CS Mount Camera ALARM IN ALARM OUT VIDEO OUT(CVBS) NETWORK / PoE DC - IRIS...
  • Page 4 • Installing Camera Mounting Brackets (Optional)
  • Page 5 • Dimension < CS mount >...

  • Page 6: Micro-Sd Card Insertion

    2.2 Micro-SD Card Insertion • Micro SD memory card insertion User can install and change Micro-SD card as shown in the following picture.
  • Page 7 2.3 Connections • Connecting the Network Connect a standard RJ-45 cable to the network port of the camera. Generally a crossover cable is used for directly connecting to a PC, while a direct cable is used for connection to a hub. •...

  • Page 8: Network Connection & Ip Assignment

    2.4. Network Connection & IP assignment The camera supports operation through the network. When a camera is first connected to the network, it is necessary to allocate an IP address to the device with the SmartManager utility on the CD. (Default IP 192.168.0.129) 1) Connect the network camera/device to the network and power up.

  • Page 9: Operation

    3 Operation The network camera can be used with Windows operating system and browsers. The recommended browsers are Internet Explorer, Safari, Firefox, Opera and Google Chrome with Windows. NOTE: To view streaming video in Microsoft Internet Explorer, set your browser to allow ActiveX controls.

  • Page 10: Access From The Internet

    3.2 Access from the internet Once connected, the network camera is accessible on your local network (LAN). To access the network camera from the Internet you must configure your broadband router to allow incoming data traffic to the network camera. To do this, enable the NAT traversal feature, which will attempt to automatically configure the router to allow access to the network camera.

  • Page 11: Live View Page

    3.4 Live View Page The Live View page comes in several screen modes: 1920x1080, 1280x1024, 1280x720(960), 1024x768, 704x480(576), 640x480(360) and 320x240. Users are allowed to select the most suitable mode for their application needs. Adjust the mode in accordance with your PC specifications and monitoring purposes.
  • Page 12 2) Control toolbar The live viewer toolbar is available in the web browser page only. It displays the following buttons: The Stop button stops the video stream being played. Pressing the key again toggles the play and stop. The Play button connects to the network camera or starts playing a video stream. The Pause button pauses the video stream being played.
  • Page 13 3.5 Playback The Playback window contains a list of recordings made to the memory card. It shows each recording’s start time, length, the event type used to start the recording, calendar and time slice bar indicates if the recording exists or not. The description of playback window follows.
  • Page 14 3) Time Chart Display an hour-based search screen for the chosen date. If there is recorded data, a blue section will be displayed on a 24-hour basis. If you select a particular hour in the chart, a yellow square on the hour will be displayed.

  • Page 15: Network Camera Setup

    3.6 Network Camera Setup This section describes how to configure the network camera. Administrator has unrestricted access to all the Setup tools, whereas Operators have access to the settings of Basic Configuration, which are Live View, Video & Image, Audio, Event, Dome Configuration, and System.

  • Page 16: Resetting To The Factory Default Settings

    3.7 Resetting to the factory default settings To reset the network camera to the original factory settings, go to the Setup > System > Maintenance web page (described in “System > Maintenance” of User’s Manual) or use the Reset button on the network camera, as described below: •...

  • Page 17: System Requirement For Web Browser

    System Requirement for Web Browser • Operating System: Microsoft Windows OS Series • CPU: Intel Core 2 Duo 2GHz or higher, 1GB RAM or more, 10GB free disk or higher • VGA: AGP, Video RAM 32MB or higher (1024x768, 24bpp or higher) General Performance Considerations When setting up your system, it is important to consider how various settings and situations will affect performance.
  • Page 18 Compression H.264(Baseline, Main, High Profile), MJPEG Bitrate Control CVBR, VBR 1920x1080, 1280x1024, 1280x720/960, 1024x768, 704x480/576, Resolution 640x360/480, 320x240 Frame Rate Max. 50fps/60fps 50/60fps (Dual Stream : H.264 x 1, MJPEG x 1) Streaming 25/30fps (Triple Stream : H.264 x 2, MJPEG x 1) Composite Out Yes(25/30fps Mode)
  • Page 19 Full-HD NETWORK SQUARE CAMERA 50303998B...
