- Page 1 Network Camera Installation Manual...
- Page 2 Before reading this manual This is a basic installation manual for use of a network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
- Page 4 Before reading this manual Warning: This product emits infrared light. Do not look into the IR LED. FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
-
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
Part 1 – Introduction Product Features • Supports H.265 and H.264 video compression and M-JPEG still image compression algorithms • Supports 4-stage video compression rate and This camera is an IP-based network camera that multiple compression resolutions compresses and transmits video over ethernet. •... - Page 7 Part 1 – Introduction • Easy network access via UPnP (Universal Plug and • Backup storage on a microSD memory card as Play) function and embedded mDNS (Multicast DNS) a safeguard against data loss during network protocol interruptions • Wide dynamic range compensation (True WDR) for •...
-
Page 8: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. Network Camera Terminal Blocks (2 ea.) Guide Pattern Quick Guide Allen Wrench Screws (3 ea.) Desiccant CVBS Cable Protect Connector (1 ea.) -
Page 9: Overview
Part 1 – Introduction Overview Dome Cover & Horizontal Rotator IR LED Safety Wire Vertical Rotator Lens Rotator • Safety Wire Prevents the dome cover from falling on to the floor Lens when detached from the camera. Dome Cover Assembly Part Bottom Cover Body Power... - Page 10 Part 1 – Introduction • Horizontal Rotator • Cable Rubber Used to adjust the lens' horizontal angle. Foreign matter may get inside if reconnecting is failed after removing the cable access hole rubber. • IR LED • Video Out (CVBS) A sensor in the middle monitors lighting levels and activates the IR LED during low-lighting conditions.
- Page 11 Part 1 – Introduction • Audio • Check your local laws and regulations on making - O (Out): Connect an amplifier to this port (line video or audio recordings. The user will be held out). This device does not feature a built-in audio liable for any violation of the law.
-
Page 12: Factory Reset
Part 1 – Introduction Factory Reset Lens Only use the factory reset switch to restore the camera to its factory default settings. Motorized focus and zoom lens A factory reset will clear all camera settings configured by the user. Shut off the power supply. Remove the dome cover and then press and hold the reset switch down Hold the switch down and reconnect the power... -
Page 13: Installation
Part 1 – Introduction Installation Inserting a SD Memory Card Insert a SD memory card into the SD memory card slot Installation of this product does not require the use of with the 'micro SD' print facing upward. special tools. For more information on other devices comprising the overall system, refer to their respective installation manuals. -
Page 14: Installation
Part 1 – Introduction Installation Assemble the cable rubber to the bottom cover. • Check the wall or ceiling to see if it needs to be reinforced. The camera may fall off if the wall or ceiling is not strong enough to support its weight. •... -
Page 15: Closing The Dome Cover
Part 1 – Introduction Closing the Dome Cover Fasten the screws for the dome cover clockwise using the allen wrench provided with the camera. Connect external devices, the network cable, and the power adapter. Remove the protective film inside and outside before Adjust the angle. -
Page 16: Angle Adjustment
Part 1 – Introduction Angle Adjustment Dimensions The lens can be rotated along three axes. Ø 160mm (6.3") Lens Rotation Horizontal Rotation Vertical Rotation • Lens Rotation Used to adjust the lens' rotation angle. Turn the lens rotator in the clockwise or counterclockwise direction. •... -
Page 17: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectNET™ NVR or non DirectNET™ NVR, VMS such as INEX Basic. With DirectNET™ NVR-based Layout Audio In Audio Out Alarm Out Power Sensor In Network Camera Monitor Out Power Remote Monitoring DirectNET™... -
Page 18: With Non Directnet™ Nvr-Based Layout
Part 2 - Camera Connection With non DirectNET™ NVR-based Layout Sensor In Audio In Alarm Out Audio Out Network microSD Memory Card Network Camera Remote Monitoring (INEX Basic or WebGuard) Remote Recording (INEX Basic) Control the camera over the network from software installed on a computer. Ideal for using the camera over the network from a remote location. -
Page 19: Part 3 - Appendix
Part 3 - Appendix Troubleshooting Problem Check The main unit won't turn • Check the power cable connection. If using a PoE switch to supply power to the camera using an ethernet cable, check the ethernet cable connection. • Check the power outlet. If using a PoE switch to supply power to the camera using an ethernet cable, check the PSE device's power supply. -
Page 20: Specifications
Part 3 - Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/3" CMOS Max. Resolution 1920 x 1080 Scanning Mode Progressive Scan Lens type Motorized Vari-focal Focal Length f=2.8 - 12mm Aperture F=1.6 Iris Control P-Iris Angular Field of View Wide : 98°(H) x 52°(V) x 116°(D) - Page 21 Part 3 - Appendix Network Video Compression H.265, H.264(MP), M-JPEG Bitrate Control CBR / VBR Max. Frame Rate 60ips : 1920 x 1080 30ips : 1920 x 1080(WDR) Audio Compression G.726, ADPCM-16K, G.711u-Law, G.711a-Law, ADPCM 16K Supported DirectNET 1920x1080, 1280x720, 704x480, 640x360, 352x240 Resolution Non DirectNET 1920x1080, 1280x720, 704x480, 640x360, 352x240...
- Page 22 Part 3 - Appendix General Vandal Resistance Out-door Ready IP67, Heater Operating Temperature -40°C ~ +60°C (-40°F ~ +140°F) Boot Up Temperature -20°C ~ +60˚C (-4°F ~ +140˚F) Operating Humidity 0% ~ 90% Power Source , PoE(IEEE 802.3af, Class3) Power Consumption Max.
