- Page 1 Network Camera Quick Guide...
-
Page 2: Safety Precautions
Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read before the Do not overload wall outlets and extension cords as this can result appliance is operated. -
Page 3: Fcc Compliance Statement
FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. - Page 4 Overview • Product color and design may vary depending on the model. • For more details on each part name, refer to the operation manual. Body Heater Supported Model Vandal Dome IR LED Supported Vandal Dome IR LED Non- Model Supported Model Plastic Dome IR LED Supported Plastic Dome IR LED Non-Supported...
-
Page 5: I/O Device Port
Camera Installation I/O Device Port Removing the Dome Cover Vandal Dome Model Loosen the screws counterclockwise using the allen wrench provided with the product. Network Port FGND (Frame Ground) Video Out Audio In/Out Power Alarm In/Out Remove the dome cover. Plastic Dome Model Insert a flat-head screwdriver into the groove indicated by the triangle mark on the dome cover,... -
Page 6: Installation
Inserting a SD Card Installation Check the wall or ceiling to see if it needs to be Vandal Dome Model reinforced. The camera may fall off if the wall or Insert a SD card into the SD card slot with the ‘micro SD’ ceiling is not strong enough to support its weight. -
Page 7: Closing The Dome Cover
Closing the Dome Cover Plastic Dome Model Turn the camera body to align the protrusion on its back with the base's reference point. Vandal Dome Model Attach the dome cover to the bottom cover. If the protrusions are not aligned with each Fasten the screws for the dome cover clockwise other, the screw holes are not revealed. -
Page 8: Angle Adjustment
Angle Adjustment Plastic Dome Model Attach the dome cover to the bottom cover. Vandal Dome IR LED Supported Model Vandal Dome IR LED Non-Supported Model Press the area where the triangular mark meets the side hole cable to assemble the dome cover. Plastic Dome IR LED Supported Model Plastic Dome IR LED Non-Supported Model Lens Rotation... -
Page 9: Specifications
Specifications Vandal Resistance Yes ( Vandal Dome Model only Out-door Ready Vandal Dome Model only IP66 ( Heater supported model only Heater ( Operating Temperature -10°C ~ +50°C (+14°F ~ +122°F) Heater supported model only -40°C ~ +50°C (-40°F ~ +122°F) [ Boot Up Temperature 0°C ~ +50°C (+32°F ~ +122°F) -20°C ~ +50°C (-4°F ~ +122°F) [... - Page 10 Memo...
