Summary of Contents for Costar Video Systems CDI2110VIRFH

  • Page 1 Network Camera Installation Manual...

  • Page 2: Safety Symbols

    Before reading this manual This is a basic installation manual for use of a network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.

  • Page 3: Safety Precautions

    Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.

  • Page 4: Fcc Compliance Statement

    Before reading this manual Warning: This product emits infrared light. Do not look into the IR LED. FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

  • Page 5: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 6 Product Features .

  • Page 6: Part 1 - Introduction

    Part 1 – Introduction Product Features • IP filtering, HTTPS, SSL, IEEE 802.1X, and configurable user authority levels for greater security • Network bandwidth limitation and MAT features for These cameras are IP-based network cameras that more efficient use of network bandwidth compress and transmit video over ethernet.

  • Page 7: Accessories

    Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Network Camera Ferrite Core Vandal dome model Plastic dome model Installation CD Quick Guide...

  • Page 8: Overview

    Part 1 – Introduction Overview Product color and design may vary depending on the model. Dome Cover Bottom • Vandal Dome Model • Vandal Dome Model • Plastic Dome Model • Plastic Dome Model...

  • Page 9: Body

    Part 1 – Introduction Body Dome Cover Screws Hole Safety Wire Heater Supported Model Dome Cover Screws Dome Cover Removal Groove Dome Cover Assembly Notch • Dome Cover Screws Hole For routing cables and wires. • Safety Wire Prevents the dome cover from falling on to the floor when detached from the camera.
  • Page 10 Part 1 – Introduction Vandal Dome IR LED Non-Supported Model Plastic Dome IR LED Supported Model 2 13...
  • Page 11 Part 1 – Introduction Plastic Dome IR LED Non-Supported Model IR LED Lens Wall/Ceiling Installation Hole Lens Rotator Vertical Rotation Adjustment Screw Dome Cover Screw Hole Factory Reset Switch SD Memory Card Slot Rubber Side Cable Access Hole Bottom Cover Heater Bottom Cover Securing Point Ceiling Cable Hole...

  • Page 12: Factory Reset

    Part 1 – Introduction • Dome Cover Screw Hole • Bottom Cover Securing Point Secures the dome cover to the camera. Align this reference point with the dome cover's reference point to assemble them. • Factory Reset Switch • Ceiling Cable Hole Restores the camera's default factory settings.

  • Page 13: Lens

    Part 1 – Introduction Lens Network Port Video Out Power A Motorized focus and zoom lens FGND (Frame Ground) Audio In/Out Alarm In/Out • Network Port Connect a network cable with an RJ-45 connector to this port. If using a PoE switch, you can supply power to the camera using an ethernet cable.
  • Page 14 Part 1 – Introduction • Audio In/Out – In: Connect an alarm-in device to this port. (Mechanism: Choose between an NC (Normally – Out: Connect an amplifier to this port (line out). Closed) type or an NO (Normally Open) type) → This device does not feature a built-in audio Connect a mechanical or electrical switch to the amplifier unit and therefore requires the user to...

  • Page 15: Installation

    Part 1 – Introduction Installation • Check your local laws and regulations on making video or audio recordings. The user will be held liable for any violation of the law. (Article 25-5 of Installation of this product does not require the use of the Personal Information Protection Act: Operators special tools.

  • Page 16: Inserting A Sd Memory Card

    Part 1 – Introduction Inserting a SD Memory Card Plastic Dome Model Insert a flat-head screwdriver into the groove indicated by the triangle mark on the dome cover, Vandal Dome Model and push down the screwdriver. Insert a SD memory card into the SD memory card slot with the 'micro SD' print facing upward.

  • Page 17: Installation

    Part 1 – Introduction Installation Attach the enclosed desiccant in the body to prevent moisture. • Check the wall or ceiling to see if it needs to be reinforced. The camera may fall off if the wall or ceiling is not strong enough to support its weight. •...

  • Page 18: Closing The Dome Cover

    Part 1 – Introduction Closing the Dome Cover Attach the camera body to the wall or ceiling using the installation anchors and screws provided with the camera. Vandal Dome Model Attach the dome cover to the bottom cover. Connect external devices, the network cable, and the power adapter.

  • Page 19: Angle Adjustment

    Part 1 – Introduction Angle Adjustment Plastic Dome Model The lens can be rotated along three axes. Attach the dome cover to the bottom cover. Vandal Dome IR LED Supported Model Vandal Dome IR LED Non-Supported Model Press the area where the triangular mark meets the side hole cable to assemble the dome cover.

  • Page 20: Dimensions

    Part 1 – Introduction Dimensions Plastic Dome IR LED Non-Supported Model Vandal Dome Model Lens Rotation Horizontal Rotation 150.5mm Vertical Rotation • Lens Rotation Used to adjust the lens' rotation angle. Turn the rotator in clockwise or counterclockwise direction. • Vertical Rotation Used to adjust the lens' vertical angle.

  • Page 21: Part 2 - Camera Connection

    Part 2 - Camera Connection Sensor In Audio In Alarm Out Audio Out Network Camera Network microSD Memory Card Remote Monitoring (INEX Basic or WebGuard) Remote Recording (iNEX Basic) Control the camera over the network from software installed on a computer. Ideal for using the camera over the network from a remote location.

  • Page 22: Part 3 - Appendix

    Part 3 - Appendix Troubleshooting Problem Check The main unit won't turn • Check the power cable connection. • Check the power outlet. PoE switch isn't being Check the grounding status of the I/O device connected to the camera and the PoE recognized.

  • Page 23: Specifications

    Part 3 - Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/2.8" CMOS Max. Resolution 1920 x 1080 Scanning Mode Progressive Scan Lens type Motorized Vari-focal Focal Length f=3.3mm ~ 10mm Aperture F1.3 ~ 2.5 Iris Control DC Auto Iris Angular Field of View...
  • Page 24 Part 3 - Appendix Network Video Compression H.264(MP), M-JPEG Bitrate Control H.264 - CBR / VBR Max. Frame Rate 30fps : 1920 x 1080 Audio Compression G.726, G.711 Supported Resolution 1920x1080, 1280x720, 704x480, 352x240 Multi-Video Streaming Triple Ethernet RJ45(10/100BASE-T) Edge Storage * (Optional) (micro SD/SDHC (Class 6 or above, up to 32 GB) memory card) * An SLC (Single Level Cell) or MLC (Multi Level Cell) card by SanDisk or Transcend is recommended to ensure stable recording...
  • Page 25 Part 3 - Appendix General Vandal Resistance Yes ( Vandal Dome Model only Out-door Ready Vandal Dome Model only IP66 ( Heater supported model only Heater ( Operating Temperature -10°C ~ +50°C (+14°F ~ +122°F) -40°C ~ +50°C (-40°F ~ +122°F) [ Heater supported model only Boot Up Temperature 0°C ~ +50°C (+32°F ~ +122°F)
