D.C. Inverter Multi-variable Modular

2 Product Introduction

Gree Multi VRF Modular System adopts inverter compressor technology. According to change
the displacement of compressor, stepless capacity regulation within range of 10%-100% can be
realized. Various product lineup is provided with capacity range from 22.4kW to 180kW, which can be
widely used in working area and especially applicable to the place with variable load change.Gree air
conditioner is absolutely your best choice.

2.1 Names of Main Parts

Air outlet
1
2
Air inlet
3
NO.
Name Fan, Motor

2.2 Combinations of Outdoor Units

Model
GMV-504WM/B-X
(Single)
Model GMV-224WM/B-X
(Combined) +GMV-280WM/B-X
Model
GMV-730WM/B-X
(Single)
Model GMV-280WM/B-X
(Combined) +GMV-450WM/B-X
Model
GMV-960WM/B-X
(Single)
GMV-280WM/B-X
Model
+GMV-280WM/B-X
(Combined)
+GMV-400WM/B-X
Air inlet
4 5 4 5
Electric Box
Assembly
GMV-560WM/B-X
GMV-280WM/B-X
+GMV-280WM/B-X
GMV-785WM/B-X
GMV-335WM/B-X
+GMV-450WM/B-X
GMV-1010WM/B-X
GMV-280WM/B-X
+GMV-280WM/B-X
+GMV-450WM/B-X
Air outlet
1
2
Air inlet
3
Fig.1
Power cord
Valve interface
through-hole
GMV-615WM/B-X
GMV-280WM/B-X
+GMV-335WM/B-X
GMV-850WM/B-X
GMV-400WM/B-X
+GMV-450WM/B-X
GMV-1065WM/B-X
GMV-280WM/B-X
+GMV-335WM/B-X
+GMV-450WM/B-X
3
Air outlet
Air inlet
4 5 4 5
Communication
code through-hole
GMV-680WM/B-X
GMV-280WM/B-X
+GMV-400WM/B-X
GMV-900WM/B-X
GMV-450WM/B-X
+GMV-450WM/B-X
GMV-1130WM/B-X
GMV-280WM/B-X
+GMV-400WM/B-X
+GMV-450WM/B-X
