3.2.1 When the outdoor unit is totally surrounded by walls, please refer to following
figures for space dimension.
3.2.1.1 Space dimension for single-module unit
3.2.1.2 Space dimension for dual-module unit
Air Outlet
3.2.1.3 Space dimension for three-module unit
＞200
Air Outlet
Air Outlet
＞200
＞200
＞1000
Electrical Box
Outlet on this side
Fig. 3
＞1000
Fig. 4
＞1000
＞200
Fig.5
7
＞1000
＞1000
＞200
Electrical Box
Outlet on this side
＞200
Electrical Box
Outlet on this side
＞1000
