  • Page 1 Welch Allyn In-Floor Scales Directions for use Models 6102, 6154...
  • Page 2 © 2017 Welch Allyn. All rights are reserved. To support the intended use of the product described in this publication, the purchaser of the product is permitted to copy this publication, for internal distribution only, from the media provided by Welch Allyn. No other use, reproduction, or distribution of this publication, or any part of it, is permitted without written permission from Welch Allyn.

  • Page 3: Table Of Contents

    Contents Introduction ..................... 1 Intended use ......................1 Indications for use ....................1 Symbols ....................... 1 About warnings and cautions ................2 Controls and indicators ..................4 Assembly and setup ................7 Scale and handrail installation ................7 Custom setup ...................... 7 Scale operation ..................
  • Page 4 Contents Welch Allyn In-Floor Scales...

  • Page 5: Introduction

    Introduction Intended use The Welch Allyn Integrated Scales are intended to be used by clinicians for weighing patients up to 825 lb (375 kg) for models 6102 and 6154. Indications for use The Welch Allyn In-Floor Scales are used by clinicians to weigh patients.

  • Page 6: About Warnings And Cautions

    Caution statements can appear on the Welch Allyn In-Floor Scales, the packaging, the shipping container, or in this Directions for use. The Welch Allyn In-Floor Scales are safe for patients and clinicians when used in accordance with the instructions and caution statements presented in this Directions for use.
  • Page 7 Directions for use Introduction 3 section, you must also review the more specific cautions that appear throughout the manual in conjunction with setup/startup, operation, and maintenance tasks. • Failure to understand and observe any warning statement in this manual could lead to patient injury or illness.

  • Page 8: Controls And Indicators

    4 Introduction Welch Allyn In-Floor Scales Controls and indicators Scale Front panel Hand rail (optional) Weighing platform...
  • Page 9 Directions for use Introduction 5 Front panel buttons Button Function ZERO Press this button to reset the scale to zero. Press this button to turn on the scale. Press this button in conjunction with to enter the setup mode. RECALL Press this button to recall the previously stored scale reading.
  • Page 10 6 Introduction Welch Allyn In-Floor Scales...

  • Page 11: Assembly And Setup

    Assembly and setup Use the following instructions to assemble and setup your scale for use. Scale and handrail installation Please refer to the instructions that shipped with your scale for installation information. Custom setup You can customize the scale to best suit your needs. Configurations that can be selected include the automatic shut-off time, weighing units, weight resolution, and more.
  • Page 12 RE CALL rECALL* Press RE CALL to change the button functionality between rS-232 Detailed instructions for this feature are available from Welch Allyn. Go to http:// www.welchallyn.com/en/other/contact-us.html to find your local representative. OutPut* This option displays the current data port output option. Detailed instructions for this feature are available from Welch Allyn.
  • Page 13 Directions for use Assembly and setup 9 Set the value to to disable the optional internal printer or the RS-232 port. PrtUnt* This option determines whether pounds or kilograms are displayed on a printout. RE CALL Press to switch between the following options: If the pounds and kilograms indicators are illuminated on the control panel, the printed output is determined by whichever unit is selected on the control panel.
  • Page 14 10 Assembly and setup Welch Allyn In-Floor Scales...

  • Page 15: Scale Operation

    Scale operation Power options The scale can be used with battery power or with AC power. Battery power Press ON to turn on the scale. The scale automatically turns off after 45 seconds of non-use when operating on battery power. The LOW-BATT indicator displays when the battery power is low.

  • Page 16: Weighing Procedure

    12 Scale operation Welch Allyn In-Floor Scales Weighing procedure 1. Press ON to turn on the scale. The scale sounds one beep. 2. Wait for the scale to display 0.0. The scale sounds two beeps. 3. Place the patient on the scale and make sure that his or her weight is evenly distributed.

  • Page 17: Cleaning And Maintenance

    Cleaning and maintenance Cleaning 1. Clean the scale at least once per day, and the optional handrail after each use. 2. Use one of the following products when cleaning your scale: 70 percent isopropyl alcohol ® PDI Sani-Cloths Rechargeable battery replacement Contact your service department.

  • Page 18: Change The Printer Paper

    14 Cleaning and maintenance Welch Allyn In-Floor Scales Change the printer paper The printer is a purchasable option. 1. Use a screwdriver to loosen the screw on the battery access door and remove the printer access door. 2. Remove the spindle containing the empty printer paper roll from the printer paper well.

  • Page 19: Maintenance

    Directions for use Cleaning and maintenance 15 8. Install the printer access door, and advance the new paper through the slot on the door. 9. Install the screw on the printer access door. Maintenance Routinely perform the following preventive maintenance to keep your scale in working order.
  • Page 20 16 Cleaning and maintenance Welch Allyn In-Floor Scales Issue Possible cause Suggested action r-FAIL The scale's memory has failed. Contact your service department. The error message displayed A-FAIL The scale's memory has failed Contact your service department. The error message...

  • Page 21: Appendices

    Scales 6102, 6154 Resolution (factory default) 0.1 lb / 100 g Weighing capacity 6102, 6154: 825 lb (375 kg) Readout Large, bright light-emitting diode display. Selectable weight displayed in pounds or kilograms. Indicator light to show selected units. Power source Battery •...

  • Page 22: Product Configurations

    Battery pack 7.2V Warranty Welch Allyn will warranty the weight scale to be free of defects in material and workmanship and to perform in accordance with manufacturer specifications for the period of one year from the date of retail purchase.
  • Page 23 3) the date of purchase of the product from a Welch Allyn authorized distributor as documented from a receipt from said distributor. This warranty does NOT cover damages caused by misuse or abuse, including but not limited to: •...
  • Page 24 Material No. 724518...
