Instruction Leaflet IL04802001E Effective May 2010 HMi Series Instruction Leaflet Contents Description Page Preface............1 Safety Information........1 General Description ......... 2 Accessories (sold Separately) ..... 3 Unpack and Inspect........3 Hardware Features ........4 Dimensions and Cut-Outs....... 9 Serial Port Pinout ........11 Accessing the Setup Screens ....
This instruction leaflet will be helpful in Carefully note and observe the the installation, wiring and inspection of following safety precautions when the Eaton HMi series of operator receiving, inspecting, installing, operating, maintaining and troubleshooting. The interface products. Before using the...
HMi Series Instruction Leaflet Wiring Method General Description WARNING Positioned between the ELC graphics Remove the terminal block from the panels and the XV series of operator HMi before wiring. interfaces, HMi is the work horse of the Insert only one wire into each industry.
Included with the HMi are: • ELC-CBPCELC1 — 1 meter cable to • Panel Mounting clips (number of clips connect between the HMi and Eaton Logic varies depending on the size of the unit). Controller (ELC) • DB9 gender changer for easy connection •...
HMi Series Instruction Leaflet Hardware Features 4” HMi (HMI04BU/HMI04CU) Power Input Terminal COM2 (Note) COM1 Startup Switch UP position - Run Mode DOWN position - Boot Menu NOTE For simultaneous communications, wire one DB9 connector for COM1 and COM3 according to the pinout diagram in this document.
Page 6
HMi Series Instruction Leaflet 6” HMi (HMI06CU) Power Input Terminal (Note) COM2 COM1 Battery Cover USB Host USB Client System Key NOTE For simultaneous communications, wire one DB9 connector for COM2 and COM3 according to the pinout diagram in this document.
Page 7
HMi Series Instruction Leaflet 6” HMi (HMI06BE/HMI06GE/HMI06CE) Power Input Terminal Expansion Slot Smart Memory Card Slot (Note) COM2 COM1 NOTE For simultaneous communications, wire one DB9 connector for COM2 and COM3 according to the pinout diagram in this document. EATON CORPORATION www.eaton.com...
Page 8
HMi Series Instruction Leaflet 8” HMi (HMI08CE) Power Input Terminal Expansion Slot Smart Memory Card Slot (Note) COM2 COM 1 Battery Cover NOTE For simultaneous communications, wire one DB9 connector for COM2 and COM3 according to the pinout diagram in this document.
Page 9
HMi Series Instruction Leaflet 10” HMi (HMI10CE) Power Input Terminal Expansion Slot Smart Memory Card Slot (Note) COM2 COM 1 Battery Cover NOTE For simultaneous communications, wire one DB9 connector for COM2 and COM3 according to the pinout diagram in this document.
HMi Series Instruction Leaflet Serial Port Pinout For 4” (HMI04BU/HMI04CU) COM1 and COM3 are RS-232 only COM2 DB 9 Pinout for COM1 and COM3 RS-232 COM2 Pinout for RS-422 & RS-485 COM3 Not Used COM3 Used RS-422 RS-485 COM1 COM3...
Page 13
HMi Series Instruction Leaflet For 6” (HMI06CU) COM1 is RS-232 only COM2 and COM3 DB 9 Pinout for COM1 RS-232 DB 9 Pinout for COM2 and COM3 COM1 RS-232 RS-232 RS-485 COM3 Not Used COM3 Used COM2 COM3 COM2 COM3 Note: Blank=No connection.
Page 14
HMi Series Instruction Leaflet For 6" (HMI06BE, HMI06GE, HMI06CE), 8" (HMI08CE), and 10" (HMI10CE) COM1 is RS-232 only COM2 and COM3 DB 9 Pinout for COM1 RS-232 DB 9 Pinout for COM2 and COM3 COM1 RS-232 COM3 Not Used COM3 Used...
HMi Series Instruction Leaflet Accessing the Apply Power Setup Screens For 4” (HMI04BU/HMI04CU), To bring up the System menu, press and hold the SYS key for several seconds 6” (HMI06BE/HMI06GE/HMI06CE), located on the front for those models 8” (HMI08CE), 10” (HMI10CE) with function buttons and on the back of the unit for all other models.
HMi Series Instruction Leaflet Specifications MODEL HMI04BU HMI04CU HMI06BE HMI06GE Display Type TFT LCD FSTN Display Color 8 Blues 65536 Colors 8 Blues 16 Grays Screen Pixels 320 x 240 pixels LCD Module LED Back Light LED Back Light CCFL Back Light...
Page 17
In order to ensure the normal operation, it is recommended to use a power supply which the capacity is 1.5 ~2 times the value of the power consumption. 6) For further details, please visit the Eaton website www.eaton.com/electrical. EATON CORPORATION www.eaton.com...
Page 18
HMi Series Instruction Leaflet MODEL HMI06CE HMI06CU HMI08CE HMI10CE Display Type TFT LCD TFT LCD TFT LCD Display Color 25 6 C 65536 Color 65536 Color 65536 Color Screen Pixels 320 x 240 pixels 640 x 480 pixels 2CCFL Back...
Page 19
1.5 ~2 times the value of the power consumption. 6) A total of 125K Bytes of memory is shared for History and Alarms. 7) For further details, please visit the Eaton website www.eaton.com/electrical. EATON CORPORATION www.eaton.com...
