Page 1
(338.07) Behind Panel Surface for Mounting Hardware Figure 1. Dimensions of the PXM4/6/8K Meter Advanced Display - 12” Color Touchscreen (PXM468K-DISP-12). For detailed information concerning the operation and features avail- able in the PXM4/6/8K Meter Advanced Display - 12” Color Touch-...
Page 2
Figure 5. PXM4/6/8K Display Fasteners - Installed. as OFF-OFF-ON 6. Set the PXM4/6/8K meter to Advanced Display mode by chang- ing the Security Mode Dip Switches to OFF-OFF-ON. This dis- ables the log-in screen when the Advanced Display is connected to the Local Config.
Page 3
PXM4/6/8K Meter Advanced Color Technical Data TD150019EN Touchscreen Display Quick Start Guide Effective January 2017 LAN 1 (reserved for factory Audio jack configuration) Alternative power USB 2.0 (top) LAN 2 COM 1 COM 2 connection USB 3.0 (bottom) (local meter connection) Figure 8.
Page 4
PXM4/6/8K Meter Advanced Color Technical Data TD150019EN Touchscreen Display Quick Start Guide Effective January 2017 The user will be prompted to open the installer. Follow the prompts On future power-ups, when the device is properly connected to the to open the certificate to begin installation. Be sure to select meter, a grey progress bar will begin to fill, in conjunction with the Trusted Root Certification Authorities as the certificate store.
PXM4/6/8K Meter Advanced Color Technical Data TD150019EN Touchscreen Display Quick Start Guide Effective January 2017 Connection with Multiple Meters Meter Firmware Requirements The minimum meter firmware version required for compatibility is 13.3.6.5. Technical Information 1024 x 768 pixel backlit LCD graphic touch screen display.
