Summary of Contents for Eaton PXBCM-DISP-6
- Page 1 Instruction Booklet IB150007EN Effective August 2015 PXBCM Meter Color Touchscreen Display User Manual...
- Page 2 1 Introduction Back Previous Next The Eaton PXBCM Meter 6” Color Touchscreen Display (PXBCM- DISP-6 ) is pre-programmed to communicate with Eaton PXBCM-MB Meters. The programming allows access to branch-circuit-monitor data and meters through the PXBCM meter base. The built-in navi- gation functions are simple and convenient, allowing easy navigation between screens.
- Page 3 The Power Factor category displays the apparent power factor for • each channel. Each Virtual Meter or Main has a couple screens containing detailed data for the selected meter (see Figure 5). Figure 5. Main and Virtual Meter Data. EATON www.eaton.com...
- Page 4 Also within the Channel Data screens, the “Up” and “Down” arrows navigate through pages of channel data, specifically 1-7 on the first page, 8-15 on the second page, 16-21 on the third page, and AX1- AX4 on the fourth page (see Figure 7). Figure 7. Channel Data Screen. EATON www.eaton.com...
- Page 5 The Current Alarm Counters include columns for “Low-Low” (i.e. very low), “Low” , “High” , and “High-High” (i.e. very high). Meanwhile, the Voltage Alarm Counter include columns for “Low” and “High” (see Figure 10). EATON www.eaton.com...
- Page 6 PXBCM Meter Color Touchscreen Instruction Booklet IB150007EN Display User Manual Effective August 2015 Notes: EATON www.eaton.com...
- Page 7 PXBCM Meter Color Touchscreen Instruction Booklet IB150007EN Display User Manual Effective August 2015 Notes: EATON www.eaton.com...
- Page 8 OF DEALING OR USAGE OF TRADE, ARE MADE REGARDING THE INFORMATION, RECOMMENDATIONS, AND DESCRIPTIONS CONTAINED HEREIN. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or otherwise for any special, indirect, incidental or consequential damage or loss...
