Table 10 Usable field width with dynamic operation (median deviation)
MDS D124
25
All dimensions in mm
Table 11 Operating range in mm (S
MDS D124
10...25
All dimensions in mm
Table 12 Limit distance in mm (S
MDS D124
75
All dimensions in mm
Note
Tips if the range is too short
If the range of the antenna is too short, you must check
● the power supply/switched-mode power supply (interference)
● whether there are monitors or other sources of interference nearby
● whether there is metal in the environment
Minimum distance from transponder to transponder (without multitag mode), in mm
The values are valid at a distance of 20 mm (reader-tag).
Table 13 Minimum distance transponder
MDS D124 to
MDS D124
Horizontal main
100
field
Vertical main field
150
The minimum distance can be undershot in multitag mode.
NOTICE
Extension of the data transmission time if distance values are undershot
If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected. The time
required for data transmission can increase unpredictably.
For this reason, please observe the values in the tables.
SIMATIC RF382R Scanmode
J31069-D0214-U001-A1-7618, 10/2009
MDS D160
25
)
a
MDS D160
10...25
)
g
MDS D160
65
MDS D160 to
MDS D160
100
120
MDS D324
25
MDS D324
10...25
MDS D324
75
MDS D324 to
MDS D324
100
150
MDS D424
25
MDS D424
10...25
MDS D424
75
MDS D424 to
MDS D460 to
MDS D460
MDS D424
100
100
180
120
MDS D460
25
MDS D460
10...25
MDS D460
60
7
