7. DISASSEMBLY

A
Note: Even if the unit shown in the photos and illustrations in this manual may differ from your product, the
procedures described here are common.
Knobs and Volumes Location
B
A
B
C
C
D
D
A Knob/MIC
(DAA1301) ×2
White
Gray
E
Knob/CH
F
(DAA1300) ×4
White
Gray
FX SEL Knob
I
(DAA1213) ×1
White
F
Black
72
1
2
B Knob/EQ C Rotary SW Knob (HM)
(DAA1302) ×2 (DAA1256) ×4
White
Black
Rotary SW Knob (B) Select Knob
G H
(DAA1176) ×12 (DAA1205) ×1
White
White
Black
Black
White
Projection
Knob (TIME) Rotary Knob (BN)
J K
(DAA1214) ×1 (DAA1220) ×1
Black
2
3
L
D Knob (Black)
(DAA1212) ×2
White
White
Black
Silver
Slider Knob 1
L
(DAC2684) ×5
Slider Knob 2
Slider Knob 1
White
Slider Knob Stopper
Black
DJM-850-K
3
4
E
F
G
E
H
I
E
J
K
E Knob (MA)
(DAA1210) ×3
White
Black
Slider Knob 2 Slider Knob Stopper
(DAC2685) ×5 (DNK5888) ×5
White
Black
Gray
