YOUR SAFETY FIRST
G
MAKE SURE YOU HAVE ENOUGH SPACE AND SUPPORT.
– Mount the oven against a flat, vertical wall, so that it is supported by the wall. The wall should be constructed
of minimum 2" x 4" wood studding and 3/8" thick drywall or plaster/lath.
– ATTACH AT LEAST ONE of the two lag screws supporting the oven to a vertical, 2" x 4" wall stud.
– DO NOT mount the microwave oven to an island or peninsula cabinet.
– BE SURE the upper cabinet and rear wall structures are able to support 150 lbs., plus the weight of any
items you place inside the oven or upper cabinet.
– Locate the oven away from strong draft areas, such as windows, doors, and strong heating vents.
you risk personal injury and/or property damage.
– BE SURE you have enough space. See Figure 3 below for minimum vertical and horizontal clearance.
G
Before you begin installing the oven, PLACE A PIECE OF THE CARTON OR OTHER HEAVY MATERIAL (a
blanket) over the countertop or cooktop to protect it. Do not use a plastic cover.
Failure to protect these surfaces could result in property damage.
NOTE: Do not use this microwave oven for commercial purposes.
This oven is designed for household use only.
w w WARNING w w
If you do not mount the oven as instructed,
15" max. upper cabinet
14" min. microwave
oven to cooking surface
or countertop
w w CAUTION w w
30" min. cabinet opening width
30" min. clearance from bottom
of cabinet to cooking surface
or countertop
(Use templates included
with installation instructions)
Figure 3
- 4 -
Grounded Plug
(inside upper cabinet)
Power Supply
Cord Hole
