Ordering Nomenclature - Danfoss KPP Pulse Pickup Technical Information

Technical Information

Ordering Nomenclature

KPP PPU
Hall effect PPU
Revision
Mechanical configuration (housing)
1
Flat end
2 Conical end
3 Conical end, fixed position
4
Flat end, fixed position
Electrical configuration
2 Regulated supply 4.5 to 8.5 Vdc, 3 connection,
non-directional, wire fault detection
3
Regulated supply 4.5 to 8.5 Vdc, 4 connection, directional,
wire fault detection, low current
4
Regulated supply 4.5 to 8.5 Vdc, 4 connection, directional,
wire fault on speed signal, open collector on direction signal
5
Regulated supply 4.5 to 8.5 Vdc, 4 connection, directional wire
fault detection, high current, filtered speed output
6
Battery supply 7 to 32 Vdc, 3 connection, non-directional,
limited wire fault detection
7
Regulated supply 4.5 to 8.5 Vdc, 4 connection, directional,
wire fault detection, low current, quad output**
8
Regulated supply 4.5 to 8.5 Vdc, 4 connection, directional,
wire fault detection, low current, output signal divided by 2
9
Regulated supply 4.5 to 8.5 Vdc, 4 connection, directional,
wire fault detection, high current, quad output**
A Battery supply 7 to 32 Vdc, 4 connection, directional, limited
wire fault detection, high current, quad output**
B Regulated supply 4.5 to 8.5 Vdc, 3 connection, non-
directional, wire fault detection, high current, filtered speed
output
Electrical connector
1 Amp Mate-n-Lok
4
Delphi/Packard Weather-Pack (3 pin)
1
Delphi/Packard Weather-Pack (4 pin), used when direction signal is required
2
5
Delphi/Packard Metri-Pack
6 Integral Turck Eurofast (no leadwires)
7 Deutsch DT04 (3 pin)
1
Deutsch DT04 (4 pin), used when direction signal is required
2
8
Delphi/Packard Metri-Pack 150 series plug
9 Delphi/Packard Metri-Pack 150 series jack
All leadwire length is described in inches unless denoted with m (meters)
Specialties
A
Special connector pinouts
B Special connector pins
**Do not attempt to apply a quadrature output PPU without first consulting with a Sauer-
Danfoss field applications engineer for specific application requirements.
11029257 • Rev BB • July 2013
KPP X X X X XX
