  • Page 1 Security System Installation and Setup Guide N9833V2 2/00...
  • Page 2 XL-2T Installation & Setup Guide...
  • Page 3 XL-2T Security System. The purpose of this manual is to give you a brief overview of the XL-2T control panel, and provide instruc- tions for installing a basic system. FBII is always available to serve YOU. Our SALES and TECHNICAL SUPPORT staff are available to assist you in any way possible.

  • Page 4: Table Of Contents

    S E C T I O N 2 - PC BOARD AND KEYPAD MOUNTING ..........2–1 Mounting the XL-2T PC Board...................... 2–1 Mounting the XK-4600RM Keypad ....................2–2 Mounting the XK-4600SM Keypad....................2–3 Mounting the XK-406 and 6615 Keypads ..................2–4 Surface Mounting the XK-508 and XK-5LC Keypads ..............
  • Page 5 Standard (3x1 or 4x1) ........................A–1 Extended (3x1 Ext. or 4x1 Ext.) .....................A–2 Partial Extended (3x1 Part. Ext. or 4x1 Part. Ext.)................A–2 3x2 or 4x2............................A–2 FBII Superfast (4x3x1) ........................A–3 ADEMCO 4x1 Express........................A–3 ADEMCO 4x2 Express........................A–3 ADEMCO Point ID........................A–4 APPENDIX B - TROUBLESHOOTING.....................

  • Page 6: Conventions Used In This Manual

    Conventions Used in This Manual • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Before you begin using this manual, it is important that you understand the meaning of the following symbols (icons) and text note.

  • Page 7: Xl-2T To Xl-2 Comparison

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • The XL-2T is an enhanced version of the XL-2 control panel. Some new features have been added and others have been modified.
  • Page 8 • (Program Question 07) Stay Mode 40 Sec. Dialer Delay w/ Bell & Keypad ....Stay Mode Entry Delay w/ Keypad Sounder warning for Exit/Entry Zones Only Sounder Warning for All Zones • (Program Question 12) Auto Arming in Different Modes ........NONE •...

  • Page 9: S E C T I O N Features

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Features The XL-2T is a state-of-the-art microprocessor-based control/communicator. The system fea- tures seven fully programmable zones. Programming can be performed through any of the compatible keypads, or the system can be uploaded and downloaded remotely using the EZMATE/COMPASS PC Downloader Software.

  • Page 10: Compatible Keypads

    Failure to install and program this unit in accordance with the UL requirement is a violation of the listing mark. For more information on UL Listings, contact Underwriters Laboratories, Progress Department, 333 Pfingsten Road, Northbrook IL 60062. The XL-2T is a Residential (Household) control panel and has been listed by Underwriters Laboratories for the following applications: •...

  • Page 11: S E C T I O N Mounting The Xl-2T Pc Board

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Mounting the XL-2T PC Board To make it easier to install the control panel, the door of the metal cabinet may be removed.

  • Page 12: Mounting The Xk-4600Rm Keypad

    XL-2T Installation & Setup Guide Mounting the XK-4600RM Keypad FLUSH MOUNTING USING DOUBLE-GANG BOX 1. Create an opening and mount a standard dou- ble-gang box. 2. Secure keypad to double-gang box as shown in graphic at left. NOTE: Mount the double-gang box flush with wall in order for keypad screws to fit.

  • Page 13: Mounting The Xk-4600Sm Keypad

    Section 2 - PC Board and Keypad Mounting Mounting the XK-4600SM Keypad The XK-4600SM Keypad may be surface-mounted in the following ways: A. Directly to a control panel having a keypad cutout on the front of its enclosure. B. Directly to a single-gang or double-gang electrical junction box. C.

  • Page 14: Mounting The Xk-406 And 6615 Keypads

    XL-2T Installation & Setup Guide Mounting the XK-406 and 6615 Keypads Mounting is identical for the XK-406 and 6615 (LED type) keypads. The keypads can be surface- mounted or flush-mounted as described below. SURFACE MOUNTING 1. Select a mounting location and place the rear plate of the keypad on the wall.

  • Page 15: Surface Mounting The Xk-508 And Xk-5Lc Keypads

    Section 2 - PC Board and Keypad Mounting Surface Mounting the XK-508 and XK-5LC Keypads Mounting is identical for the XK-508 and XK-5LC LCD type keypads. The keypads are surface- mounted as described below. 1. Separate the two halves of the keypad by placing a straight-slot screwdriver into one of the two slots at the bottom of the keypad and twisting.

  • Page 16: Recess Mounting The Xk-7Lc Keypad

    XL-2T Installation & Setup Guide Recess Mounting the XK-7LC Keypad 1. Select the desired location between wall studs for mounting the keypad. NOTE: The rear plastic mounting plate is not used for recessed installations. 2. Create an opening in the wall exactly 4 inches high by 5 13/16 inches wide, as shown in diagram at left.

  • Page 17: S E C T I O N 3 - System Wiring And Hookup

    C O N N E C T I O N S F O R H O U S E H O L D F I R E / B U R G L A R A L A R M S Y S T E M XL-2T...

  • Page 18: Terminal Connections

    XL-2T Installation & Setup Guide Terminal Connections TERMINALS DESCRIPTION Zone 1 (Requires 2.2K EOL resistor) [Default = DELAY] 1(+) & 2(-) Zone 2 (Requires 2.2K EOL resistor) [Default = INTERIOR] 3(+) & 2(-) Zone 3 (Requires 2.2K EOL resistor) [Default = PERIMETER] 4(+) &...
  • Page 19 This system will accept 9.5-12VDC RANGE RATED FOUR-WIRE SMOKE DETECTORS ONLY. Approximately 50mA of current is avail- able at these terminals for powering all detectors and an EOL relay FBII model 620. For UL installations, see wiring diagram for hookup.
  • Page 20 CS if enabled (Program Question 32, Location 3). If the siren is already sounding, the supervision will not take effect until after bell cutoff time. NOTE: Use FBII models ZR-815C, ZR-815EC, or ZR-830EC. Refer to the following diagram: 22 (+)
  • Page 21 Section 3 - System Wiring and Hookup SPEAKER SUPERVISION (VS-299 Siren/Driver) - To supervise a speaker connected to the VS-299 Siren Driver, connect terminal 1 of the VS-299 to the positive terminal of any zone programmed as a 24-Hour Trouble zone (Program Questions 17 - 23, Locations 1 and 2).
  • Page 22 Ground start capability can be added to the system through addition of GROUND START: the FBII Model 117 Module. Refer to the 117 Installation Instructions for hookup information. With this device, some systems can obtain dial tone in areas that do not automatically provide dial tone. At the moment tele- phone line seizure occurs, the Telco Tip is momentary connected to earth ground to access dial tone.

  • Page 23: Auxiliary Device Current Draw Worksheet

    Section 3 - System Wiring and Hookup Auxiliary Device Current Draw Worksheet DEVICE TYPES CURRENT DRAW FOR NUMBER OF TOTAL CURRENT FOR EACH DEVICE UNITS EACH DEVICE TYPE XK-406 Keypad 60mA * XK-4600RM Keypad 30mA * XK-4600SM Keypad 30mA * 6615 Keypad 60mA * XK-508 Keypad...
  • Page 24 XL-2T Installation & Setup Guide 3–8...

  • Page 25: S E C T I O N 4 - Keypad Features

    The XL-2T control panel supports the XK-5LC and XK-7LC LCD Keypads; and the following LED Keypads: XK-406, XK-508, XK-4600RM, XK-4600SM, and 6615. Shown below and on the next page are layouts for XL-2T supported LCD and LED Keypads. Refer to the key following these layouts for descriptions of numbered features.
  • Page 26 XL-2T Installation & Setup Guide LED KEYPAD TYPES XK-406 XK-508 XK-4600SM XK-4600RM 6615 4–2...
  • Page 27 Section 5 - System Operation 1 - ZONE STATUS LEDS These LEDs display the current zone status, including alarms, bypasses, and faults. Each condition will cause these LEDs to operate differently, as follows: ALARMS Fast Blink (approx. 150mS ON - 150mS OFF). TROUBLES Slow Pulse (approx.

  • Page 28: System Mode Summary

    XL-2T Installation & Setup Guide 7 - COM LED This LED indicates that communication between the panel and Central Station (CS) is being maintained. Slow Blink Communication failure. Normal operation - communication active. 8 - STAY BUTTON The STAY button arms the system, excluding zones programmed as interior zones. This provides exterior protection of the premises while allowing full access throughout the in- terior.

  • Page 29: Keypad Sounder

    Section 5 - System Operation Keypad Sounder The sounder (or loudspeaker) housed inside the keypad emits sounds according to the condi- tion of the security system. The keypad sounder annunciates differently to indicate the following conditions: CHIRP - Keypad sounds a short chirp to confirm each keystroke. STEADY - The keypad makes a steady sound during entry time and/or during burglary alarm.
  • Page 30 XL-2T Installation & Setup Guide 1 2 3 4 XK-508 AND XK-5LC (BOTTOM VIEW WITH BACK REMOVED) On XK-508 and XK-5LC keypads, when the switch is pushed toward the back of the keypad (in the direction of the arrow above), the switch is in the ON position. When the switch is pushed toward the front of the keypad (in the opposite direction of the arrow), the switch is in the OFF position.

  • Page 31: S E C T I O N Power-Up/System Reset

    S E C T I O N System Operation • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Power-Up/System Reset SYSTEM STABILIZATION MODE: Upon power-up of the system and after completion of system programming, IF THE SYSTEM WAS PREVIOUSLY ARMED, all the lights on the...

  • Page 32: Instant Arming

    XL-2T Installation & Setup Guide Instant Arming TO ARM: Press the INSTANT key followed by a four-digit user code. The INSTANT and ARM LEDs will light continuously. LCD display keypads will indicate the following message: ON: AWAY INSTANT The entire security system (interior and exterior) is armed at this time, allowing only for the entry/exit time delay that has been programmed into the system.

  • Page 33: Quick Bypass By Zone/Group

    Section 5 - System Operation If QUICK BYPASS is disabled (Question 08, Location 3) and ZONE BYPASS is enabled (Question 17-23, Location 3), then: TO BYPASS BY ZONE: Press the BYPASS key followed by any valid 4-digit user code, fol- lowed by a single-digit number (1-7) representing the zone to be bypassed.

  • Page 34: Auto Unbypass

    XL-2T Installation & Setup Guide Auto Unbypass All burglary zones that are bypassed are automatically unbypassed upon system disarm. Twenty-four-hour zones that have been bypassed will be unbypassed only if they are not validated. Manual Unbypass MANUAL UNBYPASS removes an existing bypass from a currently bypassed zone or group.

  • Page 35: User Deletion

    Section 5 - System Operation Example: To define user #03 with an ID of 7493 (assuming master code is 1234), enter: [CODE] + [1234] + [03] + [7493]. An acknowledge sound (steady tone) verifies a successful user code programming. A negative acknowledge sound (4 short tones) indicates unsuccessful programming.
  • Page 36 XL-2T Installation & Setup Guide COMMAND KEYSTROKES ENABLED IN Display Time (LCD Keypad Only) [#] [7] To require user code (Question 10, Location 4) Display Auto Arm Time (LCD [#] [8] To require user code (Question 10, Keypad Only) Location 4 Question 14;...
  • Page 37 Section 5 - System Operation SET AUTO ARM TIME: [#] + [5] If auto arming is programmed (enabled in Programming Question 8, Location 4), then pressing [#] + [5] will set the auto arm time of the current area. If a user code is required to set the time, then enter: [#] + [5] + [USER] + [HOUR] + [MINUTE] where:...

  • Page 38: Installer Modes

    XL-2T Installation & Setup Guide DISPLAY AUTO ARM TIME: [#] + [8] (LCD Keypads Only) If auto arming is programmed, then pressing [#] + [8] will display on the LCD keypads the current auto arm time for the current area.
  • Page 39 Section 5 - System Operation 2. WALK TEST WITH SOUNDER 3. WALK TEST WITH SOUNDER AND BELL 4. SYSTEM LOG VIEW 5. WALK TEST MOTION 6. Not Used - RESERVED 7. SYSTEM DEFAULT 8. UNATTENDED DOWNLOAD 9. ON-LINE DOWNLOADING INSTALLER MODE 1 (INSTALLER KEYPAD PROGRAMMING) The installer uses this mode to enter keypad programming.
  • Page 40 XL-2T Installation & Setup Guide INSTALLER MODE 4 (SYSTEM LOG VIEW) The system retains history of the past 78 events (alarms, troubles, openings, closings, by- passes, etc.). Upon entry to the system log view, LCD-based keypads will show the events one at a time starting from the oldest event.
  • Page 41 Section 5 - System Operation 1. The PC operator must select UNATTENDED DOWNLOAD in the Downloader Soft- ware Main Menu. 2. Enter Unattended Download mode by pressing: [CODE] + [Q] + [INSTALLER] + [8]. 3. The system will now enter UNATTENDED programming (Question 01). Enter the telephone number of the Central Station downloading computer into this question (12 digits maximum, each digit followed by the [#] key;...
  • Page 42 XL-2T Installation & Setup Guide 5–12...

  • Page 43: S E C T I O N 6 - System Programming

    Programming Questions Programming questions and their values are described below. First, completely fill in the XL-2T SYSTEM PLANNING WORKSHEET in Appendix C. Next, complete the SYSTEM PROGRAMMING WORKSHEET in Appendix D. Then enter the data as explained in Section 7: Data Entry via Keypads. DO NOT ATTEMPT TO ENTER DATA BEFORE COMPLETELY FILLING OUT THE PROGRAMMING WORKSHEET.
  • Page 44 XL-2T Installation & Setup Guide QUESTION 01 PRIMARY TELEPHONE NUMBER........DEFAULT = 234AAAAAAAAAAAAA Enter the telephone number (including area code and/or dialing prefix, if necessary) of the primary Central Station receiver in Locations L1-L16. This number is known as CS#1. Example: If the primary telephone number to be entered is 1-516-810-5604, enter on Pro- gramming Worksheet: 8105604.

  • Page 45: Dual Reporting

    With Pager reporting enabled (Question 07, L1 above and Question 08, L1), Dual Reporting, Single Reporting, and Backup Dialing are the available reporting options in Question 07, L3. Refer to FBII Superfast (4x3x1) reporting in Appendix A for reporting format. Dual Reporting The following Dual Reporting options are available: •...

  • Page 46: Single Reporting

    XL-2T Installation & Setup Guide However, if communication with CS#1 is unsuccessful, the panel accesses CS#2 format (the Pager format). After the Pager format is sent, it will attempt another transmission to CS#1. If the CS#1 second attempt is successful, panel receives a kissoff and does not make a second attempt to CS#2.
  • Page 47 NOTE: The value placed in this digit will be ignored if transmitting in one of the DTMF for- mats (FBII Superfast, ADEMCO PID, ADEMCO Express). For UL installations, the acceptable receivers are FBII CP220 (all formats except ADEMCO Ex- press, 4x1 + 4x2, and ADEMCO High Speed), ADEMCO 685 (all formats without parity and not FBII Superfast), Silent Knight 9000 (10PPS, No Parity, 1400, or 2300Hz).
  • Page 48 XL-2T Installation & Setup Guide SPLIT REPORTING - If split reporting is enabled, then alarms, restores, and troubles will be reported to CS#1, and openings/closings will be transmitted to CS#2. DIALER DISABLE: This option will turn OFF the digital dialer, making the control a local panel.
  • Page 49 NOTE: The value placed in this digit will be ignored if transmission is in one of the DTMF formats (FBII Superfast, ADEMCO PID, ADEMCO Express). For UL installations, the acceptable receivers are FBII CP220 (all formats except ADEMCO Ex- press, 4x1 + 4x2, and ADEMCO High Speed), ADEMCO 685 (all formats without parity and not FBII Superfast), Silent Knight 9000 (10PPS, No Parity, 1400 or 2300Hz).
  • Page 50 XL-2T Installation & Setup Guide Question 08, L3 - Quick Commands, User 14 Arms Only, and All Users Door Strike ....................Default = 0 Enter the digit for the desired message length from the table below. NOTE: The checkmarks highlight which options are selected.
  • Page 51 Section 6 - System Programming QUESTION 09 MISCELLANEOUS OPTIONS ..............DEFAULT = 8010 Question 09, L1 & L2 - Group Bypass for Zones 1-7 and Quick Exit ................L1 Default = 8, L2 Default = 0 Select the zones to be bypassed as a single group from the tables below. If Quick Bypassing is enabled, group bypassing can be performed by the following sequence: [BYPASS] + [User Code] + [#] or [BYPASS] + [#].
  • Page 52 XL-2T Installation & Setup Guide Question 09, L3 - No CS Bypass for Stay, Auto Stay Keyswitch, Armed Bypass Display..................Default = 1 Select the desired options from the table below. NOTE: The checkmarks highlight which options are selected. Digit...
  • Page 53 Section 6 - System Programming QUESTION 10 BELL TIMEOUTS, CS TEST TIME, and MISCELLANEOUS ......DEFAULT = 5F26 There are 4 Locations (L1-L4) within this question, as follows: Question 10, L1 - Burglary Bell Timeout .............. Default = 5 Question 10, L2 - Fire Bell Timeout ..............Default = F Enter the digit for the desired bell timeouts from the table below.
  • Page 54 XL-2T Installation & Setup Guide TEST BY TIME - Indicates that system TEST signals (if selected) will be sent at the time specified in Question 16. The interval depends on the test interval selected. TEST BY EVENT - This indicates that each event transmitted will restart the test timer. For...
  • Page 55 Section 6 - System Programming QUESTION 11 ENTRY/EXIT TIMEOUTS & CROSS ZONE TIMEOUT ........DEFAULT = 6333 There are 4 Locations (L1-L4) within this question that define the exit/entry times as follows: Question 11, L1 - Exit Delay/Exit Delay Restart ........Default = 6 (UL max) •...
  • Page 56 XL-2T Installation & Setup Guide Question 11, L4 - Cross Zone Timeout ..............Default = 3 This option selects the timeout for all zones programmed with Cross Zone capability (see Questions 17 - 23, Location 3). When one of the zones enabled for cross zones is tripped, then a timer is started.
  • Page 57 Digit 0 (12-Volt Bell Output) must be selected for all UL applications. For Built-in Siren Driver, connect a single 8 ohm speaker only. For Bell Output, connect a si- ren driver (e.g., FBII model VS-299 or 679S) and an 8 ohm speaker, a self-contained siren, or a bell.
  • Page 58 XL-2T Installation & Setup Guide AUDIBLE SILENT AUDIBLE SILENT ARMING ARMING KEYPAD PANIC - The keypad panic condition can be selected for audible or silent response by pressing the [Q] and [#] keys at the same time. Central Station transmission will depend on the value entered in Question 29, Locations 1 and 2.
  • Page 59 Section 6 - System Programming On-line downloading allows the user to call the office and discuss the action required, and al- lows the CS operator to complete the request while on-line with no additional telephone call needed. Pressing [#] + [CODE] enables this ON-LINE downloading option. Refer to USER ON-LINE DOWNLOADING in Section 5: System Operation for the procedure.
  • Page 60 XL-2T Installation & Setup Guide Question 13, L2 - Only User 4 Sends Opening/Closing, CS Test Every Hour When Armed ..................... Default = 0 Enter the digit for the desired system options from the table below. NOTE: The checkmarks highlight which options are selected.
  • Page 61 Section 6 - System Programming Digits TRIGGER TYPE DESCRIPTION OF OPERATION NON-INVERT INVERT DEFINITION Keypad Sounder Follows keypad sounder Ground Start Follows Dialing (Trigger #1 only) Glassbreak Reset Resets Latched Glassbreak detectors Exit Error Follows Exit Error Auto Test Time Momentary pulse when CS Test is transmitted Listen In Active after receiving a CS "kissoff"...
  • Page 62 XL-2T Installation & Setup Guide QUESTIONS 17 – 23 ZONE PROGRAMMING Questions 17 - 23 represent all the options related to programmable zones 1-7. There are four Locations (L1-L4, starting on next page) in each question, which define various zone options.
  • Page 63 Section 6 - System Programming Questions 17 - 23, L1 - Zone Type Descriptions Location 1 defines the zone type for each zone. Enter the digit from the table below. NOTE: The checkmarks highlight which options are selected. Digit STAY ARMING OPTIONS ZONE TYPE AUTO STAY MANUAL STAY...
  • Page 64 XL-2T Installation & Setup Guide 24-Hr. Zones FIRE - Fire with Verification zones contain Fire Verification Logic. Upon detection of the first violation, smoke detector power on conventional 4-wire smoke detectors connected to ZONE modules will be reset for a period of 8 seconds. After this time period, power is restored. For a period of 5 seconds, the fire zone will not be scanned, allowing the smoke detectors to settle.
  • Page 65 Section 6 - System Programming Question 17 - 23, L2 - Loop Type, Fast Zone, & Entry Timer L2 contains the loop EOL type and the entry delay timer to be used for the zone. Enter the digit from the table below. NOTE: The checkmarks highlight which options are selected.
  • Page 66 XL-2T Installation & Setup Guide BYPASS - If this option is selected, then the zone will be bypassable, either individually or by group (refer to Question 09, Locations 1 and 2). Fire zones cannot be bypassed. 24-Hour zones can be bypassed; however, they cannot be un- bypassed if a violation exists on their zone terminals.
  • Page 67 Section 6 - System Programming QUESTIONS 24 - 27 ZONE CS CODES Questions 24 - 27 define the programming codes to be transmitted to the Central Station for each zone, and contain 4 locations, as follows: QUESTION 24 CS CODES for ZONES 1 & 2 ................ DEFAULT = 3132 Question 24, L1 &...
  • Page 68 XL-2T Installation & Setup Guide QUESTION 28 CS CODES for AMBUSH and AC LOSS ............DEFAULT = AAA1 There are 4 locations (L1-L4) in this question, as follows: Question 28, L1 & L2 - Ambush Code ............... Default = AA If an ambush code is defined, then user 15 is the ambush code. The rules regarding dialer format apply here.
  • Page 69 Section 6 - System Programming Question 31, L1 - Cancel Code ................Default = B A cancel code can be transmitted to the Central Station if, after violation of a controlled zone, a user code is entered. If the zone is programmed for restore, then the restore code can be transmitted when the loop status has returned to normal, when bell timeout and loop are normal, or when a code is entered.
  • Page 70 XL-2T Installation & Setup Guide L3 and L4 is the code transmitted to the CS for KEYPAD AUXILIARY condition (by pressing 1 and 3 on the keypad). To disable the keypad auxiliary CS reporting, enter AA. NOTE: The keypad auxiliary condition can be silent or audible (keypad sounder only) based on the Question 13, Location 1.

  • Page 71: Zone Descriptor Programming

    Section 6 - System Programming Zone Descriptor Programming The LCD keypads have the capability to display 12-character zone descriptors that can be programmed directly through the keypad. The zone descriptors appear on the first portion of the second line of LCD display. They are entered as Questions 36 - 42. NOTE: These descriptors can be accessed only by an LCD keypad or PC downloader software.
  • Page 72 XL-2T Installation & Setup Guide 6–30...

  • Page 73: S E C T I O N General

    S E C T I O N Data Entry via Keypads • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • General This section describes the keystrokes used to perform keypad programming.

  • Page 74: What You See On The Lcd Keypad

    XL-2T Installation & Setup Guide QUESTION NUMBERS = ZONE 1-6 LEDs: There are 36 total questions, with multiple data entry locations. Zone 1 through 6 LEDs dis- play the current question number only. The question number is the total you get when you ADD the values of all zone LEDs that are ON.
  • Page 75 Section 7 - Data Entry via Keypads MOVEMENT WITHIN QUESTIONS Zone 1-6 LEDs display the question number and ARM, STAY, INST, and AC/LB LEDs dis- play the contents (data) within each location. Movement from location L1 to the next loc a- tion within any question can be performed by pressing the [#] button.
  • Page 76 XL-2T Installation & Setup Guide 7–4...

  • Page 77: S E C T I O N 8 - System Defaults

    S E C T I O N System Defaults • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • The control panel is preprogrammed from the factory with default values.
  • Page 78 XL-2T Installation & Setup Guide 8–2...

  • Page 79: S E C T I O N User Functions

    S E C T I O N Summary of Keypad Functions • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • User Functions [4-digit user code] ARMING/DISARMING:...
  • Page 80 XL-2T Installation & Setup Guide 9–2...

  • Page 81: Appendix A - Central Station Reporting Formats

    A P P E N D I X Central Station Reporting Formats • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • This security system is designed to transmit data to a Central Station receiver when an alarm, system trouble, or an opening/closing occurs.

  • Page 82: Extended (3X1 Ext. Or 4X1 Ext

    XL-2T Installation & Setup Guide Extended (3x1 Ext. or 4x1 Ext.) The Extended Reporting Format is AAA EZ or AAAA EZ, where: AAAA = Three- or four-digit account number (Program Questions 08 and 09) E = Single-digit event code; it is the first of the 2 programmable reporting code digits Z = Zone or user identifier;...

  • Page 83: Fbii Superfast (4X3X1

    1234 31 (resulting data) Burglary Zone 1 FBII Superfast (4x3x1) The FBII Superfast Reporting Format is AAAA AZZ S, where: AAAA = Four-digit account number (Program Questions 05 and 06) A = Alarm type; it is the first of the 2 programmable reporting code digits ZZ = Zone or user identifier;...

  • Page 84: Ademco Point Id

    XL-2T Installation & Setup Guide ADEMCO Point ID The Point ID Reporting Format is AAA 18 QXYZ GG ZZZ, where: AAAA = Four-digit account number (Program Questions 05 and 06) 18 = Uniquely identifies this format to the receiver and to an automation system, but is not displayed or printed.
  • Page 85 Appendix A 24-HOUR ALARM TYPES 24-HOUR TROUBLE TYPES Digit EVENT ENGLISH OUTPUT AT Digit EVENT ENGLISH OUTPUT AT CODE CS RECEIVER CODE CS RECEIVER Medical Medical Pendant Transmitter Silent Panic Panic Alarm Audible Panic Silent Panic Tamper Audible Panic 24-Hour Non-Burg Burglary Loss of Heat 24-Hour Alarm...
  • Page 86 XL-2T Installation & Setup Guide A–6...

  • Page 87: Appendix B - Troubleshooting

    A P P E N D I X Troubleshooting • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • SYMPTOM POSSIBLE CAUSE REMEDY...
  • Page 88 XL-2T Installation & Setup Guide B–2...

  • Page 89: Appendix C - System Planning Worksheet

    A P P E N D I X System Planning Worksheet • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • ZONE ZONES OPTIONS...
  • Page 90 XL-2T Installation & Setup Guide C–2...

  • Page 91: Appendix D - System Programming Worksheet

    A P P E N D I X System Programming Worksheet • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 00-INSTALLER CODE DEFAULT = 2468 01 PRIMARY TELEPHONE NUMBER...
  • Page 92 XL-2T Installation & Setup Guide ZONE DESCRIPTORS 36 ZONE 1 DESCRIPTOR DEFAULT = ZONE 1 37 ZONE 2 DESCRIPTOR DEFAULT = ZONE 2 38 ZONE 3 DESCRIPTOR DEFAULT = ZONE 3 39 ZONE 4 DESCRIPTOR DEFAULT = ZONE 4 40 ZONE 5 DESCRIPTOR...

  • Page 93: Appendix E - Warnings And Limitations

    A P P E N D I X Warnings and Limitations • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • While this system is an advanced design security system, it does not offer guaranteed protection against burglary, fire, or other emergency.
  • Page 94 XL-2T Installation & Setup Guide E–2...

  • Page 95: Appendix F - Regulatory Agency Statements

    A P P E N D I X Regulatory Agency Statements • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC) STATEMENT NOTICE...
  • Page 96 XL-2T Installation & Setup Guide FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information. This equipment generates and uses radio frequency energy, and if not installed and used properly (that is, in strict accordance with the manufacturer's instructions) may cause interference to radio and television reception.

  • Page 97: Appendix G - Warranty Information

    A P P E N D I X Warranty Information • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • LIMITED WARRANTY Fire Burglary Instruments Inc., a Subsidiary of Pittway Corporation, and Pittway Corporation, its divisions, subsidiaries, and affiliates ("Seller") 149 Eileen Way, Syosset, New York 11791, warrants...
  • Page 98 Subsidiary of PITTWAY CORPORATION 149 Eileen Way, Syosset, New York 11791 Copyright © 2000 PITTWAY CORPORATION ÊN9833V2eŠ N9833V2 2/00...
