FBII XL-2T User Manual
Hide thumbs
Also See for XL-2T:
- Installation and setup manual (104 pages) ,
- Hookup and installation instructions (71 pages) ,
- Installation and setup manual (98 pages)
Related Manuals for FBII XL-2T
Summary of Contents for FBII XL-2T
-
Page 1: Security System
Security System User Guide FIRE BURGLARY INSTRUMENTS, INC. N9819V3 2/00... -
Page 2: Table Of Contents
Table Of Contents QUICK REFERENCE........................3 INTRODUCTION ..........................5 SYSTEM REFERENCE........................6 TURNING THE SYSTEM ON......................9 TURNING THE SYSTEM OFF....................12 USER CODES..........................13 MISCELLANEOUS COMMANDS .....................14 TESTING THE SYSTEM......................16 NATIONAL FIRE PROTECTION ASSOCIATION RECOMMENDATIONS ON SMOKE DETECTORS..........................17 EMERGENCY EVACUATION.....................18 GLOSSARY............................20 FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT ......23 TELEPHONE OPERATIONAL PROBLEMS ................23 LIMITATIONS OF THIS ALARM SYSTEM................25... -
Page 3: Quick Reference
Quick Reference TO TURN SYSTEM ON Check to make sure the system is ready, (Green READY light is † Enter your 4-digit user code. Exit through a door designated by your installer as an exit/entry door. The ON/OFF (ARM) light will light. TO TURN SYSTEM OFF Enter through a door designated by your installer as an exit/entry door... - Page 4 The ON/OFF (ARM) light, the INSTANT light, and the STAY light will all be on. TO RESET SMOKE DETECTOR 1. Enter your 4-digit user code. READY light is not available on all keypads. - 4 -...
-
Page 5: Introduction
Introduction Congratulations on your decision to protect your home or business with the XL-2T security system. You have chosen a reliable, state- of-the-art security system that is remarkably easy to operate. Your system has been professionally installed by your local Security Company whose representative can explain the specifics of your system. -
Page 6: System Reference
System Reference ZONE DESCRIPTIONS In the following table, enter a description of the area of protection for each zone. Example: Zone 1 Windows on North side of building Zone 4 Main entrance to building. ZONE DESCRIPTION _______________________________________ Entry time ________ Door __________ Exit time ________ Entry time ________ Door __________ Exit time is the same for all designated Entry/Exit doors. - Page 7 Buttons on XL-4600SM keypad only - 7 -...
-
Page 8: Door Strike
System Reference (cont) USER CODE ASSIGNMENTS In the following table, enter the names of the individuals assigned to each specific User ID number. USER ID ASSIGNED TO (MASTER USER * ) (MASTER USER * ) Door Strike ______________________ (If user 13 is not assigned to door strike, then any user can activate the door strike.) Only Turns... -
Page 9: Turning The System On
Account # Telephone # Turning The System On IS THE SYSTEM READY? You can turn the burglar portion of your security system ON and OFF. Before you can turn the system ON, it must be “ready.” If you have a protected door open, or someone is moving in view of a motion detector, the system will not display “READY.”... - Page 10 Turning The System ON (cont) TO TURN SYSTEM ON AND LEAVE Enter your 4-digit user code. The System ON, (ARM) light will go ON or the display will show: ON: AWAY ..Exit through a door designated by your installer as an exit/entry door. You must leave within the exit time programmed by your installer.
- Page 11 Turning The System ON (cont) NOTE: This system can be programmed by the installer for the AUTO-STAY feature which automatically bypasses interior zones if you arm the system and do not exit through a delay zone during exit time. TO TURN SYSTEM ON IN INSTANT MODE In INSTANT mode, all alarm sensors, including those on doors and windows, will report an alarm immediately if activated.
-
Page 12: Turning The System Off
Turning The System OFF When you turn the system OFF, you turn OFF only the burglar portion of your system; any smoke or heat detectors and panic keys will remain ON. You must enter through a designated entry door and turn OFF the system within the time allowed. -
Page 13: User Codes
User Codes TO ADD OR CHANGE A USER CODE Users can be added or changed directly at the keypad. Your system can have up to 15 different user codes. Users #1 and #2 are the only users allowed to add or delete other user codes. -
Page 14: Miscellaneous Commands
Miscellaneous Commands SEND HELP ALERTS Your system can be programmed for 3 separate keypad Send Help alerts that would send an emergency signal to your Central Station. See the System Reference sheet to see which have been programmed for your system. DURESS Your system can be programmed to send an emergency signal to the Central Station if you are forced to enter the premises. - Page 15 Miscellaneous Commands (cont) TURN CHIME ON/OFF Chime is an optional feature that causes the keypad to chime when selected doors are opened while the burglary protection is OFF or disarmed. Only your installer can program a zone for the Chime feature. Once programmed, you can turn Chime ON or OFF to meet your daily needs.
-
Page 16: Testing The System
Testing The System SYSTEM TEST It is recommended that you test your system once a week using the following procedure: NOTE: If your system is monitored, contact your Central Station before you perform this test. 1. Turn your security system ON. 2. -
Page 17: National Fire Protection Association Recommendations On Smoke Detectors
National Fire Protection Association Recommendations On Smoke Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association’s (NFPA) Standard #72 noted below. Early warning fire detection is best achieved by the installation of fire detection equipment in all rooms and areas of the household as follows: A smoke detector installed outside of each separate sleeping area, in the immediate vicinity of the bedrooms and on each additional story of the family living unit, including... -
Page 18: Emergency Evacuation
Emergency Evacuation Establish and regularly practice a plan of escape in event fire. following steps recommended National Fire Protection Association: 1. Position your detector or your interior and/or exterior sounders so that they can be heard by all occupants. 2. Determine two means of escape from each room. One path of escape should lead to the door that permits normal exit from the building. - Page 19 - 19 -...
-
Page 20: Glossary
Glossary AC INDICATOR: Small green power ON/OFF light between the center buttons on the keypad. When lit, the system is running on primary power; when not lit, the system is running off the backup battery. ALARM: Sound from keypad or other horn/siren indicates a burglar alarm, fire alarm, or other condition you should be alerted to. - Page 21 Glossary (cont) EXIT DELAY: The period of time allowed between turning the system on and leaving through a designated exit/entry door before the system will register an alarm condition. This is determined at the time of installation. INTERIOR ZONE: An interior zone is a group of points that protect the interior of your premises.
- Page 22 Glossary (cont) SENSOR: The actual alarm sensor, detector, or device installed to detect an intrusion, fire, or environmental problem. Examples include: door contacts, window contacts, motion sensors, glassbreak sensors, smoke detectors, rate-of-rise heat detectors, temperature sensors, flood/water sensors, and carbon monoxide gas detectors. SILENT CONDITION: Most types of alarms and troubles alert you with the keypad sounder and the sirens, horns, or speakers located in your premises.
-
Page 23: Federal Communications Commission (Fcc) Statement
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information: This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. - Page 24 service. The user may not under any circumstances (in or out of warranty) attempt any service or repairs to the system. It must be returned to the factory or an authorized service agency for all repairs. This control unit was manufactured under rigid quality standards and complies with all UL requirements for its intended use.
-
Page 25: Limitations Of This Alarm System
LIMITATIONS OF THIS ALARM SYSTEM While this system is an advanced design security system, it does not offer guaranteed protection against burglary, fire, or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of reasons. For example: Intruders may gain access through unprotected openings or have the technical sophistication to bypass an alarm sensor or disconnect an alarm warning device. - Page 26 material on the mirrors, windows, or any part of the optical system can reduce their detection ability. Passive Infrared Detectors sense changes in temperature; however, as the ambient temperature of the protected area approaches the temperature range of 90 degrees to 150 degrees Fahrenheit, the detection performance can decrease.
- Page 27 LIMITATIONS OF THIS ALARM SYSTEM (cont) Alarm warning devices such as sirens, bells or horns may not alert people or wake up sleepers who are located on the other side of closed or partly open doors. If warning devices sound on a different level of the residence from the bedrooms, then they are less likely to waken or alert people inside the bedrooms.
-
Page 28: Limited Warranty
LIMITED WARRANTY Fire Burglary Instruments, Inc., a subsidiary of Pittway Corporation, and its divisions, subsidiaries and affiliates ("Seller"), 149 Eileen Way, Syosset, New York 11791, warrants its security equipment (the "product") to be free from defects in material and workmanship for one year from date of original purchase, under normal use and service. Seller's obligation is limited to repairing or replacing, at its option, free of charge for parts, labor, or transportation, any product proved to be defective in materials or workmanship under normal use and service. - Page 29 WARRANTY OR OTHERWISE, REGARDLESS OF CAUSE OR ORIGIN, SELLER'S MAXIMUM LIABILITY SHALL NOT IN ANY CASE EXCEED THE PURCHASE PRICE OF THE PRODUCT, WHILE SHALL BE THE COMPLETE AND EXCLUSIVE REMEDY AGAINST SELLER. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
- Page 30 FIRE BURGLARY INSTRUMENTS, INC. Subsidiary of PITTWAY CORPORATION 149 Eileen Way, Syosset, New York 11791 ÊN9819V3ÆŠ N9819V3 2/00...
