- Page 1 Italian Music Experience GOLD NOTE PA-1175 PA-1175 Stereo Power Amplifier OWNER’S MANUAL...
-
Page 2: Important Safety Information
The power Chord supplied must be used only on this unit. Gold Note does not have responsibility for any improper use of this unit. This appliance has a serial number located on the rear panel. - Page 3 IMPORTANT SAFETY INFORMATION 1 Read these instructions and store them. 9 Protect the power cord from being walked on or pinched particularly plugs, convenience 2 Heed all warnings. receptacles, and the point where they exit from the apparatus. 3 Follow the instructions. 10 Only use attachments/accessories specified by the 4 Do not use this apparatus near water.
-
Page 4: Description And Specifications
DESCRIPTION & SPECIFICATIONS The PA-1175 is one of the most innovative stereo Power PA-1175 features a unique adjustable Damping Factor Amplifiers available on the market. design to set a DF of 250 or 25 allowing an ideal match with any kind of speakers: delivering full power and... - Page 5 DESCRIPTION & SPECIFICATIONS HIGH POWER AMP SPECIFICATIONS The PA-1175 is a 175Watt per channel @ 8ohm Power output: 175W per channel @ 8Ω and 350W @ 8Ω Stereo Power Amplifier bridgeable to have a mono in mono (BTL) 350Watt per channel Frequency response: 1Hz-100kHz at +/-1dB THD –...
-
Page 6: Front Panel Overview
When the DF is set on HIGH, the STATUS LED is BLUE When the DF is set on LOW, the STATUS LED is GREEN Every time the PA-1175 is switched ON, the DF is set on HIGH by default OWNER’S MANUAL... -
Page 7: Rear Panel Overview
REAR PANEL OVERVIEW AUDIO INPUT XLR Balanced Left Analogue Audio IN (and XLR Mono IN if configured in BTL mode) RCA Unbalanced Left Analogue Audio IN (and RCA Mono IN configured in BTL mode) XLR Balanced Right Analogue Audio IN RCA Unbalanced Right Analogue Audio IN SPEAKER OUT Speaker Out Left Channel (positive pole “+”... -
Page 8: Warranty And Service
WARRANTY & SERVICE WARRANTY To validate the warranty is necessary to register the unit on the Gold Note internet web site within 15 days from the purchase on the appropriate area of the web site: www.goldnote.it/warranty If the unit is not registered correctly or has been purchased from a different country of the purchaser home address the unit will not be covered by any warranty and the registration will be refused. -
Page 9: Faq And Troubleshooting
•Connect them properly •The interconnect cables are not properly connected to the amp. •Substitute the fuse with one of the •One of the fuses is blown same value For spare parts visit the official Gold Note store at: http://www.akamaiaudio.it/ OWNER’S MANUAL... - Page 10 NOTE OWNER’S MANUAL...
- Page 11 NOTE OWNER’S MANUAL...
- Page 12 Italian Music Experience www.goldnote.it...
