GOLD NOTE
PA-1175
DF
PA-1175
Stereo Power Amplifier
Stereo 175W@8Ohm - Bridged Mono 350W@8Ohm
OWNER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the PA-1175 and is the answer not in the manual?

Questions and answers

Related Manuals for Gold Note PA-1175

Summary of Contents for Gold Note PA-1175

  • Page 1 GOLD NOTE PA-1175 PA-1175 Stereo Power Amplifier Stereo 175W@8Ohm - Bridged Mono 350W@8Ohm OWNER’S MANUAL...

  • Page 2: Important Safety Information

    The power Chord supplied must be used only on this unit. Gold Note does not have responsibility for any improper use of this unit This appliance has a serial number located on the rear panel. Please record the model and serial numbee and retain them for your records.
  • Page 3 IMPORTANT SAFETY INFORMATION 1 Read these instructions. normally, or has been dropped. 2 Keep these instructions. • Do not expose this apparatus to drips or splashes. • Do not place any objects filled with liquids, such as vases, on 3 Heed all warnings. the apparatus.
  • Page 4 Besides Gold Note introduced a new unique Optical The PA-1175 is built around a very solid steel chassis Protection for the output stage, featuring optical completed by large massive panels of aluminum to avoid decoupling that despite the traditional electronic ones...
  • Page 5 HIGH POWER AMP: Power output: 175W per channel @ 8Ω and 350W @ 8Ω in mono (BTL) The PA-1175 is a 175Watt per channel @ 8ohm Frequency response: 1Hz-100kHz at +/-1dB Stereo Power Amplifier bridgeable to have a mono 350Watt per channel.

  • Page 6: Front Panel

    FRONT PANEL GOLD NOTE PA-1175 - Power On LED Light Blue with High Damping-Factor 250 for low sensitivity speakers and Green for Low Damping-Factor 25 for high sensitivity small driver/monitor speakers - Standby Button - DF (Damping-Factor) Selectable 250 or 25 Damping Factor OWNER’S MANUAL...

  • Page 7: Rear Panel

    REAR PANEL POWER: ANALOGUE AUDIO IN: - AC Power ON/OFF - XLR Balanced Left Analogue Audio IN (and XLR Mono IN if configured in BTL mode) - AC Power Plug IEC - RCA Unbalanced Left Analogue Audio IN (and RCA Mono IN configured in BTL mode) - BTL SWITCH Stereo working left side switch position Mono working right side switch position...

  • Page 8: Customer Service

    WARRANTIES WARRANTIES REGISTRATION To validate the warranty is necessary to register the unit on the Gold Note internet web site within 15 days from the purchase on the appropriate area of the web site: http://www.goldnote.it/ If the unit is not registered correctly or is been purchased from a different coun- try of the purchaser origin/home the unit will not be covered by any warranty and the eventual registration refused.
  • Page 9 •The interconnect cables are not properly connected to the amp. •Substitute the fuse with one of the •One of the fuses is blown same value For spare parts visit the official Gold Note store at: http://www.akamaiaudio.it/ OWNER’S MANUAL page 8...
  • Page 10 USER NOTE OWNER’S MANUAL page 9...
  • Page 11 USER NOTE OWNER’S MANUAL page 10...
  • Page 12 Via della Gora, 6 Montespertoli (Florence) Italy 50025 Tel. + 39 0571 675005 Fax. + 39 0571 675013 www.goldnote.it...
